采用自适应预筛选的遥感图像目标开集检测研究

党思航 李晓哲 夏召强 蒋晓悦 桂术亮 冯晓毅

党思航, 李晓哲, 夏召强, 蒋晓悦, 桂术亮, 冯晓毅. 采用自适应预筛选的遥感图像目标开集检测研究[J]. 电子与信息学报. doi: 10.11999/JEIT231426
引用本文: 党思航, 李晓哲, 夏召强, 蒋晓悦, 桂术亮, 冯晓毅. 采用自适应预筛选的遥感图像目标开集检测研究[J]. 电子与信息学报. doi: 10.11999/JEIT231426
DANG Sihang, LI Xiaozhe, XIA Zhaoqiang, JIANG Xiaoyue, GUI Shuliang, FENG Xiaoyi. Research on Open-Set Object Detection in Remote Sensing Images Based on Adaptive Pre-Screening[J]. Journal of Electronics & Information Technology. doi: 10.11999/JEIT231426
Citation: DANG Sihang, LI Xiaozhe, XIA Zhaoqiang, JIANG Xiaoyue, GUI Shuliang, FENG Xiaoyi. Research on Open-Set Object Detection in Remote Sensing Images Based on Adaptive Pre-Screening[J]. Journal of Electronics & Information Technology. doi: 10.11999/JEIT231426

采用自适应预筛选的遥感图像目标开集检测研究

doi: 10.11999/JEIT231426
基金项目: 国家自然科学基金(62201461, 62301101),上海市2022年度“科技创新行动计划”启明星培育(扬帆专项)项目(22YF1452100),陕西省科技厅秦创原项目(QCYRCXM-2022-325),陕西省重点研发计划(2023-ZDLGY-16, 2023-ZDLGY-44, 2023-ZDLGY-12, 2021-ZDLGY15-01, 2021-ZDLGY09-04, 2021GY-004, 2022-ZDLGY06-07),重庆市博士“直通车”科研项目(sl202100000315)
详细信息
    作者简介:

    党思航:男,副教授,研究方向为雷达目标识别、增量学习

    李晓哲:男,硕士,研究方向为目标检测、开集识别

    夏召强:男,副教授,研究方向为图像处理、计算机视觉

    蒋晓悦:女,副教授,研究方向为图像处理、计算机视觉

    桂术亮:男,讲师,研究方向为雷达信号处理、目标检测

    冯晓毅:女,教授,研究方向为图像处理、计算机视觉

    通讯作者:

    夏召强 zxia@nwpu.edu.cn

  • 中图分类号: TP75

Research on Open-Set Object Detection in Remote Sensing Images Based on Adaptive Pre-Screening

Funds: The National Natural Science Foundation of China(62201461, 62301101), The Shanghai Sailing Program (22YF1452100), The QINCHUANGYUAN Program (QCYRCXM-2022-325), The Key Research and Development Program of Shaanxi (2023-ZDLGY-16, 2023-ZDLGY-44, 2023-ZDLGY-12, 2021-ZDLGY15-01, 2021-ZDLGY09-04, 2021GY-004, 2022-ZDLGY06-07), Chongqing Doctoral Direct Train Research Project (sl202100000315)
  • 摘要: 开放动态环境下目标类别不断丰富,遥感目标检测问题不能局限于已知类目标的鉴别,还需要对未知类目标做出有效判决。该文设计一种基于自适应预筛选的遥感开集目标检测网络,首先,提出面向目标候选框的自适应预筛选模块,依据筛选出的候选框坐标得到具有丰富语义信息和空间特征的查询传递至解码器。然后,结合原始图像中目标边缘信息提出一种伪标签选取方法,并以开集判决为目的构造损失函数,提高网络对未知新类特征的学习能力。最后,采用MAR20飞机目标识别数据集模拟不同的开放动态遥感目标检测环境,通过广泛的对比实验和消融实验,验证了该文方法能够实现对已知类目标的可靠检测和未知类目标的有效检出。
  • 图  1  网络总体结构

    图  2  自适应预筛选模块

    图  3  MAR20数据集部分图像展示

    图  4  MAR20测试集示例图像定性结果

    1  基于图像边缘信息的伪标签选取算法

     输入:当前迭代$ t $条件下:对应特征图$ \boldsymbol{A} $;经过DDETR匹配机制剩余的预测候选框$ {b}_{i}^{F} $;基于图像边缘信息生成的候选框$ {b}_{j}^{E} $;损失存储队
     列$ {l}_{m} $;微调参数$ {\lambda }_{p} $和$ {\lambda }_{n} $;权重更新迭代次数$ {T}_{w} $;权重值$ {w}_{1} $和$ {w}_{2} $;伪标签个数$ u $
     输出:当前迭代$ t $条件下:图像的伪标签
     1. while train do:
     2. 式(1)初步得到基于卷积特征的目标置信度得分$ F\left({b}_{i}^{F}\right) $;
     3. 式(3)得到基于图像底层边缘信息的目标置信度得分S$ \left({b}_{i}^{E}\right) $;
     4. if $ t\mathrm{\%}{T}_{w}==0 $ then:
     5. 使用式(7)和$ {l}_{m} $计算$ \Delta l $;
     6. 使用式(8)计算$ \Delta w $;
     7. 使用式(5)更新权重值$ {w}_{1} $和$ {w}_{2} $;
     8. end if
     9. 使用式(4)得到剩余的预测候选框$ {b}_{i}^{F} $的最终目标置信度分数$ {F}_{i}^{{\mathrm{new}}} $;
     10. 对$ {F}_{i}^{\mathrm{n}\mathrm{e}\mathrm{w}} $从大到小排序,选取前$ {u} $个候选框标记“未知类”。
    下载: 导出CSV

