基于宽带吸波体的低雷达散射截面平面印刷磁电偶极子天线设计

兰俊祥; 曹祥玉; 高军; 郑月军; 张晨

doi:10.11999/JEIT170721

基于宽带吸波体的低雷达散射截面平面印刷磁电偶极子天线设计

doi: 10.11999/JEIT170721

基金项目:

国家自然科学基金(61271100, 61471389, 61501494)，陕西省自然科学基金(2017JM6025)

计量
- 文章访问数: 1142
- HTML全文浏览量: 203
- PDF下载量: 138
- 被引次数: 0
出版历程
- 收稿日期: 2017-07-19
- 修回日期: 2017-12-21
- 刊出日期: 2018-05-19

Low Radar Cross Section of Planar Printed Magneto-electric Dipole Antenna Based on Wide-band Metamaterial Absorber

Funds:

The National Natural Science Foundation of China (61271100, 61471389, 61501494), The Natural Science Foundational of Shannxi Province (2017JM6025)

摘要

摘要: 该文设计了一种工作于X波段的平面印刷磁电偶极子天线，并设计了一种加载集总电阻的宽入射角、极化不敏感、宽频带吸波体(WBMA)。当平面波垂直入射时，吸波体在7.2~12.6 GHz范围内的吸波率大于90%，入射角增加至45时仍能在X波段保持90％以上的吸波率。通过将WBMA加载在天线四周，实现了天线雷达散射截面(RCS)的大幅缩减。实测和仿真结果表明：不同极化波垂直入射时，天线单站RCS减缩3 dB带宽为6.6~14.4 GHz，最大减缩量达23.8 dB。中心频点10 GHz处，TE极化波照射时，双站RCS能实现90角域内的减缩，TM极化波照射时，在35角域内实现了减缩，同时天线辐射性能几乎保持不变。
- 磁电偶极子天线 /
- 雷达散射截面 /
- 宽带吸波体 /
- X波段
Abstract: A broadband planar printed Magneto-Electric (ME) dipole antenna and a Wide-Band Metamaterial Absorber (WBMA) with polarization-insensitive and wide-angle absorption are designed for X band application. The absorber exhibits absorptivity above 90% from 7.2 GHz to 12.6 GHz under normal incidence. When the incident angle increases to 45, the absorptivity is still above 90% at X band. By applying the absorber around the antenna, the RCS of antenna is reduced significantly. Simulated and experimental results show a monostatic RCS reduction above 3 dB from 7.2 GHz to 12.6 GHz, and the peak reduction is up to 23.8 dB under different polarized waves. At the center working frequency of 10 GHz, the bistatic RCS decreases significantly from-90 to +90 under TE polarized wave and from-35 to+35 under TM polarized wave while the radiation performance remains unchanged basically, which proves that the absorber has great absorptivity.
- Magneto-Electric (ME) dipole antenna /
- Rader Cross Section (RCS) /
- Wide-Band Metamaterial Absorber (WBMA) /
- X band

HTML全文

参考文献(19)

DING Cheng and LUK K M. A low-profile magneto-electric dipole antenna[J]. IEEE Antennas and Wireless Propagation Letters, 2012, 15(4): 1642-1644. doi: 10.1109/LAWP.2016. 2519942.

LUK K M and WONG H. A new wideband unidirectional antenna element[J]. Microwave and Optical Technology Letter, 2006, 1(1): 35-44.

LI Mingjian and LUK K M. A wideband circularly polarized antenna for microwave and millimeter-wave applications[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(4): 1872-1879. doi: 10.1109/TAP.2014.2298246.

ABDOLMEHDI Dadgarpour, MILAD Shrifi Sorkherizi, and AHMED Kishk. High efficient circularly polarized magneto- electric dipole antennas for 5G applications using dual- polarized split-ring resonator lens[J]. IEEE Transactions on Antennas and Propagation, 2017, 65(8): 4263-4267. doi: 10.1109/TAP.2017.2708091.

