宽频带四端口馈源网络系统设计

王进; 杜彪; 焦永昌; 解磊

doi:10.11999/JEIT160918

宽频带四端口馈源网络系统设计

doi: 10.11999/JEIT160918

1.
(中国电子科技集团公司第五十四研究所石家庄 050081) ②(西安电子科技大学天线与微波技术重点实验室西安 710071)

基金项目:

国家重点基础研究发展计划(2013CB837902)，国家自然科学基金(11261140641)

计量
- 文章访问数: 2004
- HTML全文浏览量: 152
- PDF下载量: 413
- 被引次数: 0
出版历程
- 收稿日期: 2016-09-12
- 修回日期: 2017-02-15
- 刊出日期: 2017-06-19

Design of Broadband 4-port Feed Network System

1.
(The 54th Research Institute, China Electronic Science &
2.
(Science and Technology on Antenna and Microwave Laboratory, Xidian University, Xi&rsquo

Funds:

The National Basic Research Program of China (2013CB837902), The National Natural Science Foundation of China (11261140641)

摘要

摘要: 展宽现有卫星通信频段的带宽是增大通信容量的有效途径之一。为将C波段通信接收频段带宽展宽为3.625~4.800 GHz，发射频段展宽为5.850~7.025 GHz，该文设计了一种宽频带、结构紧凑、双线极化四端口馈源网络系统，通过采用宽带正交模耦合器与E面侧壁耦合T-接头宽带频率双工器，拓宽了馈源网络的工作带宽，由于该工作频带超过了标准波导的工作带宽，网络各部件的设计采取了非标波导，该文设计了八边形过渡波导解决了系统各部件在整个频带内的匹配问题。研发和测试了该馈源网络系统，测试与仿真结果吻合良好。实测结果表明，所有端口电压驻波比小于1.35，插入损耗小于0.5 dB，收发隔离度大于95 dB。
- 卫星通信 /
- 馈源网络 /
- 正交模耦合器 /
- 双工器 /
- 双线极化
Abstract: With the development of satellite communication technology, the demand for communication capacity is increasing. Broadening existing communication bandwidth is a key technology of satellite communication antenna. In order to extend the C band satellite communication, covering the receiving band 3.625~4.800 GHz and the transmitting band 5.850~7.025 GHz, a compact broadband four-port dual linear polarization feed network is designed. The broadband characteristics are achieved by employing a broadband orthomode transducer and two identical E-plane side coupling T-junction duplexers. The extended C band exceeds the bandwidth of a standard rectangular waveguide, so an octave bandwidth concept for compact waveguide transitions based on the use of octagonal-shaped sections is presented. A prototype of the feed network is developed. Simulated and measured results show good agreements. Measurements show that, this compact 4-port network provides Voltage Standing Wave Ratio (VSWR) better than 1.35 in all ports, insertion losses less than 0.5 dB, isolation Tx/Rx greater than 95 dB.
- Satellite communication /
- Feed network /
- Orthomode transducer /
- Diplexer /
- Dual linear polarization

HTML全文

参考文献(19)

易克初, 李怡, 孙晨华, 等. 卫星通信的近期发展与前景展望[J]. 通信学报, 2015, 36(6): 1-16. doi: 10.1109/j.issn.1000- 436x2015223.

YI Kechu, LI Yi, SUN Chenhua, et al. Recent development and its prospect of satellite communications[J]. Journal on Communications, 2015, 36(6): 1-16. doi: 10.1109/j.issn.1000- 436x2015223.

RAHMAT-SAMII Y and DENSMORE A C. Technology trends and challenges of antennas for satellite communication systems[J]. IEEE Transactions on Antennas and Propagation, 2015, 63(4): 1191-1204. doi: 10.1109/TAP. 2014.2366784.

齐述堂, 田哲民. 高性能C波段800 MHz带宽频谱复用馈源网络[J]. 无线电工程, 1998, 28(4): 1-4, 15.

QI Shutang and TIAN Zhemin. High-performance C band 800 MHz frequency reuse feed network[J]. Radio Engineering, 1998, 28(4): 1-4, 15.

GARCIA R, MAYOL F, MONTERO J M, et al. Circular polarization feed with dual-frequency OMT-based turnstile junction[J]. IEEE Antennas and Propagation Magazine, 2011, 53(1): 226-236. doi: 10.1109/MAP.2011.5773622.

UHER J, BORNEMANN J, and ROSENBERG U. Waveguide Components for Antenna Feed Systems: Theory and CAD[M]. Norwood, MA: Artech House, 1993: 284-299.

MONTEJO-GARAI J R, RUIZ-CRUZ J A, LEAL- SEVILLANO C A, et al. Modelling of dual-polarisation diplexers based on enhanced multiport turnstile junctions[J]. IET Microwaves, Antennas Propagation, 2013, 7(7): 485-492. doi: 10.1049/iet-map.2012.0424.

RAVANELLI R, CECCHINI P, MIZZONI R, et al. A K/Ka/EHF feed chain for dual-use telecom[C]. 2015 9th European Conference on Antennas and Propagation (EuCAP), Lisbon, Portugal, 2015: 1-5.

ROBERTS R, BOOTH P, FOX G, et al. Q/V-band feed system development[C]. 2016 10th European Conference on Antennas and Propagation (EuCAP), Davos Platz, Switzerland, 2016: 1-5. doi: 10.1109/EuCAP.2016.7481185.

TRIBAK A, CANO J L, MEDIAVILLA A, et al. Octave bandwidth compact turnstile-based orthomode transducer[J]. IEEE Microwave and Wireless Components Letters, 2010, 20(10): 539-541. doi: 10.1109/LMWC.2010.2060261.

VIRONE G, PEVERINI O A, LUMIA M, et al. Platelet orthomode transducer for-band correlation polarimeter clusters[J]. IEEE Transactions on Microwave Theory and Techniques, 2014, 62(7): 1487-1494. doi: 10.1109/TMTT. 2014.2325793.

VIRONE G, PEVERINI O A, LUMIA M, et al. W-band orthomode transducer for dense focal-plane clusters[J]. IEEE Microwave and Wireless Components Letters, 2015, 25(2): 85-87. doi: 10.1109/LMWC.2014.2373638.

张本全, 王锡良, 阮颖铮. Ku段波导双工器的研制[J]. 通信学报, 2004, 25(3): 161-166.

ZHANG Benquan, WANG Xiliang, and RUAN Yingzheng. Design of Ku-band waveguide diplexer[J]. Journal on Communications, 2004, 25(3): 161-166.

YUN S H, UHM M S, and YOM I B. Design of the multipaction free high power Ka-band diplexer with an E-plane T-junction[C]. 2005 Asia-Pacific Conference on Communications, Perth, Australia, 2005: 582-585. doi: 10.1109/APCC.2005.1554128.

ROSENBERG U, BRADT A, PERELSHTEIN M, et al. Extreme broadband waveguide diplexer design for high performance antenna feed systems[C]. Microwave Conference (EuMC), Paris, France, 2010: 1249-1252.

DE PAOLIS F, GOULOUEV R, ZHENG J, et al. CAD procedure for high-performance composite corrugated filters [J]. IEEE Transactions on Microwave Theory and Techniques, 2013, 61(9): 3216-3224. doi: 10.1109/TMTT.2013.2275451.

MEDIAVILLA A, CANO J L, and CEPERO K. On the octave bandwidth properties of octagonal-shaped waveguide mode transformers[J]. IEEE Transactions on Microwave Theory and Techniques, 2011, 59(10): 2447-2451. doi: 10.1109/TMTT.2011.2163077.