    表  1  MAR20数据集图像数量分布情况

    A1 A2 A3 A4 A5 A6 A7 A8 A9 A10
    168 16 150 70 247 31 100 142 146 146
    A11 A12 A13 A14 A15 A16 A17 A18 A19 A20
    86 66 212 252 108 265 173 37 129 130
    含多类 1017
    总计 3842
    下载: 导出CSV

    表  2  开集目标检测任务

    实验编号未知类目标类别训练与测试比例总计
    #已知类+#未知类已知类未知类训练测试
    任务10.75A1~A5A6~A20644161805
    任务20.5A1~A10A11~A20736185921
    任务30.25A1~A15A16~A20764192956
    下载: 导出CSV

    表  3  网络检测结果对比(%)

    任务编号 任务1 任务2 任务3
    已知类mAP 未知类召回率 已知类mAP 未知类召回率 已知类mAP 未知类召回率
    Faster-RCNN 73.95 77.84 88.18
    YOLOv3 88.02 88.40 88.86
    DDETR 84.30 87.60 88.95
    OW-DETR 82.52 17.66 87.90 29.68 87.66 30.41
    CAT 77.40 21.21 83.78 36.09 85.05 53.42
    本文算法 89.09 38.67 90.35 47.17 90.38 61.20
    下载: 导出CSV

    表  4  模块验证实验结果(%)

    模块任务1消融实验任务2消融实验任务3消融实验
    基准
    模型
    自适应预筛选基于边缘信息的
    伪标签选取策略
    已知类mAP未知类
    召回率
    已知类mAP未知类
    召回率
    已知类mAP未知类
    召回率
    82.5217.6687.9029.6887.6630.41
    89.342.4390.835.9689.7413.33
    83.2845.8187.5463.0187.6954.80
    89.0938.6790.3547.1790.3861.20
    下载: 导出CSV
  • [1] ZAIDI S S A, ANSARI M S, ASLAM A, et al. A survey of modern deep learning based object detection models[J]. Digital Signal Processing, 2022, 126: 103514. doi: 10.1016/j.dsp.2022.103514.
    [2] ZOU Zhengxia, CHEN Keyan, SHI Zhenwei, et al. Object detection in 20 years: A survey[J]. Proceedings of the IEEE, 2023, 111(3): 257–276. doi: 10.1109/JPROC.2023.3238524.
    [3] 吕进东, 王彤, 唐晓斌. 基于图注意力网络的半监督SAR舰船目标检测[J]. 电子与信息学报, 2023, 45(5): 1541–1549. doi: 10.11999/JEIT220139.

    LÜ Jindong, WANG Tong, and TANG Xiaobin. Semi-supervised SAR ship target detection with graph attention network[J]. Journal of Electronics & Information Technology, 2023, 45(5): 1541–1549. doi: 10.11999/JEIT220139.
    [4] 王玺坤, 姜宏旭, 林珂玉. 基于改进型YOLO算法的遥感图像舰船检测[J]. 北京航空航天大学学报, 2020, 46(6): 1184–1191. doi: 10.13700/j.bh.1001-5965.2019.0394.

    WANG Xikun, JIANG Hongxu, and LIN Keyu. Remote sensing image ship detection based on modified YOLO algorithm[J]. Journal of Beijing University of Aeronautics and Astronautics, 2020, 46(6): 1184–1191. doi: 10.13700/j.bh.1001-5965.2019.0394.
    [5] AI Jiaqiu, TIAN Ruitian, LUO Qiwu, et al. Multi-scale rotation-invariant Haar-like feature integrated CNN-based ship detection algorithm of multiple-target environment in SAR imagery[J]. IEEE Transactions on Geoscience and Remote Sensing, 2019, 57(12): 10070–10087. doi: 10.1109/TGRS.2019.2931308.
    [6] 黄玉玲, 陶昕辰, 朱涛, 等. 残差对抗目标检测算法的遥感图像检测[J]. 电光与控制, 2023, 30(7): 63–67. doi: 10.3969/j.issn.1671-637X.2023.07.011.

    HUANG Yuling, TAO Xinchen, ZHU Tao, et al. A remote sensing image detection method based on residuals adversarial object detection algorithm[J]. Electronics Optics & Control, 2023, 30(7): 63–67. doi: 10.3969/j.issn.1671-637X.2023.07.011.
    [7] 马梁, 苟于涛, 雷涛, 等. 基于多尺度特征融合的遥感图像小目标检测[J]. 光电工程, 2022, 49(4): 210363. doi: 10.12086/oee.2022.210363.

