一种新的采用分布式孔径的无源雷达成像方法
doi: 10.3724/SP.J.1146.2010.00625
A Novel Passive Radar Imaging Method Using Distributed Apertures
-
摘要: 该文提出一种新的利用机会照射源的无源分布式雷达目标成像方法。首先基于波方程建立接收回波信号模型。然后建立新的无源回波模型,该模型将所有接收单元(或接收机)处的回波信号用某一基准接收单元处的接收信号来描述,无需发射源信息。基于分布式孔径获得的数据有限,成像被描述为目标位置未知的二元假设检验。采用无源回波模型,依据最大信噪比准则构造空间可分辨的检测统计量,对观测区域每个位置进行检测,最终形成关于成像区域的检测统计量图像,获知目标位置信息。在给出该成像方法分辨率的理论分析的基础上,进一步通过仿真实验验证了理论分析结果和成像方法的有效性。Abstract: A novel passive radar imaging method is presented using distributed apertures that relies on illuminators of opportunity. The measurement is modeled using the wave equation. A new passive measurement model is proposed that expresses the measurement at a receiver in terms of the measurement at a different receiver and therefore requires no information about the illumination sources. Since only a limited number of measurements are available due to sparsely and randomly distributed apertures, the imaging issue is formulated as a binary hypothesis test with unknown target location. The spatial-resolved test-statistic is determined by maximizing the SNR of the test-statistic using the proposed passive measurement model. The resulting image is formed with the test-statistics evaluated at each hypothetical target location, which can provide the information about the target location. The resolution analysis of the imaging method is presented and numerical simulations are conducted to verify its performance and validate the theoretical findings.
-
Key words:
- Passive radar /
- Distributed aperture /
- Illuminator of opportunity /
- Imaging /
- Wave equation
-
Griffiths H D and Baker C J. Passive coherent location radar systemsPart 1: performance prediction [J].. IEE Proceedings of Radar Sonar Navigation.2005, 152(3):153-159[2]Baker C J, Griffiths H D, and Papoutsis I. Passive coherent location radar systemsPart 2: waveform properties [J].. IEE Proceedings of Radar Sonar Navigation.2005, 152(3):160-168[3]Howland P E, Maksimiuk D, and Reitsma G. Fm radio based bistatic radar [J].IEE Proceedings of Radar Sonar Navigation.2005, 152(3):107-115[4]Poullin D. Passive detection using digital broadcasters (DAB, DVB) with COFDM modulations [J].IEE Proceedings of Radar Sonar Navigation.2005, 152(3):143-152[5]Tan D, Sun H, Lu Y, Lesturgie M, and Chan H. Passive radar using global system for mobile communication signal: theory, Implementation and measurements [J].IEE Proceedings of Radar Sonar Navigation.2005, 152(3):116-123[6]Coleman C and Yardley H. Passive bistatic radar based on target illuminations by digital audio broadcasting [J].IET Radar Sonar Navigation.2008, 2(5):366-375[11]Yarman C E and Yazici B. Synthetic aperture hitchhiker imaging [J].IEEE Transactions on Imaging Processing.2008, 17(11):2156-2173[12]Yarman C E, Wang L, and Yazici B. Doppler synthetic aperture hitchhiker imaging [J].Inverse Problems.2010, 26(6):065006-[13]王大海, 王俊. 单发多收模式下无源雷达成像研究[J].电子学报.2006, 34(6):1138-1141[15]李岩, 王俊, 张守宏. 基于外辐射源的ESPRIT超分辨成像算法 [J].电子与信息学报.2009, 31(1):143-146浏览[16]吴海洲, 陶然, 单涛. 基于DTTB照射源的无源雷达直达波干扰抑制[J].电子与信息学报.2009, 31(9):2033-2038浏览 期刊类型引用(9)
