修正Gram-Schmidt正交化构建电源分配网络时域宏模型
doi: 10.3724/SP.J.1146.2006.00486
Construction of Macromodel in Time Domain for Power Distribution Network Using Modified Gram-Schmidt Orthogonal
-
摘要: 有理函数逼近法方程组病态条件数为构建电源分配网络时域宏模型带来了数值问题。该文提出利用修正Gram-Schmidt正交化处理对超定方程组系数矩阵进行正交三角分解，结合Bernoulli多项式求根方法及稳定、无源性准则可以精确构建无源时域宏模型。计算实例精确构建了自DC至1GHz频带内的宽带无源时域宏模型，从而验证了该方法的有效性。Abstract: The ill-conditioned normal equations bring numerical problems in construction of macromodel in time domain for power distribution networking using rational function approximation. This paper presents the superdefinite equations coefficient matrix can be decomposed in QR form using modified Gram-Schmidt orthogonal and the accurate passive macromodel in time domain can be constructed based on Bernoulli polynomial root finding method and the formulae for stability and passivity. Finally, a broadband passive macromodel constructed from DC to 1GHz is given to demonstrate the validity and accuracy of the method.
-
Choi J, Min S H, and Kim J H. Modeling and analysis of power distribution networks for gigabit applications[J].IEEE Trans. on Mobile Computing.2003, 2(4):299-313[2]Beyene W T. Improving time-domain measurements with a network analyzer using a robust rational interpolation technique[J].IEEE Trans. on Microwave Theory and Techniques.2001, 49(3):500-508[3]Gustavsen B and Semlyen A. Enforcing passivity for admittance matrices approximated by rational functions[J].IEEE Trans. on Power Systems.2001, 16(1):97-104[4]Beyene W T and Schutt-Aine J E. Efficient transient simulation of high-speed interconnects characterized by sampled data[J].IEEE Trans. on Components, Packaging and Manufacturing Technology-Part B.1998, 21(1):105-114[5]Min S H and Swaminathan M. Construction of broadband passive macromodels from frequency data for simulation of interconnect networks. Proceedings of the 15th Intl Zurich Symp and Technical Exhibition on Electromagnetic Compatibility, Zurich, 2003: 299-313.[6]Kim J H, Matoglu E, Choi J, and Swaminathan M. Modeling of multi-layered power distribution planes including via effects using transmission matrix method. Proceedings of the 15th International Conference on VLSI Design, Bangalore, 2002: 59-64.[7]Choi K L and Swaminathan M. Development of model libraries of embedded passives using network synthesis[J].IEEE Trans. on Analog and Digital Signal Processing.2000, 47(4):249-260[8]蒋长锦. 科学计算和C程序集. 合肥: 中国科学技术大学出版社, 1998: 198-204. -
