基于俯仰频率分集技术的波束形成方法

吴旭姿; 刘峥; 谢荣

doi:10.11999/JEIT160667

基于俯仰频率分集技术的波束形成方法

doi: 10.11999/JEIT160667

吴旭姿¹,
刘峥^1, ,,
谢荣¹

基金项目:

国家自然科学基金(61301282)

计量
- 文章访问数: 1198
- HTML全文浏览量: 170
- PDF下载量: 187
- 被引次数: 0
出版历程
- 收稿日期: 2016-06-24
- 修回日期: 2016-11-01
- 刊出日期: 2016-12-19

Beamforming with Vertical Frequency Diverse Array

WU Xuzi¹,
LIU Zheng^{1
, ,},
XIE Rong¹

Funds:

The National Natural Science Foundation of China (61301282)

摘要

摘要: 传统频率分集阵列雷达在水平阵元间引入线性频率偏差，其波束在方位维与距离维具有耦合性，且存在栅瓣。针对此问题，该文提出一种基于俯仰频率分集技术的波束形成方法。首先建立俯仰频率分集阵列雷达信号模型，详细分析了发射方向图的时间依赖性和栅瓣特性。然后通过设计接收端的阵元参数，合成无栅瓣的发射-接收方向图。仿真实验验证了所提方法的有效性，所得波束在距离维与方位维无耦合，且主瓣宽度较窄。
- 相控阵雷达 /
- 波束形成 /
- 俯仰频率分集
Abstract: In most of the frequency diverse array radars, a small linear frequency offset is always applied across the horizontal array elements, generating a different beampattern with coupling between the azimuth dimension and range dimension. Moreover, the grating lobes also exist in the range dimension. To overcome this, a method of beamforming with the vertical frequency diverse array is proposed. Based on the radar signal model, the characteristics of the time dependence and grating lobes in the transmit pattern are analyzed. Then the transmit-receive pattern with no grating lobes is synthesized by designing the parameters of the receive elements. Simulations results show the validity of the proposed method. The synthesized pattern is range-dependent only, and also has the smaller beamwidth of the mainlobe.
- Phased array radar /
- Beamforming /
- Vertical frequency diversity

HTML全文

参考文献(17)

FISHLER E, HAIMOVICH A M, BLUM R S, et al. MIMO radar: An idea whose time has come[C]. Proceedings of IEEE Radar Conference, Philadelphia, Pennsylvania, USA, 2004: 71-78. doi: 10.1109/NRC.2004.1316398.

HAYKIN S. Cognitive radar: A way of the future[J]. IEEE Signal Processing Magazine, 2006, 23(1): 30-40. doi: 10.1109/ MSP.2006.1593335.

ANTONIK P, WICKS M C, GRIFFITHS H D, et al. Frequency diverse array radars[C]. Proceedings of IEEE Radar Conference, Verona, NY, USA, 2006: 215-217. doi: 10.1109/RADAR.2006.1631800.

ANTONIK P, WICKS M C, GRIFFITHS H D, et al. Multi-mission multi-mode waveform diversity[C]. Proceedings of IEEE Radar Conference, Verona, NY, USA, 2006: 580-582. doi: 10.1109/RADAR.2006.1631858.

SAMMARTINO P F, BAKER C J, and GRIFFITHS H D. Frequency diverse MIMO techniques for radar[J]. IEEE Transactions on Aerospace and Electronic Systems, 2013, 49(1): 201-222. doi: 10.1109/TAES.2013.6404099.

WANG Wenqin. Frequency diverse array antenna: New opportunities[J]. IEEE Antennas and Propagation Magazine, 2015, 57(2): 145-152. doi: 10.1109/MAP.2015.2414692.

WANG Wenqin and SO H C. Transmit subaperturing for range and angle estimation in frequency diverse array radar[J]. IEEE Transactions on Signal Processing, 2014, 62(8): 2000-2011. doi: 10.1109/TSP.2014.2305638.

XU Jingwei, LIAO Guisheng, ZHU Shengqi, et al. Joint range and angle estimation using MIMO radar with frequency diverse array[J]. IEEE Transactions on Signal Processing, 2015, 63(13): 3396-3410. doi: 10.1109/TSP.2015.2422680.

XU Jingwei, ZHU Shengqi, and LIAO Guisheng. Space- time-range adaptive processing for airborne radar systems[J]. IEEE Sensors Journal, 2015, 15(3): 1602-1610. doi: 10.1109/ JSEN.2014.2364594.

王伟伟, 吴孙勇, 许京伟, 等. 基于频率分集阵列的机载雷达距离模糊杂波抑制方法[J]. 电子与信息学报, 2015, 37(10): 2321-2327. doi: 10.11999/JEIT150187.

WANG Weiwei, WU Sunyong, XU Jingwei, et al. Range ambiguity clutter suppression for airborne radar based on frequency diverse array[J]. Journal of Electronics Information Technology, 2015, 37(10): 2321-2327. doi: 10.11999/JEIT150187.

SHAO Huaizong, CHEN Hui, and LI Jingchi. Transmit energy focusing in two-dimensional sections with frequency diverse array[C]. 2015 IEEE China Summit and International Conference on Signal and Information Processing (ChinaSIP), Chengdu, China, 2015: 104-108. doi: 10.1109/ChinaSIP.2015. 7230371.

BASIT A, QURESHI I M, KHAN W, et al. Beam pattern synthesis for a cognitive frequency diverse array radar to localize multiple targets with same direction but different ranges[C]. 2016 13th International Bhurban Conference on Applied Science and Technology (IBCAST), Islamabad, Pakistan, 2016: 682-688. doi: 10.1109/IBCAST.2016. 7429954.

KHAN W and QURESHI I M. Frequency diverse array radar with time-dependent frequency offset[J]. IEEE Antennas and Wireless Propagation Letters, 2014, 13(2): 758-761. doi: 10.1109/LAWP.2014.2315215.

KHAN W, QURESHI I M, and SAEED S. Frequency diverse array radar with logarithmically increasing frequency offset[J]. IEEE Antennas and Wireless Propagation Letters, 2015, 14(3): 499-502. doi: 10.1109/LAWP.2014.2368977.

VAN TREES H L. Optimum Array Processing[M]. New York: Wiley, 2002: 47-59.

STOICA P, LI Jian, and XIE Yao. On probing signal design for MIMO radar[J]. IEEE Transactions on Signal Processing, 2007, 55(8): 4151-4161. doi: 10.1109/TSP.2007.894398.
