Ka波段宽频带高线性空间行波管研制

黄明光; 朱丹; 何俊; 郝广凯; 李海强; 赵建东; 李现霞

doi:10.11999/JEIT161267

Ka波段宽频带高线性空间行波管研制

doi: 10.11999/JEIT161267

1.
(中国科学院电子学研究所北京 100190) ②(上海航天技术研究院804所上海 201109)

基金项目:

国家自然科学基金(61401430)

计量
- 文章访问数: 1467
- HTML全文浏览量: 147
- PDF下载量: 179
- 被引次数: 0
出版历程
- 收稿日期: 2016-11-24
- 修回日期: 2017-08-29
- 刊出日期: 2017-11-19

Development of Ka-band Broadband, High-linearity Space Traveling Wave Tube

1.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)
2.
(Shanghai Academy of Spaceflight Technology 804, Shanghai 201109, China)

Funds:

The National Natural Science Foundation of China (61401430)

摘要

摘要: 该文对Ka波段空间行波管宽频带、高线性、高效率的慢波系统进行设计，通过动态渐变技术实现了低相位失真、高效率的指标要求。在此设计基础上研制的Ka波段空间行波管实现了宽频带(25~27 GHz)、低非线性失真(非线性相移40 , AM/PM2.86/dB ，三阶交调10.39 dBc)、高效率(总效率51.7%)。经数传系统测试，误码pe优于10-6 的情况下C/N0有2.4 dB裕度，满足了卫星数传系统对多通道并行传输方案的工作需求。
- 空间行波管 /
- Ka波段 /
- 宽频带 /
- 高线性度
Abstract: In this paper, the design of Ka-band broadband, high-linearity and high-efficiency slow-wave system is proposed for Space Traveling Wave Tube (TWT). The dynamic phase-shifting technique is used to achieve low phase distortion and high efficiency. Based on this design, the Ka-band TWT is developed to realize wideband (25~27 ), low nonlinear distortion (non-linear phase shift40, AM / PM2.86/dB, third order intermodulation10.39 dBc), high efficiency (total efficiency51.7%). By the digital transmission system test, the error codepe is better than10-6 in the case ofC/N0 2.4 dB margin, it meets the satellite data transmission system for multi-channel parallel transmission program work requirements.
- Space Traveling Wave Tube (TWT) /
- Ka band /
- Wide bandwidth /
- High linearity

HTML全文

参考文献(11)

GOEBEL D M, ADLER E A, and MENNINGER W L. Efficient, highly linear traveling wave tube[P]. US. Patent 59428521999.

GOEBEL D M and ADLER E A. Optimally designed traveling wave tube for operation backed off from saturation [P]. U.S. Patent 59329711999.

ABE D K, LEVUSH B, ANTONSEN T M, et al. Design of a linear C-band helix TWT for digital communications experiments using the CHRISTINE suite of large-signal codes[J]. IEEE Transactions on Plasmas Science, 2002, 30(3): 1053-1062. doi: 10.1109/TPS.2002.801635.

HU X, WANG G, and LUO J R. A type of TWTA predistortion linearizer for space telecommunication applications[C]. IEEE International Conference on Wireless Communications, Networking and Information Security, Washington, DC, USA, 2010: 77-79.

GARY H, NISHIMURA T B, and IWATA N. A highly efficient linearized wide-band CDMA handset power amplifier based on predistortion under various bias conditions[J]. IEEE Transactions on Microwave Theory and Techniques, 2001, 49(6): 1194-1201. doi: 10.1109/22.925522.

WOLHLBIER J G, BOOSKE J H, and DOBSON I. Generation and growth rates of nonlinear distortions in a traveling wave tube[J]. Physics Review E, 2002, 66(5): 56504. doi: 10.1103/PhysRevE.66.056504.

WOLHLBIER J G, DOBSON I, and BOOSKE J H. The Multifrequency Spectral Eulerian (MUSE) model of a traveling-wave tube[J]. IEEE Transactions on Plasmas Science, 2002, 30(3): 1063-1075. doi: 10.1109/TPS.2002. 801603.

JOO Y D, SINHA A K, and PARK G S. Helix traveling wave tube performance optimization through circuit tapering[C]. The 30th International Conference on Plasmas Science, 2003: 176. doi: 10.1109/PLASMA.2003.1228635.

LI Li, FENG Jinjun, and CAI Shaolun. Experiment on TWT 3IM suppression using harmonic and IM3 injection[C]. IEEE International Vacuum Electronics Conference, Monterey, CA, USA, 2008: 105-106. doi: 10.1109/IVELEC.2008.4556474.

TSUTAKI K, YUASA Y, and MORIZUMI Y. Numerical analysis and design for high performance helix traveling wave tubes[J]. IEEE Transactions on Electron Devices, 1985, 32(9): 1842-1849. doi: 10.1109/T-ED.1985.22207.

VGENERON L. Ka band traveling wave tube[OL]. www. thalesgroup.com/components-subsystems, 2010.
