一种混合特征高效融合的视网膜血管分割方法

蔡轶珩; 高旭蓉; 邱长炎; 崔益泽

doi:10.11999/JEIT161290

一种混合特征高效融合的视网膜血管分割方法

doi: 10.11999/JEIT161290

基金项目:

国家自然科学基金(61201360)

计量
- 文章访问数: 1358
- HTML全文浏览量: 222
- PDF下载量: 351
- 被引次数: 0
出版历程
- 收稿日期: 2016-11-28
- 修回日期: 2017-04-14
- 刊出日期: 2017-08-19

Retinal Vessel Segmentation Method with Efficient Hybrid Features Fusion

Funds:

The National Natural Science Foundation of China (61201360)

摘要

摘要: 将机器学习运用到视网膜血管分割当中已成为一种趋势，然而选取什么特征作为血管与非血管的特征仍为众所思考的问题。该文利用将血管像素与非血管像素看作二分类的原理，提出一种混合的5D特征作为血管像素与非血管像素的表达，从而能够简单快速地将视网膜血管从背景中分割开来。其中5D特征向量包括CLAHE (Contrast Limited Adaptive Histgram Equalization)，高斯匹配滤波，Hesse矩阵变换，形态学底帽变换，B-COSFIRE(Bar-selective Combination Of Shifted FIlter REsponses)，通过将融合特征输入SVM(支持向量机)分类器训练得到所需的模型。通过在DRIVE和STARE数据库进行实验分析，利用Se, Sp, Acc, Ppv, Npv, F1-measure等常规评价指标来检测分割效果，其中平均准确率分别达到0.9573和0.9575，结果显示该融合方法比单独使用B-COSFIRE或者其他目前所提出的融合特征方法更准确有效。
- 机器学习 /
- 视网膜 /
- 血管分割 /
- 特征向量 /
- 支持向量机
Abstract: How to apply machine learning to retinal vessel segmentation effectively has become a trend, however, choosing what kind of features for the blood vessels is still a problem. In this paper, the blood vessels of pixels are regarded as a theory of binary classification, and a hybrid 5D features for each pixel is put forward to extract retinal blood vessels from the background simplely and quickly. The 5D eigenvector includes Contrast Limited Adaptive Histgram Equalization (CLAHE), Gaussian matched filter, Hessian matrix transform, morphological bottom hat transform and Bar-selective Combination Of Shifted Filter Responses (B-COSFIRE). Then the fusion features are input into the Support Vector Machine (SVM) classifier to train a model that is needed. The proposed method is evaluated on two publicly available datasets of DRIVE and STARE, respectively. Se, Sp, Acc, Ppv, Npv, F1-measure are used to test the proposed method, and average classification accuracies are 0.9573 and 0.9575 on the DRIVE and STARE datasets, respectively. Performance results show that the fusion method also outperform the state-of-the-art method including B-COSFIRE and other currently proposed fusion features method.
- Machine learning /
- Retina /
- Vessel segmentation /
- Feature vetor /
- Support Vector Machine (SVM)

HTML全文

参考文献(15)

扬琴, 赵景秀. 基于主成分分析的血管分割算法[J]. 电子技术设计与应用, 2016, 3: 66-70.

YANG Qin and ZHAO Jingxiu. Blood vessel segmentation algorithm based on principal components analysis[J]. Electronics Design Application, 2016, 45(3): 66-70.

SINGH N P and SRIVASTAVA R. Retinal blood vessels segmentation by using Gumbel probability distributiaon function based matched filter[J]. Comput Methods Progr Biomed, 2016, 129(C): 40-50. doi: 10.1016/j.cmpb.2016.03. 001.

FRAZ M M, BASIT A, and BARMAN S A. Application of morphological bit planes in retinal blood vessel extration[J]. Digit Imaging. 2013, 26(2): 274-286. doi: 10.1007/s10278-012- 9513-3.

FRAZ M M, REMAGNINO P, HOPPE A, et al. Blood vessel segmentation methodologies in retinalimages-A survey[J]. Computer Methods and Programs Biomedicine, 2012, 108(1): 407-433. doi: 10.1016/j.cmpb.2012.03009.

吴奎, 蔡冬梅, 贾鹏, 等. 基于2D Gabor小波与组合线检测算子的视网膜血管分割[J]. 科学技术与工程, 2016, 16(12): 106-112.

WU Kui, CAI Dongmei, JIA Peng, et al. Retinal vessel segmentation based on 2D Gabor wavelet and combined line operators[J]. Science Technology and Engineering, 2016, 16(12): 106-112.

于辉, 王小鹏. 基于HESSIAN增强和形态学尺度空间的视网膜血管分割[J]. 计算机应用与软件, 2016, 33(8): 200-205.

YU Hui and WANG Xiaopeng. Retinal vessels segmentation based on Hessian enhancement and morphological scale space[J]. Computer Applications and Software, 2016, 33(8): 200-205.

WAHEED Z, AKRAM M U, WAHEED A, et al. Person identification using vascular and non-vascular retinal feature[J]. Computers and Electrical Engineering, 2016, 53: 359-371. doi: 10.1016/j.compeleceng.2016.03.010.

RICCI E and PERFETTI R. Retinal blood vessel segmentation using line operators and support vector classification[J]. IEEE Transactions on Medical Imaging, 2007, 26(10): 1357-1365. doi: 10.1109/TMI.2007.8985551.

FRAZ M M, REMAGNINO P, HOPPE A, et al. An ensemble classification-based approach applied to retinal blood vessel segmentation[J]. IEEE Transactions on Biomedical Engineering, 2012, 59(9): 2538-2548. doi: 10.1109/TBME. 2012.2205687.

AZZOPARDI G, STRISCIUGLIO N, VENTO M, et al. Trainable COSFIRE filters for vessel delineation with application to retinal images[J]. Medical Image Analysis, 2015, 19(1): 46-57. doi: 10.1016/j.media.2014.08.002.

STRISCIUGLIO N, AZZOPARDI G, VENTO M, et al. Supervised vessel delineation in retinal fundus images with the automatic selection of B-COSFIRE filters[J]. Machine Vision and Applications, 2016, 27(8): 1137-1149. doi: 10.1007 //s00138-016-0781-7.

ASLANI S and SARNEL H. A new supervised retinal vessel segmentation method based on robust hybrid feature[J]. Biomedical Singal Processing and Control, 2016, 30: 1-12. doi: 10.1016/j.bspc.2016.05006.
