基于矩量法的电大目标RCS核外并行计算
doi: 10.3724/SP.J.1146.2010.00519
Parallel Out-of-core Calculation of Electrically Large Objects RCS Based on MOM
-
摘要: 核外求解计算可以解决计算机内存不足的问题，但由于硬盘读写速度的限制，使得问题的求解速度过慢。针对上述问题，该文采用了核外并行求解方法；为充分利用各计算节点的内存和减少读写数据的时间，将矩阵按分块依次并行消元，加快了问题求解速度。计算了金属立方体、金属组合体和飞机模型的双站雷达散射截面，并与常规核外并行方法、核内并行方法进行了比较。结果表明，该文方法可快速、有效地求解电大目标的电磁散射问题，而且不损失计算精度。Abstract: The problems, which can not be calculated due to the insufficient of memory, can be solved with out-of- core solving method, but it takes too longer time because the speed limit of the data reading/writing on the disk. To solve the above problem, parallel out-of-core solving method is used. In order to use the RAM sufficiently and reduce the reading/writing time, the matrix is eliminated by looping over blocks in parallel, so the solving speed is accelerated. The bistatic RCS of a PEC cube, a PEC union and a plane model are calculated, respectively. Parallel block out-of-core solver, which is proposed in this paper, is compared with usual parallel out-of-core solver and parallel in-core solver. The results indicate that the method in this paper can effectively solve the scattering problems of electrically large objects, and the calculation precision is not lost.
-
李晓峰, 谢拥军, 王元源. 半空间电大导体目标散射的高频分析方法 [J].电子与信息学报.2009, 31(5):1268-1270浏览[7]Li X F, Xie Y J, and Wang Y Y. High-frequency analysis on scattering from conductive targets with electrically large size in half space [J].Journal of Electronics Information Technology.2009, 31(5):1268-1270[8]Gao Z H and Wang M L. An Efficient algorithm for calculating aircraft RCS based on the geometrical characteristics [J].Chinese Journal of Aeronautics.2008, 21(4):296-303[9]袁军, 刘其中, 郭景丽等. 电大尺寸涂层散射体RCS的快速并行分析 [J].电子与信息学报.2008, 30(10):2360-2363浏览[10]Yuan J, Liu Q Z, and Guo J L, et al.. Rcs fast analysis of electrically large coated scatters via parallel method [J].Journal of Electronics Information Technology.2008, 30(10):2360-2363[11]卢光辉, 孙世新, 聂在平等. 并行处理技术在电大尺寸复杂目标电磁散射中的应用[J].电子学报.2003, 31(6):882-885[14]Jaime L, Marcos R P, and Raj M, et al.. Parallelized multilevel characteristic basis function method for solving electromagnetic scattering problems [J].Microwave and Optical Technology Letters.2009, 51(12):2963-2969[15]Rao S M, Wilton D R, and Glisson A W. Electromagnetic scattering by surfaces of arbitrary shape [J].IEEE Transaction on Antennas and Propagat.1982, 30(5):409-418[16]J. Thomas King著, 林成森, 颜起居, 李明霞译. 数值计算引论 [M]. 南京: 南京大学出版社, 2002: 136-148. -
