离散复镜像方法中的积分路径与展开函数的研究
doi: 10.3724/SP.J.1146.2007.00394
On the Integration Path and Expansion Function of the Discrete Complex Image Method
-
摘要: 该文分析了二级离散复镜像方法中的积分路径与展开函数，给出了正确的展开函数，提出了一种新的积分路径，可以用来快速计算微带结构的空间域格林函数。采用该方法计算了一个5层微带结构的空间域格林函数，证实了本文方法的有效性。
-
关键词:
Abstract: The integration paths and the expansion functions in two-level DCIM are investigated. Accurate expansion functions are proposed and a novel integration path, which can be used to calculate the spatial Greens functions of microstrip structure, is presented. The spatial Greens functions of a five-layer microstrip structure are calculated, and the results show the effectiveness of the proposed method. -
哈林登著. 王尔杰译. 计算电磁场的矩量法. 北京：国防工业出版社, 1981, 第1~3章.[2]Chow Y L, Yang J J, Fang D F, and Howard G E. A closed-form spatial Greens function for the thick substrate[J].IEEE Trans. on Microwave Theory Tech.1991, 39(3):588-[3]Aksun M I. A robust approach for the derivation of closed-form Greens function[J].IEEE Trans. on Microwave Theory Tech.1996, 44(5):651-658[4]Chew W C. Waves and Fields in Inhomogeneous Media[M]. Van Nostrand, New York, 1990, Chapter1-3.[5]Shuley N V and Boix R R. On the fast approximation of Greens functions in MPIE formulations for planar layered media[J].IEEE Trans. on MTT.2002, 50(9):2185-2192[6]Liu Y. Application of DCIM to MPIE-MOM analysis of 3-D PEC objects in multilayered media[J].IEEE Trans. on Antennas and Propagation.2002, 50(2):157-161[7]Hsu C I G, Harrington R F, Michalski K A, and Zheng D. Analysis of a multiconductor transmission line of arbitrary cross-section in multilayered uniaxial media[J].IEEE Trans. on Microwave Theory Tech.1993, 41(1):70-78[8]Hua Y and Sarkar T K. Generalized pencil-of-function method for extracting poles of an EM system from its transient response[J].IEEE Trans. on Antennas and Propagation.1989, 37(2):229-234[9]Katehi P B and Alexopoulos N G. Real axis integration of sommerfeld integrals with applications to printed circuit antennas[J].J. Math. Phys.1983, 24(3):527-533 -
