Energy Saving Mechanism with Offload Delay Aware in Cloudlet Enhanced Fi-Wi Access Network
-
摘要:
边缘云增强光无线融合网络中，存在传统节能机制与卸载业务不匹配的问题。该文提出一种带有负载转移的光网络单元卸载协同休眠机制。通过分析当前光网络单元负载，结合无线域多跳传输时延和目标光网络单元的报告帧发送时刻，进而确定休眠和目的光网络单元完成负载转移。然后光网络单元协同考虑边缘服务器的回传数据到达时刻和无线域控制帧的发送时刻，选取最合适的休眠时长以减少控制开销。仿真结果表明，所提机制在有效降低网络能耗的同时能保证卸载业务的时延性能。
Abstract:In cloudlet enhanced Fiber-Wireless (FiWi) access network, there is a problem that the traditional energy saving mechanism does not match the offload traffic. An offload collaboration sleep mechanism with load transfer is proposed. By analyzing the load of the optical network unit and combining the transmission delay of the multi-hop in the wireless domain and the sending time of the report frame of the target optical network unit, the proposed mechanism can determine the sleeping and the destination optical network unit to complete load transfer. Then, the optical network unit jointly considers the arrival time of the returned data of the edge severs and the sending time of the control frame in the wireless domain to select the optimal sleep duration and reduce the controlling overhead. Simulation results show that the proposed mechanism can effectively reduce the network energy consumption while ensuring the delay performance of offload traffic.
-
表 1 仿真参数设置
参数设定 参数数值 ONU数目N(个) 16 STA数目M(个) 50 ONU活跃状态能耗(W) 5.052 ONU休眠状态能耗(W) 0.750 STA活跃状态能耗(W) 0.900 STA休眠状态能耗(W) 0.300 平均卸载分组大小(kB) 163.6 ONU间保护时隙(μs) 46.000 STA间保护时隙(μs) 10.000 控制帧时隙(μs) 0.512
下载: 导出CSV
-
WU Dapeng, LIU Qianru, WANG Honggang, et al. Socially aware energy efficient mobile edge collaboration for video distribution[J]. IEEE Transaction on Multimedia, 2017, 19(10): 2197–2209. doi: 10.1109/TMM.2017.2733300HJK WU Dapeng, SI Shushan, WU Shaoen, et al. Dynamic trust relationships aware data privacy protection in mobile crowd-sensing[J]. IEEE Internet of Things Journal, 2017, 5(4): 2958–2970. doi: 10.1109/JIOT.2017.2768073 DAVY S, FAMAEY J, SERRAT F J, et al. Challenges to support edge-as-a-service[J]. IEEE Communications Magazine, 2014, 52(1): 132–139. doi: 10.1109/MCOM.2014.6710075 WU Dapeng, LIU Zuqi, WANG Ruyan, et al. Dynamic bandwidth allocation mechanism in EPON with idle time eliminated[J]. Optik-International Journal for Light and Electron Optics, 2013, 124(23): 6372–6376. doi: 10.1016/j.ijleo.2013.05.027 YU Yingpeng, LIU Yejun, ZHOU Yufang, et al. Planning of survivable cloud-integrated wireless-optical broadband access network against distribution fiber failure[J]. Optical Switching & Networking, 2014, 14(4): 217–225. doi: 10.1016/j.osn.2014.05.014 SARDELLITTI S, SCUTARI G, and BARBAROSSA S. Joint optimization of radio and computational resources for multicell mobile-edge computing[J]. IEEE Transactions on Signal & Information Processing Over Networks, 2015, 1(2): 89–103. doi: 10.1109/TSIPN.2015.2448520 RIMAL B P, VAN D P, and MAIER M. Mobile-edge computing versus centralized cloud computing over a converged FiWi access network[J]. IEEE Transactions on Network & Service Management, 2017, 14(3): 498–513. doi: 10.1109/TNSM.2017.2706085 YOU Changsheng, HUANG Kaibin, HYUKJIN C, et al. Energy-efficient resource allocation for mobile-edge computation offloading[J]. IEEE Transactions on Wireless Communications, 2017, 16(3): 1397–1411. doi: 10.1109/TWC.2016.2633522 ZHANG Ke, MAO Yuming, and LENG Supeng. Energy-efficient offloading for mobile edge computing in 5G heterogeneous Networks[J]. IEEE Access, 2015, 4(68): 5896–5907. doi: 10.1109/ACCESS.2016.2597169 LIU Yejun, GUO Lei, ZHANG Lincong, et al. A new integrated energy-saving scheme in green Fiber-Wireless(FiWi) access network[J]. Science China, 2014, 57(6): 62307–06. doi: 10.1007/s11432-013-4958-7 张晚生, 刘凯. 无线网络中基于位置的能量高效协作路由算法[J]. 电子与信息学报, 2012, 34(1): 63–68. doi: 10.3724/SP.J.1146.2011.00425ZHANG Wansheng and LIU Kai. Energy-efficient location-based cooperative routing in wireless networks[J]. Journal of Electronics &Information Technology, 2012, 34(1): 63–68. doi: 10.3724/SP.J.1146.2011.00425 RIMAL B P, VAN D P, and MAIER M. Mobile-edge computing vs. centralized cloud computing in fiber-wireless access networks[C]. IEEE Computer Communications Workshops, San Francisco, USA, 2016: 991–996. SARKAR S, YEN H H, DIXIT S, et al. A novel Delay-Aware Routing Algorithm (DARA) for a hybrid Wireless-Optical Broadband Access Network (WOBAN)[J]. Network IEEE, 2008, 22(3): 20–28. doi: 10.1109/MNET.2008.4519961 ZHAO Tianchu, ZHOU Sheng, GUO Xueying, et al. A cooperative scheduling scheme of local cloud and internet cloud for delay-aware mobile cloud computing[C]. IEEE Globecom Wkshps. San Diego, USA, 2015: 1–6. CHENG Dazhao, JIANG Changjun, and ZHOU Xiaobo. Heterogeneity-aware workload placement and migration in distributed sustainable datacenters[C]. IEEE International Parallel and Distributed Processing Symposium, Phoenix, USA, 2014: 307–316. NEWAZA S S H, CUEVASB A, LEE G M, et al. Adaptive delay-aware energy efficient TDM-PON[J]. Computer Networks, 2013, 57(7): 1577–1596. doi: 10.1016/j.comnet.2013.02.001 MIYANABE K, NISHIYAMA H, KATO N, et al. Synchronized power saving mechanisms for battery-powered mobile terminals in smart FiWi networks[C]. IEEE Vehicular Technology Conference, Vancouver, Canada, 2014: 1–5. -
