基于光探针的超高速波形数字化测试系统的应用
APPLICATION OF ULTRA-HIGH SPEED WAVEFORM DIGITIZED SYSTEM TO IC BASED ON LASER PROBE
-
摘要: 介绍了基于光探针的超高速波形数字化系统的结构。采用倍频移相扫描法测量了高速集成电路芯片各级的功能。分析了芯片故障产生的原因和光探针测量的特点。
-
关键词:
- 光探针; 电光采佯; 集成电路芯片
Abstract: This paper introduces the construction of the ultra-high speed waveform digitized system based on laser probe. The functions of different stages of the high-speed dynamic divider circuit chip are measured with the double-frequency phase sweeping technique. A detail analysis about the chip failure and the characteristics of laser probe measurement is given. -
Kolner B H, Bloom D M. Electronic sampling in GaAs integrated circuits. IEEE J. of QE., 1986,QE-22(1): 79-93.[2]Duvillaret L, Lourtioz J M, Chusseau L. Absolute voltage measurements on Ⅲ-V integrated circuits by internal electro-optic sampling[J].Electron. Lett.1995, 31(1):23-24[3]田小建,衣茂斌,等.倍频移相扫描电光采样测量.红外与毫米波学报,1997,16(3):190-192.[4]Mitsuru S, Tadao N. An automated electro-optic probing system for ultra-high-speed ICs. IEEE Trans. on Instrum. Meas., 1994, IM-43(6): 843-847. -
