一种基于程序执行时间量化分析的软件水印方法

张颖君; 陈恺; 鲍旭华

doi:10.11999/JEIT190850

一种基于程序执行时间量化分析的软件水印方法

doi: 10.11999/JEIT190850

1.
中国科学院软件研究所可信计算与信息保障实验室北京 100190
2.
中国科学院信息工程研究所信息安全国家重点实验室北京 100093
3.
网神信息技术(北京)股份有限公司北京 100015

基金项目: 国家重点研发计划项目(2016QY04W0805)，国家自然科学基金(U1836211)，大数据协同安全国家工程实验室开放课题

详细信息

作者简介:
张颖君：女，1982年生，副研究员，主要研究方向为安全测评、系统安全

陈恺：男，1982年生，研究员，主要研究方向为系统安全、人工智能安全

鲍旭华：男，1977年生，高级工程师，主要研究方向为信息安全

通讯作者:
鲍旭华　xuhua.bao@outlook.com

中图分类号: TP309
计量
- 文章访问数: 1710
- HTML全文浏览量: 627
- PDF下载量: 122
- 被引次数: 0
出版历程
- 收稿日期: 2019-11-01
- 修回日期: 2020-03-20
- 网络出版日期: 2020-07-08
- 刊出日期: 2020-08-18

A Software Watermarking Method Based on Program Execution Time

1.
Trusted Computing and Information Assureance Laboratory, Institute of Software, Chinese Academy of Sciences, Beijing 100190, China
2.
State Key Laboratory of Information Security, Institute of Information Engineering, Chinese Academy of Sciences, Beijing 100093, China
3.
Legendsec Information Technology(Beijing) Inc, Beijing 100015, China

Funds: The National Key Research and Development Program of China(2016QY04W0805), The National Natural Science Foundation of China (U1836211), The Open Project of National Engineering Laboratory of Big Data Collaborative Security

摘要

摘要: 当前，应用软件面临的重要问题是不法分子通过软件剽窃、重打包等技术，将恶意负载或广告加载到合法应用软件中，并形成新软件进行发布，给用户和应用软件作者的合法权益带来威胁。为了实现对应用软件剽窃、重打包等安全风险的测评，该文提出一种基于程序执行时间量化分析的软件水印方法(SW_PET)。通过生成多种相互抵消功能的操作组，实现对水印信息的时间化编码，并植入应用软件中；在检测过程中，需要提取相应的水印信息，对照之前的时间编码对应的原始水印，比较不同操作的执行时间，判断水印相似度，进而判别原始水印的存在性，完成应用软件合法性的判断。该方法也可以与其它类型的水印信息相结合，增强水印的鲁棒性。最后，通过搭建仿真模拟器，实现对不同应用软件水印信息的比较和判断，验证该方法的有效性。
- 软件水印 /
- 程序执行 /
- 水印编码
Abstract: Currently, a main problem in software is repackaging or plagiarization, which means attackers can add malicious payloads or advertisements into legitimate APPs through piggybacking, it greatly threatens the users and original developers. In this paper, a novel Software Watermarking method based on Program Execution Time (SW_PET) is proposed. By generating a variety of effect-canceling operations, the watermark information can be encoded into the form of program execution time, and can be embedded into Android APPs. In the detection process, the watermark information is extracted and compared with the original watermark to check whether the APP is repackaged. This method can be combined with other types of watermarks (e.g., picture-based watermarks) in order to enhance the robustness. Finally, the effectiveness of the proposed approach is verified, and the overhead introduced by the watermark is measured, which is demonstrated to be minimal.
- Software watermarking /
- Program execution /
- Watermark encoding

HTML全文

图 1 基于程序执行时间量化分析的水印方法流程图

下载: 全尺寸图片幻灯片

图 2 程序相关编码示例

下载: 全尺寸图片幻灯片

图 3 使用原始程序中代码作为水印示例

下载: 全尺寸图片幻灯片

表 1 主要操作类型表

操作类型	操作	示例
算术操作	加法	x = x + y, x = x + C，等
	减法	x = x – y, x = x - C，等
	乘法	x = x × y, x = x × C，等
	除法	x = x / y, x = x / C，等
逻辑操作	逻辑与	x = x && y, x = x && C，等
	逻辑或	x = x \|\| y, x = x \|\| C，等
	逻辑非	x =!x
比特位操作	比特and操作	x = x & y, x = x & C，等
比特位操作	比特or操作	x = x \| y, x = x \| C，等
移位操作	左移位	x = x << y, x = x << C，等
移位操作	右移位	x = x >> y, x = x >> C，等

下载: 导出CSV

表 2 mark的时间编码序列

水印字母	操作代码
m	x = x + y; x = x – y
a	x = x × y; x = x / y
r	x = x + y; x = x – y; x = x × y; x = x / y
k	y = x; x = (x>>2); y = x & 0 × 3; x = (x<<2)\|y

下载: 导出CSV

表 3 mark的时间编码序列

水印字母	操作代码	时间(μs)
m	x = x + y; x = x – y	2.14
a	x = x × y; x = x / y	4.04
r	x = x + y; x = x – y; x = x × y; x = x / y	7.14
k	y = x; x = (x>>2); y = x & 0x3; x = (x<<2)\|y	6.19

下载: 导出CSV

表 4 典型水印算法安全性比较

水印方法	安全性	隐蔽性	水印容量	复杂度
DMI^[13]	+	+	+++	+
GTW^[14]	++	++	+++	++
CT^[21]	++	+++	+++	++
AppInk^[2]	+++	+++	+++	++
SW_PET	+++	+++	+++	+

下载: 导出CSV

参考文献(23)

林迪. 2018年中国App下载量排名全球第一: 占全球50%[EB/OL]. https://www.sohu.com/a/289551518_162522, 2019.

