一种基于MEMS芯片的新型地面大气电场传感器

杨鹏飞; 陈博; 闻小龙; 彭春荣; 夏善红; 郝一龙

doi:10.11999/JEIT150994

一种基于MEMS芯片的新型地面大气电场传感器

doi: 10.11999/JEIT150994

1.
(北京大学微米/纳米加工技术国家重点实验室北京 100871) ②(中国科学院电子学研究所传感器技术国家重点实验室北京 100190) ③(清华大学微电子学研究所北京 100084)

基金项目:

国家自然科学基金项目(61327810, 61201078)，国家自然科学基金重大仪器专项(61302032)

计量
- 文章访问数: 2369
- HTML全文浏览量: 282
- PDF下载量: 557
- 被引次数: 0
出版历程
- 收稿日期: 2015-09-06
- 修回日期: 2016-03-03
- 刊出日期: 2016-06-19

A Novel MEMS Chip-based Ground Atmospheric Electric Field Sensor

1.
(National Key Laboratory of Micro/Nano Fabrication Technology, Peking University, Beijing 100871, China)
2.
(State Key Laboratory of Transducer Technology, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)

Funds:

The National Natural Science Foundation of China (61327810, 61201078), The National Major Scientific Research Equipment Development of National Natural Science Foundation of China (61302032)

摘要

摘要: 该文基于MEMS电场敏感芯片，研制出了一种新型的地面大气电场传感器，解决了现有场磨式电场仪易磨损、功耗大、故障率高等问题。敏感芯片采用SOIMUMPS加工工艺制备，其芯片面积仅为5.5 mm5.5 mm。该文提出了传感器敏感芯片的弱信号检测方法，设计出了满足环境适应性的传感器整体结构方案，并建立了传感器的灵敏度分析模型。对电场传感器进行测试，测量范围为-50 kV/m~50 kV/m，总不确定度为0.67%，分辨力达到10 V/m，功耗仅为0.62 W。外场试验结果表明，MEMS地面大气电场传感器在晴天和雷暴天的电场探测结果，与Campbell公司场磨式电场仪探测结果都有较好的一致性，说明该传感器能满足预测雷暴要求，实现雷电监测和预警功能。
- 微机电系统 /
- 电场传感器 /
- MEMS地面大气电场传感器
Abstract: In this paper, a novel ground atmospheric electric field sensor based on MEMS electric field sensing chip is presented, which resolves the problems of motor wear, high power consumption and failure rate of the conventional electric field mill. The chip is fabricated in a commercial SOIMUMPS process, and the area of this chip is only 5.5 mm5.5 mm. A weak signal detection method for the chip is proposed. The sensor overall structure scheme is designed, and the sensitivity model is established. The minimum detectable electric field of the sensor is 10 V/m with an uncertainty of 0.67% in the range of -50 kV/m～50 kV/m, and its power consumption is only 0.62 W. The outdoor test shows that the plotted data of the sensor agrees well with those of USA Campbell field mill on both sunny days and thunderstorm days, which indicates that the developed sensor can meet the requirement of lighting monitoring and early warning.
- MicroElectroMechanical System (MEMS) /
- Electric field sensor /
- MEMS atmospheric electric field sensor on the ground

HTML全文

参考文献(18)

谢云云, 薛禹胜, 王昊昊, 等. 电网雷击故障概率的时空在线预警[J]. 电力系统自动化, 2013, 37(17): 44-51.

XIE Yunyun, XUE Yusheng, WANG Haohao, et al. Space-time early-warning of power grid fault probability by lightning[J]. Automation of Electric Power Systems, 2013, 37(17): 44-51.

MONTANYA J, BERGAS J, and HERMOSO B. Electric field measurements at ground level as a basis for lightning hazard warning[J]. Journal of Electrostatics, 2004, 60: 241-246.

KAPLAN Benzion. Duality of the electric covering field mill and the fluxgate magnetometer[J]. IEEE Transactions on Magnetics, 1998, 34(4): 2306-2315.

RIEHL P S, SCOTT K L, MULLER R S, et al. Electrostatic charge and field sensors based on micromechanical resonators[J]. Journal of Microelectromechanical Systems, 2003, 12(5): 577-589.

BAHREYNI B, WIJEWEERA G, SHAFAI C, et al. Analysis and design of a micromachined electric-field sensor[J]. Journal of Microelectromechanical Systems, 2008, 17(1): 31-36.

KONBAYASHI Takeshi, OYAMA Syoji, TAKAHASHI Masaharu, et al. Microelectromichanical systems-based electrostatic field sensor using Pb (Zr, Ti)O3 thin films[J]. Japanese Journal of Applied Physics, 2008, 47(9): 7533-7536.

PENG Chunrong, CHEN Xianxiang, BAI Qiang, et al. A novel high performance micromechanical resonant electrostatic field sensor used in atmospheric electric field detection[C]. Proc. 19th IEEE MEMS, Istanbul, Turkey, 2006: 698-701.

PENG Chunrong, YANG Pengfei, WEN Xiaolong, et al. Design of a novel micromachined non-contact resonant voltage sensor for power distribution systems[C]. IEEE Sensors, Valencia, Spain, 2014: 978-981.

闻小龙, 彭春荣, 方东明, 等. 基于共面去耦结构的空间三维电场测量方法[J] .电子与信息学报, 2014, 36(10): 2504-2508. doi: 10.3724/SP.J.1146.2013.01921.

WEN Xiaolong, PENG Chunrong, FANG Dongming, et al. Measuring method of three dimensional atmospheric electric field based on coplanar decoupling structrure[J]. Journal of Electronics Information Technology, 2014, 36(10): 2504-2508. doi: 10.3724/SP.J.1146.2013.01921.

WEN Xiaolong, FANG Dongming, PENG Chunrong, et al. Three dimensional electric field measurement method based on coplanar decoupling structure[C]. IEEE Sensors, Valencia, Spain, 2014: 582-585.

WEN Xiaolong, PENG Chunrong, FANG Dongming, et al. High performance electric field micro sensor with combined differential structure[J]. Journal of Electronics (China), 2014, 31(2): 143-150.

WANG Yu, FANG Dongming, FENG Ke, et al. A novel 2-dimensional electric field sensor based on in-plane micro rotary actuator[C]. IEEE Sensors, Valencia, Spain, 2014: 1924-1927.

杨鹏飞, 彭春荣, 张海岩, 等. SOI微型电场传感器的设计与测试[J].电子与信息学报, 2011, 33(11): 2771-2774. doi: 10.3724/SP.J.1146.2010.01285.

YANG Pengfei, PENG Chunrong, ZHANG Haiyan, et al. Design and testing of a SOI electric-field microsensor[J]. Journal of Electronics Information Technology, 2011, 33(11): 2771-2774. doi: 10.3724/SP.J.1146.2010.01285.

YANG Pengfei, PENG Chunrong, ZHANG Haiyan, et al.. A high sensitivity SOI electric-field sensor with novel comb-shaped microelectrodes[C]. 16th International Conference on Solid-State Sensors, Actuators Microsystems (Tranducers11), Beijing, China, 2011: 1034-1037.

YANG Pengfei, PENG Chunrong, FANG Dongming, et al. Design, fabrication and application of an SOI-based resonant electric field microsensor with coplanar comb-shaped electrodes[J]. Journal of Micromechanics and Microengineering, 2013, 23, 055002: 8pp.