张晨, 曹祥玉, 高军, 等. 低RCS 宽带磁电偶极子贴片天线设计[J]. 电子与信息学报, 2016, 38(4): 1012-1015. doi: 10.11999/JEIT150897.

ZHANG Chen, CAO Xiangyu, GAO Jun, et al. Low radar cross section and broadband magneto-electric dipole patch antenna[J]. Journal of Electronics Information Technology, 2016, 38(4): 1012-1015. doi: 10.11999/JEIT150897.

ZHANG Chen, CAO Xiangyu, GAO Jun, et al. Low RCS and broadband ME dipole antenna loading artificial magnetic conductor structures[J]. Radioengineering, 2017, 26(1): 1-7. doi: 10.13164/RE.2017.0001.

ENGHETA N. Thin absorbing screens using metamaterial surfaces[C]. Antennas and Propagation Society International Symposium, San Antonio, TX, USA, 2002: 392-395. doi: 10.1109/APS.2002.1016106.

LANDY N I, SAJUYIGBE S, MOCK J J, et al. Perfect metamaterial absorber[J]. Physical Review Letters, 2008, 100(20): 207402. doi: 10.1103/PhysRevLett.100.207402.

LI Long and L Zhiyong. Ultra-wideband polarization- insensitive and wide-angle thin absorber based on resistive metasurfaces with three resonant modes[J]. Journal of Applied Physics, 2017, 122(5): 055104. doi: 10.1063/1.4997468.

ZHONG Huiteng, YANG Xuexia, TAN Chong, et al. Triple- band polarization-insensitive and wide-angle metamaterial array for electromagnetic energy harvesting[J]. Applied Physics Letters, 2016, 109(25): 253904. doi: 10.1063/ 1.4973282.

AGARWAL M, BEHERA A K V, and MESHRAM M K. Wide-angle quad-band polarization-insensitive metamaterial absorber[J]. Electronics Letters, 2016, 52(5): 340-342. doi: 10.1049/EL. 2015.4134.

SHANG Shuai, YANG Shizhong, TAO Lu, et al. Ultrathin triple-band polarization-insensitive wide-angle compact metamaterial absorber[J]. AIP Advances, 2016, 6(7): 075203. doi: 10.1063/1.4958660.

AN Shaonan, XU Haibing, ZHANG Yulu, et al. Design of a polarization-insensitive wideband tunable metamaterial absorber based on split semi-circle ring resonators[J]. Journal of Applied Physics, 2017, 122(2): 2342-2348. doi: 10.1063/ 1.4993717.

SAPTARSHI Ghosh, SOMAK Bhattacharyya, DEVKINANDAN Chaurasiya, et al. An ultra-wideband ultra-thin metamaterial absorber based on circular split rings[J]. IEEE Antennas and Wireless Propagation Letters, 2015, 14: 1172-1175. doi: 10.1109/LAWP.2015.2396302.

HE Yun, JIANG Jianjun, CHEN Mi, et al. Design of an adjustable polarization-independent and wideband electromagnetic absorber[J]. Journal of Applied Physics, 2016, 119(10): 105103. doi: 10.1063/1.4943593.

CHENG Zhang, QIANG Cheng, JIN Yang, et al. Broadband metamaterial for optical transparency and microwave absorption[J]. Applied Physics Letters, 2017, 110(14): 143511. doi: 10.1063/1.4979543.

李文惠, 张介秋, 屈绍波, 等. 基于宽带吸波体的微带天线雷达散射截面缩减设计[J]. 物理学报, 2015, 64(8): 084101. doi: 10.7498/APS.64.084101.

LI Wenhui, ZHANG Jieqiu, QU Shaobo, et al. Radar cross section reduction of microstrip antenna based on wide-band metamaterial absorber[J]. Acta Physica Sinica, 2015, 64(8): 084101. doi: 10.7498/APS.64.084101.
