一种用于加速FPGA设计空间探索的电路特性驱动半监督建模方法

杨立群; 李威; 黄志洪; 孙嘉斌; 杨海钢

doi:10.11999/JEIT150162

一种用于加速FPGA设计空间探索的电路特性驱动半监督建模方法

doi: 10.11999/JEIT150162

2.
(中国科学院电子学研究所北京 100190) ②(中国科学院大学北京 100049)

基金项目:

国家自然科学基金(61271149)

计量
- 文章访问数: 1242
- HTML全文浏览量: 109
- PDF下载量: 540
- 被引次数: 0
出版历程
- 收稿日期: 2015-01-28
- 修回日期: 2015-04-22
- 刊出日期: 2015-10-19

Circuit Characteristics-driven Semi-supervised Modelling Approach for Accelerating FPGA Design Space Exploration

2.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)

Funds:

The National Natural Science Foundation of China (61271149)

摘要

摘要: 该文提出一种电路特性驱动的半监督建模方法来探索FPGA架构设计空间。通过加入电路特性作为输入来构建一个通用的FPGA性能模型，该方法能够精确预测指定电路在特定FPGA架构上实现的性能。实验结果显示该方法在预测电路在FPGA上实现的面积时，平均相对误差达到6.25%；预测延时时，平均相对误差可达4.23%，具有与半监督模型树(Semi-supervised Model Tree, SMT)方法可比的预测精度。同时，该文方法加速了FPGA性能建模过程，与SMT方法比较，在6核Intel服务器平台Intel Xeon E7-4807上，探索具有百万架构的FPGA设计空间时，该文方法可将时间成本由500 h降低为250 h。
- FPGA设计空间 /
- 半监督建模方法 /
- 电路特性
Abstract: A circuit characteristics-driven semi-supervised modelling approach is proposed for FPGA architecture design space exploration. By including circuit characteristics as input, the proposed approach can estimate the performance of specific circuit on certain architecture accurately. Experimental results illustrate that the approach estimates the area with Mean Relative Error (MRE) up to 6.25%, and delay up to 4.23%, which is comparable to the Semi-supervised Model Tree (SMT) approach. Meanwhile, the proposed approach speedups the modelling process. Compared to the SMT approach, the proposed approach reduces the time cost from 500 h to 250 h when exploring a design space with millions of architectures inside on Intel Xeon E7-4807 platform.
- FPGA design space /
- Semi-supervised modelling approach /
- Circuit characteristics

HTML全文

参考文献(16)

Luu J, Goeders J, Wainberg M, et al.. VTR 7.0: next generation architecture and CAD system for FPGAs[J]. ACM Transactions on Reconfigurable Technology and Systems, 2014, 7(2): 6:1-6:30.

Marquardt A, Betz V, and Rose J. Speed and area tradeoffs in cluster-based FPGA architectures[J]. IEEE Transactions on Very Large Scale Integration (VLSI) Systems, 2000, 8(1): 84-93.

Ahmed E and Rose J. The effect of LUT and cluster size on deep-submicron FPGA performance and density[J]. IEEE Transactions on Very Large Scale Integration (VLSI) Systems, 2004, 12(3): 288-298.

Jiang Zheng-hong, Lin C Y, Yang Li-qun, et al.. Exploring architecture parameters for dual-output LUT based FPGAs[C]. Proceedings of the 24th International Conference on Field Programmable Logic and Applications, Munich, Germany, 2014: 1-6.

Betz V, Rose J, and Marquardt A. Architecture and CAD for Deep-Submicron FPGAs [M]. Netherlands, Kluwer Academic Publishers, 1999: 15-20.

Gao Hai-xia, Yang Yin-tang, Ma Xiao-hua, et al.. Analysis of the effect of LUT size on FPGA area and delay using theoretical derivations[C]. Proceedings of the 6th International Symposium on Quality of Electronic Design, San Jose, CA, USA, 2005: 370-374.

Smith A, Wilton S, and Das J. Wirelength modeling for homogeneous and heterogeneous FPGA architectural development[C]. Proceedings of the 17th ACM/SIGDA international symposium on Field programmable gate arrays, Monterey, CA, USA, 2009: 181-190.

Das J, Lam A, Wilton S, et al.. An analytical model relating FPGA architecture to logic density and depth[J]. IEEE Transactions on Very Large Scale Integration (VLSI) Systems, 2011, 19(12): 2229-2242.

Smith A, Constantinides G, and Cheung P. FPGA architecture optimization using geometric programming[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2010, 29(8): 1163-1176.

Pandurangaiah Y, Reddy V, and Chakravarthy K. Area-delay estimation by concurrent optimization of FPGA architecture parameters using geometric programming[J]. International Journal of Computer Applications, 2013, 82(18): 4-11.

Mehri H and Alizadeh B. An analytical dynamic and leakage power model for FPGAs[C]. Proceedings of the 22nd Iranian Conference on Electrical Engineering (ICEE), Tehran, 2014: 300-305.

Leow Yoon-kah. Post-routing analytical models for homogeneous FPGA architectures[D]. [Ph. D. dissertation], The University of Arizona, 2013.

Yang Li-qun, Yang Hai-gang, Li Wei, et al.. A semi-supervised modeling approach for performance characterization of FPGA architectures[C]. Proceedings of the 24th International Conference on Field Programmable Logic and Applications, Munich, Germany, 2014: 1-6.

Wang Y and Witten I H. Inducing model trees for continuous classes[C]. Proceedings of the Ninth European Conference on Machine Learning, Prague, Czech Republic, 1997: 128-137.

Brayton R and Mishchenko A. ABC: an academic industrial-strength verification tool[J]. Computer Aided Verification, 2010, 6174: 24-40.

Zgheib G, Yang Li-qun, Huang Zhi-hong, et al.. Revisiting and-inverter cones[C]. Proceedings of the 2014 ACM/SIGDA International Symposium on Field-Programmable Gate Arrays, Monterey, CA, USA, 2014: 45-54.
