CLIP视觉语义驱动的图像去雨模型

孙瑾; 崔云通; 田宏伟; 黄长城; 汪纪钢

doi:10.11999/JEIT251066

CLIP视觉语义驱动的图像去雨模型

doi: 10.11999/JEIT251066 cstr: 32379.14.JEIT251066

南京航空航天大学民航学院南京 211106

基金项目: 国家自然科学基金(61702260)

详细信息

作者简介:
孙瑾：女，副教授，研究方向为计算机视觉，图像处理与分析

崔云通：男，硕士生，研究方向为图像增强与复原

田宏伟：男，硕士生，研究方向为图像处理与分析，目标跟踪

黄长城：男，硕士生，研究方向为图像增强与复原

汪纪钢：男，硕士生，研究方向为图像增强与复原

通讯作者:
孙瑾　sunjinly@nuaa.edu.cn

中图分类号: TP391.4
计量
- 文章访问数: 54
- HTML全文浏览量: 35
- PDF下载量: 2
- 被引次数: 0
出版历程
- 收稿日期: 2025-10-09
- 修回日期: 2026-02-05
- 录用日期: 2026-02-05
- 网络出版日期: 2026-02-13

Image Deraining Driven by CLIP Visual Embedding

College of Civil Aviation, Nanjing University of Aeronautics and Astronautics, Nanjing 211106, China

Funds: National Natural Science Foundation of China (61702260)

摘要

摘要: 图像去雨是计算机视觉领域的基础任务，现有方法过度依赖假设雨模型或合成雨数据集，导致真实场景去雨效果泛化性能不足。该文分析发现CLIP模型图像编码器对雨纹干扰的鲁棒性，将去雨任务转化为基于视觉语义引导的像素级回归问题，提出基于冻结对比语言-图像预训练(Frozen Contrastive Language–Image Pretraining, FCLIP)策略的图像去雨模型FCLIP-UNet。该模型采用对称的编码器解码器结构(U-Net)：编码器截取CLIP-RN50图像编码器的4层结构实现雨纹与图像内容语义的自动解耦；解码阶段采用ConvNeXt-T与UpDWBlock串行结构，结合跳跃连接中嵌入层级差异化扰动策略实现高层语义引导下的细节恢复与泛化能力的协同增强。定量和定性实验结果表明，FCLIP-UNet在公开合成数据集和真实雨图数据集上均取得最优或具有竞争力的性能，并在包含真实雨图的多个独立数据集上表现出良好的泛化性能。
- 图像去雨 /
- CLIP /
- 卷积神经网络(CNN) /
- U-Net /
- 泛化性能
Abstract: Objective Rain streaks introduce visual distortions that degrade image quality, which significantly impairs the performance of downstream vision tasks such as feature extraction and object detection. This work addresses the problem of single-image rain streak removal. Existing methods often rely heavily on restrictive priors or synthetic datasets, resulting in limited robustness and generalization capabilities due to the discrepancy with complex, unstructured real-world scenarios. CLIP demonstrates remarkable zero-shot generalization capabilities through large-scale image-text cross-modal contrastive learning. Motivated by this, we propose FCLIP-UNet, a visual-semantic-driven deraining architecture, for enhanced rain removal and improved generalization in real-world rainy environments. Methods FCLIP-UNet adopts the U-Net encoder-decoder architecture and reformulates deraining as pixel-level detail regression guided by high-level semantic features. In the encoding stage, dispensing with textual queries, FCLIP-UNet employs the first four layers of the frozen CLIP-RN50 to extract robust features decoupled from rain distribution, leveraging their semantic representation capacity to suppress diverse rain patterns. To guide image restoration accurately, we adopt a collaborative architecture of ConvNeXt-T and UpDWBlock at the decoding stage. The decoder utilizes ConvNeXt-T, replacing the traditional convolutional modules, to expand the receptive field for capturing global contextual information, and it parses rain streak patterns by leveraging the semantic priors extracted from the encoder. Under the constraint of such semantic priors, UpDWBlock reduces the information loss caused by upsampling and reconstructs fine-grained image details. Multi-level skip connections are employed to compensate for the information loss incurred in the encoding stage, and a layer-wise differentiated feature perturbation strategy is embedded to further enhance the model’s robustness and adaptability in complex real-world rainy scenarios. Results and Discussions Comprehensive evaluations are conducted on the Rain13K composite dataset by benchmarking the proposed model against ten state-of-the-art deraining algorithms. FCLIP-UNet demonstrates consistently superior performance across all five testing subsets of Rain13K. Notably, FCLIP-UNet outperformed the second-best method on both datasets: on Test100 by 0.32 dB (PSNR) and 0.06 (SSIM); on Test2800 by 0.14 dB and 0.002. On Rain100H and Rain100L, FCLIP-UNet achieved competitive results, with the best SSIM on Rain100H and comparable performance on other metrics. (Table 3). To evaluate model generalization, the Rain13K-pretrained FCLIP-UNet was quantitatively evaluated on three datasets with distinct rainfall distribution characteristics: SPA-Data, HQ-RAIN, and MPID (Table 4, Fig. 7). Qualitative and quantitative assessments were also conducted using the real-world NTURain-R dataset (Table 5, Figs. 8–10). Both results consistently demonstrated FCLIP-UNet's robust generalization capability. Ablation experiments on Rain100H validate the proposed encoder architecture and the effectiveness of both the UpDWBlock and LDFPS (Tables 6-8). Furthermore, ablation results demonstrated that employing LDFPS, combined with a 1:1 weighting ratio between L₁ loss and perceptual loss, yielded optimal performance of FCLIP-UNet (Tables 9-11). Conclusions This work introduces FCLIP-UNet, a deraining network targeting real-world generalization, by leveraging the contrastive language–image pre-training (CLIP) paradigm. The main contributions are threefold. First, image deraining is reformulated as a pixel-level regression task aimed at reconstructing rain-free images based on high-level semantic features; a frozen CLIP image encoder is employed to extract representations robust to rain-distribution variations, thereby mitigating domain shifts induced by diverse rain models. Second, a decoder integrating ConvNeXt-T with an upsampling depthwise convolution block (UpDWBlock) is designed, and a layer-wise differentiated feature perturbation strategy (LDFPS) is introduced to enhance robustness against unseen rain distributions. Third, a composite loss function is constructed to jointly optimize pixel-wise accuracy and perceptual consistency. Quantitative and qualitative experiments on both synthetic and real-world rainy datasets demonstrate that FCLIP-UNet effectively removes rain streaks while preserving fine image details and exhibits superior deraining performance and strong generalization capability.
- Image deraining /
- CLIP /
- Convolutional neural network (CNN) /
- U-Net /
- Generalization performance

