利用反向补偿原理控制硅CVD外延层中的金属杂质和微缺陷
CONTROLLING METALLIC IMPURITY AND MICRODEFECT IN SILICON CVD EPITAXY LAYER USING CONTRARY COMPENSATION
-
摘要: 本文分析了硅CVD外延生长中金属杂质沾污、吸附-解吸机理模型和微缺分布规律,提出了用反向补偿原理优化外延工艺,有效地解决了硅外延层的金属杂质和微缺陷。Abstract: This paper analyzes the mechanism models of metallic impurity infection and adsorption-desorption, and the distribution law of microdefect in growing of silicon CVD epitaxy, and then a new epitaxy technology is proposed, which is optimized by using contrary compensation, and by which the metallic impurity and microdefect in silicon epitaxy layer are reduced effectively.
-
黄汉尧,等.半导体器件工艺原理.上海:上海科技出版社,1985, 46-93.[2]刘玉玲,等实用发明创造工程学.石家庄:河北科学技术出版社,1993, 9, 269-274.[3]Srinvasan G R. Solid State Tech., 1981, 124(11): 101-104.[4]胡国仁,等.P/P+外延工艺技术的操作.第八届全国半导体集成电路硅材料学术会议论文集,杭州:1993,43.[5]Zhou Z H. J. Vac. Sci. Tech., 1991, B9(2): 374-376.[6]刘玉玲.半导体技术,1981, (1): 1-9.[7]Sator S, et al., Jpn J. Appl. Phys., 1981, 20(1): 143-145. -