    MA Liang, GOU Yutao, LEI Tao, et al. Small object detection based on multi-scale feature fusion using remote sensing images[J]. Opto-Electronic Engineering, 2022, 49(4): 210363. doi: 10.12086/oee.2022.210363.
    [8] REN Shaoqing, HE Kaiming, GIRSHICK R, et al. Faster R-CNN: Towards real-time object detection with region proposal networks[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2017, 39(6): 1137–1149. doi: 10.1109/TPAMI.2016.2577031.
    [9] REDMON J, DIVVALA S, GIRSHICK R, et al. You only look once: Unified, real-time object detection[C]. The 2016 IEEE Conference on Computer Vision and Pattern Recognition, Las Vegas, USA, 2016: 779–788. doi: 10.1109/CVPR.2016.91.
    [10] REDMON J and FARHADI A. YOLOv3: An incremental improvement[EB/OL]. https://arxiv.org/abs/1804.02767, 2018.
    [11] 邵延华, 张铎, 楚红雨, 等. 基于深度学习的YOLO目标检测综述[J]. 电子与信息学报, 2022, 44(10): 3697–3708. doi: 10.11999/JEIT210790.

    SHAO Yanhua, ZHANG Duo, CHU Hongyu, et al. A review of YOLO object detection based on deep learning[J]. Journal of Electronics & Information Technology, 2022, 44(10): 3697–3708. doi: 10.11999/JEIT210790.
    [12] CARION N, MASSA F, SYNNAEVE G, et al. End-to-end object detection with transformers[C]. The 16th European Conference on Computer Vision, Glasgow, UK, 2020: 213–229. doi: 10.1007/978-3-030-58452-8_13.
    [13] GENG Chuanxing, HUANG Shengjun, and CHEN Songcan. Recent advances in open set recognition: A survey[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2021, 43(10): 3614–3631. doi: 10.1109/TPAMI.2020.2981604.
    [14] DANG Sihang, CAO Zongjie, CUI Zongyong, et al. Open set incremental learning for automatic target recognition[J]. IEEE Transactions on Geoscience and Remote Sensing, 2019, 57(7): 4445–4456. doi: 10.1109/TGRS.2019.2891266.
    [15] DANG Sihang, XIA Zhaoqiang, JIANG Xiaoyue, et al. Inclusive consistency-based quantitative decision-making framework for incremental automatic target recognition[J]. IEEE Transactions on Geoscience and Remote Sensing, 2023, 61: 5215614. doi: 10.1109/TGRS.2023.3312330.
    [16] JOSEPH K J, KHAN S, KHAN F S, et al. Towards open world object detection[C]. The 2021 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Nashville, USA, 2021: 5826–5836. doi: 10.1109/CVPR46437.2021.00577.
    [17] GUPTA A, NARAYAN S, JOSEPH KJ, et al. OW-DETR: Open-world detection transformer[C]. The 2022 IEEE/CVF Conference on Computer Vision and Pattern Recognition, New Orleans, USA, 2022: 9225–9234. doi: 10.1109/CVPR52688.2022.00902.
    [18] MA Shuailei, WANG Yuefeng, WEI Ying, et al. CAT: LoCalization and identification cascade detection transformer for open-world object detection[C]. The 2023 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Vancouver, Canada, 2023: 19681–19690. doi: 10.1109/CVPR52729.2023.01885.
    [19] UIJLINGS J R R, VAN DE SANDE K E A, GEVERS T, et al. Selective search for object recognition[J]. International Journal of Computer Vision, 2013, 104(2): 154–171. doi: 10.1007/s11263-013-0620-5.
    [20] ZOHAR O, WANG K C, and YEUNG S. PROB: Probabilistic objectness for open world object detection[C]. The 2023 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Vancouver, Canada, 2023: 11444–11453. doi: 10.1109/CVPR52729.2023.01101.
    [21] CHENG Gong, XIE Xingxing, HAN Junwei, et al. Remote sensing image scene classification meets deep learning: Challenges, methods, benchmarks, and opportunities[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2020, 13: 3735–3756. doi: 10.1109/JSTARS.2020.3005403.
    [22] ZITNICK C L and DOLLÁR P. Edge boxes: Locating object proposals from edges[C]. The 13th European Conference on Computer Vision, Zurich, Switzerland, 2014: 391–405. doi: 10.1007/978-3-319-10602-1_26.
    [23] 禹文奇, 程塨, 王美君, 等. MAR20: 遥感图像军用飞机目标识别数据集[J]. 遥感学报, 2023, 27(12): 2688–2696. doi: 10.11834/jrs.20222139.

    YU Wenqi, CHENG Gong, WANG Meijun, et al. MAR20: A benchmark for military aircraft recognition in remote sensing images[J]. National Remote Sensing Bulletin, 2023, 27(12): 2688–2696. doi: 10.11834/jrs.20222139.
    [24] ZHU Xizhou, SU Weijie, LU Lewei, et al. Deformable DETR: Deformable transformers for end-to-end object detection[C]. 9th International Conference on Learning Representations, 2021.