HTML全文

图 1 FCLIP-UNet网络结构

下载: 全尺寸图片幻灯片

图 2 图像语义特征与文本相似度(热力图)及分类概率(柱状图)

下载: 全尺寸图片幻灯片

图 3 不同密度雨纹下5种CLIP ResNet编码器提取特征分析

下载: 全尺寸图片幻灯片

图 4 解码器结构

下载: 全尺寸图片幻灯片

图 5 Test2800测试数据集图例去雨效果

下载: 全尺寸图片幻灯片

图 6 Test1200测试数据集图例去雨效果

下载: 全尺寸图片幻灯片

图 7 不同方法在多数据集的泛化能力比较

下载: 全尺寸图片幻灯片

图 8 真实雨图实例一去雨结果

下载: 全尺寸图片幻灯片

图 10 真实雨图实例三去雨结果

下载: 全尺寸图片幻灯片

图 9 真实雨图实例二去雨结果

下载: 全尺寸图片幻灯片

表 1 Test1200数据集图像与细粒度文本标签匹配情况

图像	文本标签
图像	light rain	moderate rain	heavy rain
低密度雨纹图像	196	97	107
中等密度雨纹图像	68	188	144
高密度雨纹图像	95	157	148

下载: 导出CSV

表 2 Rain13K数据集组成

数据集来源	Rain800	Rain100H	Rain100L	Rain14000	Rain1200	Rain12	总计
训练样本数	700	1800	0	11200	0	12	13712
测试样本数	100	100	100	2800	1200	0	4300
测试集名称	Test100	Rain100H	Rain100L	Test2800	Test1200	-	-

