一种宽带速调管中高次模式振荡的抑制

张志强; 王勇; 罗积润; 丁耀根

doi:10.3724/SP.J.1146.2009.00149

一种宽带速调管中高次模式振荡的抑制

doi: 10.3724/SP.J.1146.2009.00149

计量
- 文章访问数: 3569
- HTML全文浏览量: 137
- PDF下载量: 828
- 被引次数: 0
出版历程
- 收稿日期: 2009-02-05
- 修回日期: 2009-07-14
- 刊出日期: 2010-03-19

Suppression of High Order Mode Oscillation in a Broadband Klystron

摘要

摘要: 该文描述了在一种S波段宽带速调管研制过程中出现的高次模式振荡现象，分析了抑制这种振荡的可能方式，提出了一种抑制这种振荡的方法。该方法通过改变谐振腔结构，在基本不影响基模频率的前提下，使高次模式频率产生较大的改变，从而使该高次模式的振荡得到抑制。利用Ansoft HFSS模拟设计软件，对谐振腔进行了改进设计并完成了相应的实验验证。利用改进设计的谐振腔，进行了速调管整管试验，有效地抑制了速调管中高次模式的振荡。
- 宽带速调管; 高次模式振荡; 振荡抑制
Abstract: The phenomena of a high order mode oscillation in a broadband klystron are described in this paper. Some methods are discussed for suppressing parasitical mode oscillation in klystron resonant cavity. One new method is used to eliminate the oscillation in the broadband klystron. The method can make the high order mode frequency change enormously but the fundamental mode frequency alter faintly through adjust the structure of a resonant cavity, thereby the high order mode oscillation is suppressed. An improved design for resonant cavity with Ansoft HFSS code and corresponding experimental approval has been performed. The testing result of the klystron with the improved resonant cavity shows that the high order mode oscillation can effectively be suppressed.

HTML全文

参考文献(1)

Wang Yong, Xie Jing-xin, Ding Yao-gen, and Liu Pu-kun.Development of an S-band 50MW klystron. Eighth IEEEInternational Vacuum Electronics Conference, Kitakyushu,Japan, 2007: 153-154.[2]Becker U, Krietenstein B, Weiland T, Dohlus M, and Ko K.Simulation of Oscillations in High Power Klystrons.Proceeding of European Particle Accelerator Conference,Barcelona, 1996: 1274-1275.[3]丁耀根. 大功率速调管中寄生振荡问题的实验研究. 电子科学学刊, 1992, 14(4): 409-415.Ding Yao-gen. Experimental studies of parasitical oscillationsin high power klystron. Journal of Electronics, 1992, 14(4):409-415.[4]张瑞, 王勇. TM610 高次模圆柱谐振腔的模拟研究. 强激光与粒子束, 2006, 18(7): 1129-1133.Zhang Rui and Wang Yong. Simulation of TM610 higher-ordermode cylindrical cavity. High Power Laser and ParticleBeams, 2006, 18(7): 1129-1133.[5]周祖圣, 董东, 王书鸿. 国产45MW速调管实验研究. 原子能科学技术, 2008, 42(5): 398-399.Zhou Zu-sheng, Dong Dong, and Wang Shu-hong.Experimental studies on 45MW high power klystron. AtomicEnergy Science and Technology, 2008, 42(5): 398-399.[6]把慧荣, 张兆传. TM020 模多注速调管圆柱谐振腔的仿真设计. 电子器件, 2008, 31(5): 1647-1649.Ba Hui-rong and Zhang Zhao-chuan. Design and simulation ofTM020 mode multi-beam klystron cylindrical cavity. ChineseJournal of Electron Devices, 2008, 31(5): 1647-1649.[7]曹静, 丁耀根, 沈斌. TM310 模的同轴谐振腔与波导孔耦合及场分布研究[J].电子与信息学报.2008, 30(6):1521-1524浏览[8]董玉和, 丁耀根, 肖刘. 同轴谐振腔高阶横磁模式参数的研究.物理学报, 2005, 54(12): 5629-5630.Dong Yu-he, Ding Yao-gen, and Xiao Liu. Research onparameters of higher-order transverse magnetic modes incylindrical coaxial cavity resonator. Acta Physica Sinica, 2005,54(12): 5629-5630.
