条带FMCW-SAR回波数据的二维频域模拟算法

马兵强; 于彬彬; 刘畅; 王岩飞

doi:10.3724/SP.J.1146.2010.00430

条带FMCW-SAR回波数据的二维频域模拟算法

doi: 10.3724/SP.J.1146.2010.00430

马兵强^{*①② 于彬彬,},
于彬彬,
刘畅,
王岩飞

计量
- 文章访问数: 3763
- HTML全文浏览量: 103
- PDF下载量: 817
- 被引次数: 0
出版历程
- 收稿日期: 2010-04-29
- 修回日期: 2010-07-28
- 刊出日期: 2011-02-19

A 2-D Fourier Domain Algorithm for StripMap FMCW-SAR Raw Signal Simulation

Ma Bing-Qiang^{*①② 于彬彬
,},
Yu Bin-Bin,
Liu Chang,
Wang Yan-Fei

摘要

摘要: FMCW-SAR因其体积小、重量轻、成本低和高分辨率等优点近年来发展迅速，在低成本的民事应用领域具有广阔的发展前景。传统脉冲SAR的系统冲击响应函数不同于FMCW-SAR，因而，脉冲SAR的快速回波模拟算法不能直接应用于FMCW-SAR。该文在分析了条带FMCW-SAR信号特性的基础上，提出了其原始回波数据的2维频域快速模拟算法。该算法利用FFT快速实现了回波数据时域模拟方法中的距离向和方位向积分运算。与时域模拟方法相比，其计算效率提高了O(NaNr/log2(NaNr))个数量级。点目标回波数据的仿真实验验证了所提算法的合理性和有效性。
- 调频连续波合成孔径雷达(FMCW-SAR) /
- 回波数据模拟 /
- 2维频域
Abstract: Because of small size, lightweight, inexpensive and high-resolution, recently FMCW-SAR develops rapidly and has a great prospect in the cost-effective civil applications. The system transfer function of StripMap FMCW-SAR is different from that of pulsed SAR, therefore the efficient simulation approaches for pulsed SAR could not directly be applied to FMCW-SAR. Based on the analysis of the StripMap FMCW-SAR signal characteristics, a 2-D Fourier domain algorithm of the raw signal simulation for stripmap FMCW-SAR is proposed. The proposed algorithm computes the range and azimuth integration used in time-domain simulation method efficiently by FFT technique. With respect to the time-domain simulation, the computational load is reduced by the order of O(NaNr/log2(NaNr)). The rationality and effectiveness of the presented algorithm are verified with the simulation.
- Frequency Modulated Continuous Wave SAR (FMCW-SAR) /
- Echo data simulation /
- 2-Dimesional Fourier domain

HTML全文

参考文献(1)

韦立登, 李绍恩, 吴一戎, 向茂生. SAR原始回波信号生成算法的性能比较研究[J].电子与信息学报.2005, 27(2):262-265浏览Wei Li-deng, Li Shao-en, Wu Yi-rong, and Xiang Mao-sheng. Performance comparison of algorithms for SAR raw signal generation[J].Journal of Electronics Information Technology.2005, 27(2):262-265[2]Cimmino S, Franceschetti G, Iodice A, Riccio D, and Ruello G. Efficient spotlight SAR raw signal simulation of extended scenes[J].IEEE Transactions on Geoscience and Remote Sensing.2003, 41(10):2329-2337[3]Franceschetti G, Guida R, Iodice A, Riccio D, and Ruello G. Efficient Simulation of hybrid stripmap/spotlight SAR raw signals from extended scenes[J].IEEE Transactions on Geoscience and Remote Sensing.2004, 42(11):2385-2396[4]Franceschetti G, Iodice A, Perna S, and Riccio D. Efficient simulation of airborne SAR raw data of extended scenes[J].IEEE Transactions on Geoscience and Remote Sensing.2006, 44(10):2851-2860[5]Meta A, Hoogeboom P, and Ligthart L P. Signal processing for FMCW SAR[J].IEEE Transactions on Geoscience and Remote Sensing.2007, 45(11):3519-3532[6]Zaugg E C and Long D G. Theory and application of motion compensation for LFM-CW SAR[J].IEEE Transactions on Geoscience and Remote Sensing.2008, 46(10):2990-2998[7]Jiang Z H and Huang-Fu K. Squint LFMCW SAR Data processing using doppler-centroid-dependent frequency scaling algorithm[J].IEEE Transactions on Geoscience and Remote Sensing.2008, 46(11):3535-3543[8]Meta A, Hoogeboom P, and Ligthart L P. Correction of the effects induced by the continuous motion in airborne FMCW SAR[C]. IEEE Radar Conference. Verona, New York, 2006: 358-365.[9]张大炜, 魏芳, 王岩飞. 多普勒效应对FMCW-SAR系统成像性能的影响分析[J].电子与信息学报.2008, 30(3):559-563浏览Zhang Da-wei, Wei Fang, and Wang Yan-fei. Analysis of the Doppler effect in FMCW-SAR and its influence on the image of the system[J].Journal of Electronics Information Technology.2008, 30(3):559-563[10]Carrara W G, Goodman R S, and Majewdki R M. Spotlight Synthetic Aperture Radar Signal Processing Algorithms[M]. Boston: Artech House, 1995: 501-505.[11]Cumming I G and Wong F H. Digital Processing of Synthetic Aperture Radar Data: Algorithms and Implementation[M]. Norwood: Artech House, 2005: 98-103.[12]Wang R, Loffeld O, Nies H, Knedlik S, Hagelen M, and Essen H. Focus FMCW SAR data using the wavenumber domain algorithm[J].IEEE Transactions on Geoscience and Remote Sensing.2010, 48(4):2109-2118
