基于不确定集的稳健MIMO雷达波形设计算法

李秀友; 薛永华; 黄勇; 关键

doi:10.11999/JEIT151425

基于不确定集的稳健MIMO雷达波形设计算法

doi: 10.11999/JEIT151425

基金项目:

国家自然科学基金(61471382, 61401495, 61501487, 61531020)，山东省自然科学基金(2015ZRA06052)

计量
- 文章访问数: 1167
- HTML全文浏览量: 128
- PDF下载量: 432
- 被引次数: 0
出版历程
- 收稿日期: 2015-12-14
- 修回日期: 2016-05-30
- 刊出日期: 2016-10-19

Robust MIMO Radar Waveform Design Algorithm Based on Uncertainty Set

Funds:

The National Natural Science Foundation of China (61471382, 61401495, 61501487, 61531020), The Natural Science Foundation of Shandong Province (2015ZRA06052)

摘要

摘要: 针对雷达目标回波信号存在不确定性导致MIMO雷达波形优化设计性能下降问题，该文提出一种扁平椭球不确定集约束下的稳健自适应发射-接收波形联合优化设计方法。首先将目标脉冲响应的误差推广到更为一般的扁平椭球不确定集约束条件，并利用Lagrange乘子法对优化过程进行推导，得出扁平椭球不确定集约束下的闭式表达式。其次为了提高目标脉冲响应不确定集范围较大时的优化性能，采用了迭代鲁棒最小方差法进行求解(IRMVB)，求得更为精确的目标脉冲响应，提高了SINR改善性能。然后进一步分析了基于扁平椭球不确定集约束条件与球体约束条件优化问题的内在联系，推导得出该文求解过程为广义对角加载方法。最后通过仿真实验表明所提算法对于目标回波信号不确定性具有更高的稳健性。
- MIMO雷达 /
- 波形设计 /
- 扁平椭球 /
- Lagrange函数
Abstract: In order to solve the problem of performance losses in the MIMO radar waveform design when target signal is uncertainty, a novel joint optimization of transmitting waveforms and receiving filters in the MIMO radar for the case of target in flat ellipsoid uncertainty set is proposed. Firstly, constraint of impulse response of target is extended to flat ellipsoid uncertainty set, Lagrange multiplier is used to solve the optimization problem, and the closed form solution is got under the constrain. Secondly, in order to improve SINR output of waveform design when the uncertainty set is large, Iterative Robust Minimum Variance Beamforming (IRMVB) is used to get more precise target impulse response. Thirdly, the relationship between flat ellipsoid uncertainty set and sphere uncertainty set is analyzed, and a solution which has the form of diagonal loading is derived. Finally, simulation results show that the proposed algorithm has excellent performance and it is robust for the uncertainty of impulse response of the target.
- MIMO radar /
- Waveform design /
- Flat ellipsoid /
- Lagrange function

HTML全文

参考文献(23)

ROMERO R A, BAE J, and GOODMAN N A. Theory and application of SNR and mutual information matched illumination waveforms[J]. IEEE Transactions on Aerospace and Electronic Systems, 2011, 47(2): 912-927.

JIU Bo, LIU Hongwei, ZHANG Lei, et al. Wideband cognitive radar waveform optimization for joint target radar signature estimation and target detection[J]. IEEE Transactions on Aerospace and Electronic Systems, 2015, 51(2): 1530-1546.

JIU Bo, LIU Hongwei, WANG Xu, et al. Knowledge-based spatial-temporal hierarchical MIMO radar waveform design method for target detection in heterogeneous clutter zone[J]. IEEE Transactions on Signal Processing, 2015, 63(3): 543-554.

SEN S. PAPR-constrained pareto-optimal waveform design for OFDM-STAP radar[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(6): 3658-3669.

SUN Shunqiao and PETROPULU A P. Waveform design for MIMO radars with matrix completion[J]. IEEE Journal of Selected Topic in Signal Processing, 2015, 9(8): 1400-1414.

纠博, 刘宏伟, 胡利平, 等. 针对目标识别的波形优化设计方法[J]. 电子与信息学报, 2009, 31(11): 2585-2590.

JIU Bo, LIU Hongwei, HU Liping, et al. A method of waveform design for the recognition of radar targets[J]. Journal of Electronics Information Technology, 2009, 31(11): 2585-2590.

AUBRY A, DE MAIO A, FARINA A, et al. Knowledge- aided (potentially cognitive) transmit signal and receive filter design in signal-dependent clutter[J]. IEEE Transactions on Aerospace and Electronic Systems, 2013, 49(1): 93-116.

AUBRY A, DE MAIO A, JIANG Bo, et al.. Ambiguity function shaping for cognitive radar via complex quartic optimization[J]. IEEE Transactions on Signal Processing, 2013, 61(22): 5603-5619.

HAYKIN S. Cognitive radar: a way of the future[J]. IEEE Signal Processing Magazine, 2006, 23(1): 30-40.

FATEMI M and HAYKIN S. Cognitive control: Theory and application[J]. IEEE Access, 2014, 2: 698-710.

SIRA S P, COCHRAN Do, SUPPAPPOLA A P, et al. Adaptive waveform design for improved detection of Low-RCS targets in heavy sea clutter[J]. IEEE Journal of Selected Topics in Signal Processing, 2007, 1(1): 56-66.

GARREN D A, OSBORN M K, ODOM A C, et al. Enhanced target detection and identification via optimised radar transmission pulse shape[J]. IEE Proceedings Radar, Sonar and Navigation, 2001, 148(3): 130-138.

HERBERT G M. Clutter modelling for space-time adaptive processing in airborne radar[J]. IET Radar, Sonar Navigation, 2009, 4(2): 178-186.

JIAN L, STOICA P, and WANG Z S. Doubly constrained robust capon beamformer[J]. IEEE Transactions on Signal Processing, 2004, 52(9): 2407-2423.

JIAN Li and STOICA P. On robust capon beamforming and diagonal loading[J]. IEEE Transactions on Signal Processing, 2003, 51(7): 1702-1715.

NAI S E, SER W, ZHU Liangyu, et al. Iterative robust minimum variance beamforming[J]. IEEE Transactions on Signal Processing, 2011, 59(4): 1601-1611.

LORENZ R G and STEPHEN P B. Robust Minimum Variance Beam forming[J]. IEEE Transactions on Signal Processing, 2005, 53(5): 1684-1696.

杜兰. 雷达高分辨距离像目标识别方法研究[D]. [博士论文], 西安电子科技大学, 2007.

DU Lan. Study on radar HRRP target recognition[D]. [Ph. D. dissertation], Xidian University, 2007.

CHEN Chunyang and VAIDYANATHAN P P. MIMO radar waveform optimization with prior information of the extended target and clutter[J]. IEEE Transactions on Signal Processing, 2009, 57(9): 3533-3544.

戴凌燕, 王永良, 李荣锋, 等. 基于不确定集的稳健Capon波束形成算法性能分析[J]. 电子与信息学报, 2009, 31(12): 2931-2936.

DAI Lingyan, WANG Yongliang, LI Rongfeng, et al. Performance analysis of robust capon beamforming based on uncertainty set[J]. Journal of Electronics Information Technology, 2009, 31(12): 2931-2936.
