关于无截获栅电子枪栅网形状的研究
RESEARCH ON GRID-MESH SHAPES OF NON-INTERCEPTINGGRIDDED GUNS
-
摘要: 本文叙述了采用三种不同形状栅网(方孔栅、六角孔栅、环形栅)的导流系数为1.4p的无截获栅栅控电子枪,在电子注分析器上进行实验的详细情况。文中扼要地介绍了无截获栅栅控枪使用三种不同栅网的设计方法,并给出了所用实验系统的结构。三种栅网的荧光屏显示和小孔扫描测试的结果表明,环形栅的电子光学性能最佳。从概念上定性地分析并讨论了环形栅优于其它栅的原因。这为今后设计无截获栅枪指出了方向。通过对多把无截获栅枪的实验研究和计算机计算,纠正了过去有关栅控枪和基础无栅枪性能上的一些概念上的错误结论。
-
关键词:
Abstract: A non-intercepting gridded gun with the perveance of 1.4p is described. Three different grid-mesh shapes (square, hexagonal and annular) are chosen, and the experimental results in an electron beam analyzer are given in detail. The design methods of the gun for each grid-mesh shape and the structures of the test system are briefly introduced. The results measured by using the fluorescent screen and pin-hole scanning technique are given. It turns out that the annular grid possessed the best electron optical performance. The reason that the performance of the annular grid is better than the others is qualitatively explained and discussed, so as to give the guide lines of how to design the non-intercepting gridded guns. Through the experiment and computer calculation for several non-intercepting gridded guns, the previous wrong conceptional conclusions about the performances of the guns with and without grid may be corrected. -
李崇山、宋培德,栅控双模电子枪计算机研究双模枪研究第一阶段,电子对抗行波管交流会文献.1979年4月,广州.[3]微波管电子光学系统设计手册第十章,电子管设计手册编辑委员会,国防工业出版社,1981年.
