双站合成孔径声纳系统原理研究
doi: 10.3724/SP.J.1146.2005.00827
Research on Principle of the Bistatic Synthetic Aperture Sonar
-
摘要: 该文建立了发射站固定的双站合成孔径声纳模型，并对其分辨特性等原理进行了分析和研究，得到了距离分辨力 、脉冲重复频率以及测绘速率严格的数学解，同时给出了有关计算机仿真。仿真结果验证了理论分析的正确性，表明了双站合成孔径声纳成像方法可行、有效。Abstract: Firstly, a Bistatic Synthetic Aperture Sonar (Bi-SAS) configuration with fixed transmitter is given in this paper, and then the azimuth and range resolution, the Pulse Repetition Frequency (PRF) and the mapping rate of the Bistatic-SAS are studied in detail. The analytical solutions are obtained, consequently, the computer simulation are presented in the end. The simulation results validate the correctness of the theory and show the validity of the method in the Bistatic-SAS image.
-
[1] Hayes M P and Gough P T. Broad-band synthetic aperture sonar[J].IEEE Journal of Oceanic Engineering.1992, 17(1):80-94 [2] McHugh R, Shaw S, and Taylor N. Efficient digital signal processing algorithm for sonar imaging[J].IEE Proc.-Radar, Sonar Navigation.1996, 143(3):149-156 [3] Edwards J R and Schmidt H, et al.. Bistatic synthetic aperture target detection and imaging with an AUV[J].IEEE Journal of Oceanic Engineering.2001, 26(4):690-691 [4] LePage K D and Schmidt H. Bistatic synthetic aperture imaging of proud and buried targets from an AUV[J].IEEE Journal of Oceanic Engineering.2002, 27(3):471-476 [5] 赵俊渭, 丁玮, 阎宜生等.收发分置水下目标声散射特性的实验研究. 声学学报, 1997, 22(2): 124-131. [6] 张小凤, 赵俊渭, 王荣庆等.双基地声呐散射声场的建模与仿真. 系统仿真学报, 2002, 14(5): 562-565. [7] 汤子跃, 张守融. 双站合成孔径雷达系统原理. 北京: 科学出版社, 2003: 27-28. [8] 吕彤光, 陆仲良, 粟毅等. 冲激信号SAR成像的方位分辨率分析. 电子学报, 2000, 28(6): 40-43. -