下载: 导出CSV

表 3 Rain13K 数据集上对比实验结果

算法	Test100		Rain100H		Rain100L		Test2800		Test1200		Average
算法	PSNR	SSIM	PSNR	SSIM	PSNR	SSIM	PSNR	SSIM	PSNR	SSIM	PSNR	SSIM
DerainNet^[4]	22.77	0.810	14.92	0.592	27.03	0.884	24.31	0.861	23.38	0.835	22.48	0.796
DID-MDN^[24]	22.56	0.818	17.35	0.524	25.23	0.741	28.13	0.867	29.95	0.901	24.58	0.770
RESCAN^[26]	25.00	0.835	26.36	0.785	29.80	0.881	31.29	0.904	30.51	0.882	28.59	0.857
MSPFN^[27]	27.50	0.876	28.66	0.860	32.40	0.933	32.82	0.930	32.39	0.916	30.75	0.903
MPRNet^[21]	30.27	0.897	30.41	0.890	36.40	0.965	33.64	0.938	32.91	0.916	32.73	0.921
Uformer-B^[28]	29.90	0.906	30.31	0.900	36.86	0.972	33.53	0.939	29.45	0.903	32.01	0.924
IDT^[11]	29.69	0.905	29.95	0.898	37.01	0.971	33.38	0.937	31.38	0.908	32.28	0.924
DCTR^[29]	30.91	0.912	30.74	0.892	38.19	0.974	33.89	0.941	33.57	0.926	33.46	0.929
AFENet^[30]	30.51	0.918	31.22	0.901	37.66	0.978	33.13	0.925	33.82	0.944	33.27	0.933
DPCNet^[31]	30.59	0.914	30.73	0.899	37.96	0.974	33.23	0.928	33.87	0.941	33.28	0.931
FCLIP-UNet(Ours)	31.23	0.924	30.82	0.903	38.06	0.972	34.03	0.943	33.27	0.928	33.48	0.934
注：加粗字体为每列最优值，下划线为每列次优值(本文其他表格设置相同)。

下载: 导出CSV

表 4 跨数据集上的对比实验结果

算法	SPA-Data		HQ-RAIN		MPID
算法	PSNR	SSIM	PSNR	SSIM	PSNR	SSIM
DID-MDN	31.12	0.937	23.62	0.640	23.09	0.794
RESCAN	34.57	0.958	23.79	0.519	26.74	0.823
MSPFN	34.55	0.961	23.99	0.572	27.48	0.849
MPRNet	35.16	0.954	26.36	0.681	31.53	0.896
Uformer-B	35.03	0.948	26.67	0.685	31.47	0.893
IDT	35.61	0.957	26.88	0.679	31.63	0.899
DCTR	35.87	0.963	27.33	0.684	31.81	0.905
DPCNet	35.64	0.958	28.56	0.786	31.59	0.894
FCLIP-UNet(Ours)	36.39	0.967	30.36	0.858	31.96	0.913

下载: 导出CSV

表 5 NTURain-R上无参考图像质量评价指标对比结果

算法	Input	DerainNet	DID-MDN	RESCAN	MSPFN	MPRNet	Uformer-B	IDT	DCTR	DPCNet	Ours
NIQE	6.211	6.432	5.988	5.745	4.873	4.834	4.473	4.352	4.533	4.378	4.286
BRISQUE	33.156	31.167	30.896	31.766	29.866	30.651	28.768	27.378	26.245	26.509	25.676

下载: 导出CSV

表 6 CLIP不同编码器Rain100H上消融实验结果

编码器	PSNR/dB	SSIM
ResNet50	16.53	0.546
CLIP-ViT-B/32	29.78	0.878
CLIP-ViT-B/16	30.25	0.885
CLIP-RN50	30.82	0.903

下载: 导出CSV

表 7 CLIP不同编码器FLOPs和推理速度对比

CLIP编码器	RN50	ViT-B/32	ViT-B/16
FLOPs	2.36×10¹⁰	2.43×10¹¹	9.76×10¹¹
推理速度(s/frame)	0.23	0.56	1.06

下载: 导出CSV

表 8 Rain100H消融实验结果

网络	UpDWBlock	LDFPS	PSNR/dB	SSIM
N1	-	-	30.02	0.879
N2	√	-	30.42	0.893
N3	-	√	30.29	0.887
N4	√	√	30.82	0.903

下载: 导出CSV

表 9 不同损失函数的消融实验

损失函数	L_mse	L₁	L_mse+L_p	L₁+L_p
PSNR/dB	29.44	29.76	29.39	30.82
SSIM	0.880	0.892	0.885	0.903

下载: 导出CSV

表 10 不同λ_p取值的消融实验

λ_p	0.1	1	10
PSNR/dB	29.51	30.82	29.66
SSIM	0.884	0.903	0.887

下载: 导出CSV

表 11 不同强度(σ_i)扰动策略消融实验

不同扰动策略	PSNR/dB	SSIM
等强度低扰动(σ₁=σ₂=σ₃=σ₄=0.01)	30.63	0.892
等强度高扰动(σ₁=σ₂=σ₃=σ₄=0.1)	30.58	0.887
扰动强度逐层降低 (σ₁=0.1, σ₂=0.06, σ₃=0.03, σ₄=0.01)	30.11	0.880
扰动强度逐层增加 (σ₁=0.01, σ₂=0.03, σ₃=0.06, σ₄=0.1)	30.82	0.903

下载: 导出CSV