ZHOU Wu, ZHANG Xinwen, and JIANG Xuxian. AppInk: Watermarking android apps for repackaging deterrence[C]. The 8th ACM SIGSAC Symposium on Information, Computer and Communications Security. Hangzhou, China, 2013: 1–12. doi: 10.1145/2484313.2484315.

ZHOU Wu, ZHOU Yajin, JIANG Xuxian, et al. Detecting repackaged smartphone applications in third-party android marketplaces[C]. The 2nd ACM Conference on Data and Application Security and Privacy. San Antonio, United States, 2012: 317–326. doi: 10.1145/2133601.2133640.

Arxan Technologies. State of security in the App Economy: Mobile apps under attack[EB/OL]. http://www.arxan.com/assets/1/7/state-of-security-appeconomy.pdf, 2012.

CHEN Kai, ZHANG Yingjun, and LIU Peng. Leveraging information asymmetry to transform android apps into self-defending code against repackaging attacks[J]. IEEE Transactions on Mobile Computing, 2018, 17(8): 1879–1893. doi: 10.1109/TMC.2017.2782249

CHEN Kai, LIU Peng, and ZHANG Yingjun. Achieving accuracy and scalability simultaneously in detecting application clones on android markets[C]. The 36th International Conference on Software Engineering. Hyderabad, India, 2014: 175–186. doi: 10.1145/2568225.2568286.

CRUSSELL J, GIBLER C, and CHEN Hao. AnDarwin: Scalable detection of semantically similar android applications[C]. The 18th European Symposium on Research in Computer Security on Computer Security. Egham, UK, 2013: 182–199. doi: 10.1007/978-3-642-40203-6_11.

Guardsquare. Proguar[EB/OL]. http://proguard.sourceforge.net/, 2013.

Guardsquare. A specialized optimizer and obfuscator for android[EB/OL]. http://www.saikoa.com/dexguard, 2013.

陈明奇, 钮心忻, 杨义先. 数字水印的攻击方法[J]. 电子与信息学报, 2001, 23(7): 705–711.

CHEN Mingqi, NIU Xinyi, and YANG Yixian. The attack methods of digital watermarking[J]. Journal of Electronics &Information Technology, 2001, 23(7): 705–711.

毛琼, 陈明奇, 夏光升, 等. 安全数字水印体系的研究[J]. 电子与信息学报, 2001, 23(9): 833–840.

MAO Qiong, CHEN Mingqi, XIA Guangsheng, et al. The research of secure digital watermarking architecture[J]. Journal of Electronics &Information Technology, 2001, 23(9): 833–840.

HAMILTON J and DANICIC S. A survey of static software watermarking[C]. 2011 World Congress on Internet Security. London, UK, 2011: 100–107. doi: 10.1109/worldcis17046.2011.5749891.

MONDEN A, IIDA H, MATSUMOTO K, et al. A practical method for watermarking java programs[C]. The 24th Annual International Computer Software and Applications Conference. Taipei, China, 2000: 191–197. doi: 10.1109/CMPSAC.2000.884716.

VENKATESAN R, VAZIRANI V, and SINHA S. A graph theoretic approach to software watermarking[C]. The 4th International Workshop on Information Hiding. Pittsburgh, USA, 2001: 157–168. doi: 10.1007/3-540-45496-9_12.

COUSOT P and COUSOT R. An abstract interpretation-based framework for software watermarking[C]. The 31st ACM SIGPLAN-SIGACT Symposium on Principles of Programming Languages. Venice, Italy, 2004: 173–185. doi: 10.1145/964001.964016.

NAGRA J and THOMBORSON C. Threading software watermarks[C]. The 6th International Workshop on Information Hiding. Toronto, Canada, 2004: 208–223. doi: 10.1007/978-3-540-30114-1_15.

COLLBERG C, HUNTWORK A, CARTER E, et al. More on graph theoretic software watermarks: Implementation, analysis, and attacks[J]. Information and Software Technology, 2009, 51(1): 56–67. doi: 10.1016/j.infsof.2008.09.016

COLLBERG C, CARTER E, DEBRAY S, et al. Dynamic path-based software watermarking[J]. ACM Sigplan Notices, 2004, 39(6): 107–118. doi: 10.1145/996893.996856

COLLBERG C, CARTER E, DEBRAY S, et al. Dynamic path-based software watermarking[C]. The 2004 ACM SIGPLAN Conference on Programming Language Design and Implementation, Washington, USA, 2004: 107–118. doi: 10.1145/996841.996856.

ZENG Lingling, REN Wei, LEI Min, et al. DroidMark: A lightweight android text and space watermark scheme based on semantics of XML and DEX[C]. The 5th International Conference on Emerging Internetworking. Wuhan, China, 2017: 756–766. doi: 10.1007/978-3-319-59463-7_75.

COLLBERG C and THOMBORSON C. Software watermarking: Models and dynamic embedding[C]. The 26th ACM SIGPLAN-SIGACT Symposium on Principles of Programming Languages. San Antonio, USA, 1999: 311–324. doi: 10.1145/292540.292569.

ZHANG Yingjun and CHEN Kai. AppMark: A picture-based watermark for android apps[C]. The 8th International Conference on Software Security and Reliability (SERE). San Francisco, USA, 2014: 58–67. doi: 10.1109/SERE.2014.19.

王叶茂, 车生兵. 软件水印及其研究现状概述[J]. 计算机应用与软件, 2015, 32(4): 6–10. doi: 10.3969/j.issn.1000-386x.2015.04.002

WANG Yemao and CHE Shengbing. Summary on software watermarking and its research progress[J]. Computer Applications and Software, 2015, 32(4): 6–10. doi: 10.3969/j.issn.1000-386x.2015.04.002
