标准数字工艺下16位精度低压低功耗模数调制器设计
doi: 10.3724/SP.J.1146.2009.00116
Design of 16 bit Low-Voltage Low-Power Modulator with Standard Digital Technology
-
摘要: 针对输入信号频率在20 Hz～24 kHz范围的音频应用，该文采用标准数字工艺设计了一个1.2 V电源电压16位精度的低压低功耗模数调制器。在6 MHz采样频率下，该调制器信噪比为102.2 dB，整个电路功耗为2.46 mW。该调制器采用一种伪两级交互控制的双输入运算放大器构成各级积分器，在低电源电压情况下实现高摆率高增益要求的同时不会产生更多功耗。另外，采用高线性度、全互补MOS耗尽电容作为采样、积分电容使得整个电路可以采用标准数字工艺实现，从而提高电路的工艺兼容性、降低电路成本。与近期报道的低压低功耗模数调制器相比，该设计具有更高的品质因子FOM。Abstract: For audio signals with input frequency between 20 Hz and 24 kHz, a switch-capacitor feed-forward A/D modulator in 0.18m Logic technology is proposed in this paper, which gains 16 bit resolution with 1.2 V supply voltage. The modulator can achieve 102.2 dB signal-to-noise ratio (SNR) under 6MHz sample clock, and the total power dissipation is only 2.46 mW. In the modulator, a pseudo-two-stage Class-AB transconductance amplifier is used, which has high slew rate and open loop gain while without increasing power dissipation. What is more, full compensated depletion-mode capacitors are used as sample capacitors and integrating capacitors to enable the whole chip to be fabricated in standard digital technology, which is good to reduce chip cost and improve the modulators compatibility in technology. Compared with other low-power low-voltage A/D modulators reported, this design has better FOM (Figure Of Merit).
-
Yao Libin. Low-power low-voltage sigma-delta modulators in nanometer CMOS [D]. Catholic University Leuven, Belgium, 2006.[2]Jeongjin R. High-Gain Class-AB OTA with Low Quiescent[3]Current [J]. Analogous Circuit and Signal Processing, 2006, 47(2): 225-228.[4]David Baez-Villegas and Jose Silva-Martinez. Quasi rail-to- rail very low-voltage opamp with a single pMOS input differential pair [J].IEEE Transactions on Circuits and SystemsII: Express Briefs.2006, 53(11):1175-1179[5]Juan M, Carrillo, and Guido Torelli. 1-V rail-to-rail CMOS opamp with improved bulk-driven input stage [J].IEEE Journal of Solid-State Circuits.2007, 42(3):508-517[6]Yin Shujuan and Sun Yihe. Full compensated depletion-mode MOS-capacitor for pure digital technology low voltage switched-capacitor applications [C]. IEEE International Conference on Electron Devices and Solid-State Circuits. Taiwan, Dec. 2007: 913-916.[7]Goes J and Vaz B. A 0.9 V modulator with 80 dB SNDR and 83 dB DR using a single-phase technique [C]. IEEE ISSCC Dig. Tech. San Francisco, 2006: 74-75.[8]Roh J and Byun S. A 0.9 V 60 W 1 bit fourth-order delta-sigma modulator with 83-dB dynamic range [J]. IEEE Journal of Solid-state Circuits, 2008, 43(2): 225-228. -
