基于最小全变差的SAR图像自聚焦算法
doi: 10.3724/SP.J.1146.2005.00649
Minimum Total Variation Autofocus Algorithm for SAR Imaging
-
摘要: 该文分析了方位一维图像的全变差范数随二次相位误差的变化情况，得到全变差范数是二次相位误差的单峰函数的结论，且在二次相位误差等于零时全变差范数最小。从而利用全变差范数作为性能函数，采用黄金分割最优化算法，通过循环迭代得到自聚焦的SAR图像。实验结果表明此算法在处理二次相位误差时优于相位梯度自聚焦算法。通过算法复杂度的分析表明该算法的计算量约为相位梯度自聚焦的二分之一。
-
关键词:
- 合成孔径雷达;相位误差;自聚焦;全变差
Abstract: Minimum Total Variation Autofocus (MTVA) algorithm for SAR imaging is studied. Firstly, the relationship between total variation of SAR image and 2nd-order phase error is analyzed. The results show that total variation is a single peak function of 2nd-order phase error. Total variation reaches minimum when zero phase error. Then total variation norm is used as performance function. Golden selection method is adopted to get focused SAR image. Finally, experimental results show that MTVA algorithm has good performance and is better than Phase Gradient Autofocus (PGA) algorithm. Study of complexity shows that MTVAs computation amount is nearly half of PGAs. -
[1] Wahl D E, Eichel E H, and Ghiglia D C, et al.. Phase gradient autofocusA robust tool for high resolution SAR phase correction, IEEE Trans[J].on Aerospace and Electronic Systems.1994, 30(3):827-835 [2] Eichel P H and Jakowatz C V. Phase-gradient algorithm as an optimal estimator of the phase derivative[J].Optics Letters.1989, 14(20):1101-1103 [3] 刘月花, 荆麟角. 对比度最优自聚焦算法[J].电子与信息学报.2003, 25(1):24-30浏览 [4] 张澄波. 综合孔径雷达原理、系统分析与应用. 北京: 科学出版社, 1989: 163-177. [5] Mallat Stephane. A Wavelet Tour of Signal Processing, Second Edition. Academic Press. 1999: 24-25 [6] 《数学手册》编写组. 数学手册, 北京: 高等教育出版社, 1979: 923-925. -
