一种新的高重频宽带相干激光雷达系统研究

李光祚; 默迪; 王宁; 王然; 张珂殊; 张增辉; 吴一戎

doi:10.11999/JEIT170479

一种新的高重频宽带相干激光雷达系统研究

doi: 10.11999/JEIT170479

1.
(上海交通大学电子信息与电气工程学院上海 200240)
2.
(中国科学院电子学研究所北京 100190)

计量
- 文章访问数: 1226
- HTML全文浏览量: 129
- PDF下载量: 264
- 被引次数: 0
出版历程
- 收稿日期: 2017-05-18
- 修回日期: 2017-11-24
- 刊出日期: 2018-03-19

A Novel Coherent Ladar System with High Repetition Frequency and Wide Bandwidth

1.
(School of Electronic Information and Electrical Engineering, Shanghai Jiaotong University, Shanghai 200240,China)
2.
(Insititute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)

摘要

摘要: 该文提出一种新的同时具有高重复频率和大带宽性能的相干激光雷达系统。该系统基于IQ调制器正交调制技术与带宽合成信号处理技术，使得系统能够同时满足大带宽和高重复频率的要求，解决了传统激光雷达宽带信号调制速度慢的问题。该系统能够生成高重频、大带宽的相干线性调频激光雷达信号，在高分辨距离成像、(逆)合成孔径激光雷达成像、距离分辨的振动测量等方面，具有重要的应用价值。文中阐述了宽带高重复频率调制的原理和方法、基于微波域频率步进的带宽合成信号处理方法，并进行光纤环路实验和自由空间实验。作为演示，该激光雷达系统获得了16.7 kHz重复频率、6 GHz带宽，实现了优于2.5 cm距离向分辨率成像及远距离运动目标逆合成孔径激光雷达成像。实验结果证明了该系统与方法的有效性。
- 相干激光雷达 /
- 高重复频率 /
- 带宽合成 /
- 高分辨率距离成像
Abstract: A novel coherent ladar system with high repetition and wide bandwidth is proposed. Based on the IQ modulator from the fiber communication community and the bandwidth synthesis technique, the proposed system provides wide bandwidth with high repetition rate, which is difficult for conversional ladar system based on tuning the wavelength of a tunable laser. The proposed system is expected to be useful for high range resolution imaging, Inverse Synthetic Aperture Ladar (ISAL), range resolved vibration measurement. The operation principle, system description, and signal processing method for bandwidth synthesis are discussed in the paper. And experiments are performed both in fiber delay line and free space. As a demonstration, the system generates signal with 6 GHz at repetition rate of 16.7 kHz. The resolution of the obtained images is finer than 2.5 cm. The experimental results demonstrates the effectiveness of the proposed system and the processing method.
- Coherent ladar /
- High repetition frequency rate /
- Bandwidth synthesis /
- High Resolution Range Profile (HRRP)

HTML全文

参考文献(17)

PIERROTTET D, AMZAJERDIAN F, PETWAY L, et al. Linear FMCW laser radar for precision range and vector velocity measurements[C]. Material Research Society (MRS) Meeting, San Francisco, U.S.A, 2008: 1076-1085.

KRAUSE B W, BUCK J, Hwang D, et al. Synthetic aperture ladar flight demonstration[C]. IEEE Lasers and Electro- Optics Conference, Baltimore, Maryland, USA, 2011: 1-2.

CARNS J. Semiconductor optical amplifier as a phase modulator for short-pulse synthetic aperture ladar and vibrometry[D]. [Ph.D. dissertation], The Dayton University, 2012: 7-9.

RICHARDS M. Fundamentals of Radar Signal Processing[M]. New York: McGraw-Hill, 2005: 139-147.

BUELL W, MARECHAL N, BUCK J, et al. Demonstrations of synthetic aperture imaging ladar[J]. Proceedings of the SPIE, 2005, 5791: 152-166. doi: 10.1117/12.609682.

BECK S, BUCK J, BUELl W, et al. Synthetic-aperture imaging laser radar: Laboratory demonstration and signal processing[J]. Applied Optics, 2005, 44(35): 7621-7629.

LI G, WANG R, WANG P, et al. Synthetic aperture LADAR at 1550 nm: System demonstration, imaging processing and experimental result[J]. Proceedings of the SPIE, 2016, 10155: 155-158. doi: 10.1117/12.2247376.

ADANY P, ALLEN C, and HUI R. Chirped lidar using simplified homodyne detection[J]. Journal of Lightwave Technology, 2009, 27(16): 3351-3357.

GAO S and HUI R. Frequency-modulated continuous-wave lidar using I∕Q modulator for simplified heterodyne detection[J]. Optics Letters, 2012, 37(11): 2022-2024.

LI G, WANG R, SONG Z, et al. Linear frequency modulated continuous wave ladar system for synthetic aperture imaging[J] Applied Optics, 2017, 56(12): 3257-3262.

LI G, WANG N, WU Y, et al. Imaging method for airborne SAL data[J]. Electronics Letters, 2017, 53(5): 351-353. doi: 10.1049/el.2016.4205.

SCHIMPF H, WAHLEN A, and ESSEN H. High range resolution by means of synthetic bandwidth generated by frequency- stepped chirps[J]. Electronics Letters, 2003, 39(18): 1346-1348. doi: 10.1049/el:20030829.

ESSEN H, SCHIMPF H, and WAHLEN A. Improvement of the millimeterwave SAR MEMPHIS for very high resolution [R]. FGAN-FHR Technical Report, Werthhoven, 2003.

王岩飞, 刘畅, 李和平, 等. 基于多通道合成的优于 0.1 m 分辨率的机载 SAR 系统[J]. 电子与信息学报, 2013, 35(1): 29-35. doi: 10.3724/SP.J.1146.2011.01370.

WANG Yanfei, LIU Chang, LI Heping, et al. An airborne SAR with 0.1 m resolution using multi-channel synthetic bandwidth[J]. Journal of Electronics Information Technology, 2013, 35(1): 29-35. doi: 10.3724/SP.J.1146.2011. 01370.

MOTTET A and NICOLAS B. Tunable frequency shifter based on LiNbO3-IQ modulators[R]. Pthotline Delivering Modulation Solutions, 2016.

CARRAR G, GOODMAN R S, and MAJEWSKI R M. Spotlight Synthetic Aperture Radar Signal Processing Algorithms[M]. Norwood Massachusetts, Artech House, 1995: 501-506.
