用场发射显微镜测量单壁碳纳米管的逸出功

张兆祥 孙建平 侯士敏 赵兴钰 施祖进 顾镇南 刘惟敏 薛增泉

张兆祥, 孙建平, 侯士敏, 赵兴钰, 施祖进, 顾镇南, 刘惟敏, 薛增泉. 用场发射显微镜测量单壁碳纳米管的逸出功[J]. 电子与信息学报, 2002, 24(11): 1708-1713.
引用本文: 张兆祥, 孙建平, 侯士敏, 赵兴钰, 施祖进, 顾镇南, 刘惟敏, 薛增泉. 用场发射显微镜测量单壁碳纳米管的逸出功[J]. 电子与信息学报, 2002, 24(11): 1708-1713.
Zhang Zhaoxiang, Sun Jianping, Hou Shimin, Zhao Xingyu, Shi Zujin, Gu Zhennan, Liu Weimin, Xue Zengquan. Field emission microscopy study of the work function of single-walled carbon nanotubes[J]. Journal of Electronics & Information Technology, 2002, 24(11): 1708-1713.
Citation: Zhang Zhaoxiang, Sun Jianping, Hou Shimin, Zhao Xingyu, Shi Zujin, Gu Zhennan, Liu Weimin, Xue Zengquan. Field emission microscopy study of the work function of single-walled carbon nanotubes[J]. Journal of Electronics & Information Technology, 2002, 24(11): 1708-1713.

用场发射显微镜测量单壁碳纳米管的逸出功

Field emission microscopy study of the work function of single-walled carbon nanotubes

  • 摘要: 该文利用场发射显微镜对单壁碳纳米管的逸出功进行了研究和测量。未进行加热除气的单壁碳纳米管的表面吸附大量气体,此时测量的逸出功不是清洁表面单壁碳纳米管的逸出功。实验首先加热除气得到单壁碳纳米管的场发射清洁像,然后利用场发射显微镜测量I-V曲线,得到Fowler-Nordheim直线斜率;再利用透射电镜观测单壁碳纳米管微束形貌像,测量管束半径,通过三种公式估算比例因子,最后计算得到单壁碳纳米管的逸出功。
  • S. Iijima, T.Ichihashi, Single-shell carbon nanotubes of 1-nm diameter.[J]. Nature.1993,363:603-[2]D.S. Bethune, C. H. Kiang, M. S. de Vries, G. Gorman, R. Savoy, J. Vazquez, R. Beyers.Cobalt-catalysed growth of carbon nanotubes with single-atomic-layer walls.[J]. Nature.1993,363:605-[3]H.F. Ivey. Thermionic electron emission from carbon, Phys. Rev., 1949, 76(4), 567.[4]Y. Saito, K. Hamaguchi, T. Nishino, K. Hata, K. Tohji, A. Kasuya, Y. Nishina, Field emission patterns from single-walled carbon nanotubes. Jpn. J Appl. Phys., 1997, 36(10A), L1340-L1342.[5]Y. Saito, K. Hamaguchi, K. Hata, K. Tohji, A. Kasuya, Y. Nishina, K. Uchida, Y. Tasaka, F.Ikazaki, M. Yumura, Field emission from carbon nanotubes; purified single-walled multi-walled tubes, Ultramicroscopy, 1998, 73(1), 1-6.[6]Wall A. de Heer, A. Chatelain, D. Ugarte, A carbon nanotube field-emission electron source.[J].Science.1995,270:1170-[7]Q.H. Wang, T. D. Corrigan, J. Y. Dai, R. P. H. Chang, A. R. Krauss, Field emission from nanotube bundle emitters at low fields, Appl. Phys. Lett., 1997, 70(24), 3308-3310.[8]J.M. Bonard, J. P. Salvetat, T. Stockli, W. A. de Heer, L. Forro, A. Chatelain, Field emission from single-wall carbon nanotubefilms, Appl. Phys. Lett., 1998, 73(7), 918-920.[9]O.M. Kttel, O. Groning, Ch. Emmenegger, L. Schlapbach, Electron field emission from phase pure nanotube films grown in a methane/hydrogen plasma. Appl. Phys. Lett., 1998, 73(15),2113-2115.[10]Xueping Xu, G. R. Brandes, A method for fabricating large-area, patterned, carbon nanotubes field emitters, Appl. Phys. Lett., 1999, 74(17), 2549-2551.[11]P.G. Collins, A. Zettl, A simple and robust electron beam source from carbon nanotubes, Appl.Phys. Lett., 1996, 69(13), 1969-1971.[12]Yu. V. Gulyaev, N. I. Sinitsyn, G. V. Torgashov, Sh. T. Meviyut, A. I. Zhbanov, Yu. F.Zakharchenko, Z. Ya. Kosakovskaya, L. A. Chernozatonskii, O.E. Giukhova, I. G. Torgashov,Work fuction estimate for electrons emitted from nanotube carbon cluster films., J. Vac. Sci.Technol., 1997, B15(2), 422-424.[13]K.A. Dean, P. von Allmen, B. R. Chalamala, Three behavioral states observed in field emission from single-walled carbon nanotubes., J. Vac. Sci. Technol., 1999, B17(5), 1959-1969.[14]D. Lovall, M. Buss, E. Graugnard, R. P. Andres, R. Reifenberger, Electron emission and structural characterization of a rope of single-walled carbon nanotubes, Phys. Rev., 2000, B61(8), 5683-5691.[15]O. Groning, O. M. Kttel, P. Groning, L. Schlipbach, Field emission spectroscopy from discharge activated chemical vapor desposition diamond, J. Vac. Sci. Technol., 1999, B17(3), 1064-1071.[16]O. Groning, O. M. Kttel, Ch. Emmenegger, P. Groning, L. Schlapbach, Field emission properties of carbon nanotubes, J. Vac. Sci. Technol., 2000, B18(2), 665-678.[17]M. J. Fransen, Th. L. van Rooy, P. Kruit, Field emission energy distribution from individual multiwalled carbon nanotubes, Appl. Surf. Sci., 1999, 146, 312-327.[18]P. Chen, X. Wu, X. Sun, J. Lin, W. Ji, K. L. Tan, Electronic structure and optical limiting behavior of carbon nanotubes, Phys. Rev. Lett., 1999, 82(12), 2548-2551.[19]S. Suzuki, C. Bower, Y. Watanabe, O. Zhou, Work function and valence band states of pristine and Cs-intercalated single-walled carbon nanotube bundles, Appl. Phys. Lett., 2000, 76(26),4007-4009.[20]Vu. T. Binh, N. Garcia, S. T. Purcell, Electron field emission from atom-sources: fabrication;properties, and applications of nanotips, Adv. in Imaging and Electron Phys., 1996, 95, 63-153.[21]薛增泉,吴全德,电子发射和电子能谱,北京,北京大学出版社,1993,60-75.[22]М.И.Елинсони, Г.ф.Василъев, АвтоэлектроннаяЭмиссия,Москва, ГосударственноеИздателъствоФизико-Матема-тическойЛитературы, 1958, 70-83.[23]Z.J. Shi, Y. F. Lian, X. H. Zhou, Z. N. Gu, Y. G. Zhang, S. Iijima, L. X. Zhou, K. T. Yue, S. L.Zhang, Mass production of single-wall carbon nanotubes by arc-discharge method, Carbon, 1993,37(9), 1449-1453.
