旋转的正交多点源反向交叉眼干扰分析

刘松杨; 董春曦; 董阳阳; 赵国庆; 艾小凡

doi:10.11999/JEIT150919

旋转的正交多点源反向交叉眼干扰分析

doi: 10.11999/JEIT150919

基金项目:

国家重大基础研究(973项目)(613181)

计量
- 文章访问数: 1512
- HTML全文浏览量: 105
- PDF下载量: 275
- 被引次数: 0
出版历程
- 收稿日期: 2015-08-15
- 修回日期: 2015-12-18
- 刊出日期: 2016-06-19

Analysis of Rotating Orthogonal Multiple Elements Retrodirective Cross-eye Jamming

Funds:

The National Basic Research Program (973 Program) of China (613181)

摘要

摘要: 针对干扰平台旋转或者在不同方向被探测的情况，该文提出正交多点源反向交叉眼方案，并对方案进行了严格的数学推导和理论分析，得出了角度偏差与其他影响因素的闭合解公式。闭合解公式为与传统两点源反向交叉眼和正交四点源反向交叉眼的对比和评估提供了数学依据，同时为优化方案性能提供了理论依据。通过对比分析了采用正交阵列和线性排布干扰单元的工程实践方法的数学本质。将稳定因数和系统在相同雷达指向角时的角度偏差作为衡量指标，对所提方案和以往的方案进行了数学和实例分析，突显了所提方案在产生稳定的角度偏差方面和产生有效的角度偏差方面的优越性。
- 电子战 /
- 角度欺骗 /
- 交叉眼干扰 /
- 反向阵 /
- 多点源
Abstract: In the case that the jammer platform rotates or is pointed in all different directions, a new scenario consisting of orthogonal multiple elements is presented, and then rigorous mathematical derivation and theoretic analysis are given for the new scenario. The closed-form solutions for angle error are derived, which is useful in mathematics for comparison and evaluation. Meanwhile, it provides theoretical references for optimizing the performance. Through comparisons, the nature of mathematics for orthogonal arrays and linear arrangement of jamming elements are proposed. Using stability factor and angle error that the systems in the same radar pointing angle as index, mathematics analysis and example are made to prove that the new scenario outperforms the conventional one in the aspect of stability and effectivity.
- Electronic warfare /
- Angular deception /
- Cross-eye jamming /
- Retrodirective arrays /
- Multiple elements

HTML全文

参考文献(23)

赵国庆. 雷达对抗原理[M]. 西安: 西安电子科技大学出版社, 1999: 169-183.

ZHAO Guoqing. Fundamentals of Radar Countermeasure[M]. Xian: Xidian University Press, 1999: 169-183.

唐琳, 焦淑红, 齐欢, 等. 一种单脉冲雷达多通道L1正则化波束锐化方法[J]. 电子与信息学报, 2014, 36(9): 2201-2206. doi: 10.3724/SP.J.1146.2013.01732.

TANG Lin, JIAO Shuhong, Qi Huan, et al. A new mono-pulse radar beam sharpening method with multichannel L1 regularization[J]. Journal of Electronics Information Technology, 2014, 36(9): 2201-2206. doi: 10.3724/ SP.J.1146.2013.01732.

李永祯, 胡万秋, 陈思伟, 等. 有源转发式干扰的全极化单脉冲雷达抑制方法研究[J]. 电子与信息学报, 2015, 37(2): 276-282. doi: 10.11999/JEIT140146.

LI Yongzhen, HU Wanqiu, CHEN Siwei, et al. Active repeater jamming suppression using polarimetric monopulse radar[J]. Journal of Electronics Information Technology, 2015, 37(2): 276-282. doi: 10.11999/JEIT140146.

田超, 文树梁. 干扰背景下基于双圆阵的全向测角方法[J]. 电子与信息学报, 2015, 37(7): 1751-1756. doi: 10.11999/ JEIT141137.

TIAN Chao and WEN Shuliang. Omni-directional angle measurement algorithm under interference with double circular arrays[J]. Journal of Electronics Information Technology, 2015, 37(7): 1751-1756. doi: 10.11999/ JEIT141137.

苏剑, 宋志勇, 付强, 等. 单脉冲雷达不可分辨目标与诱饵联合跟踪方法[J]. 雷达学报, 2015, 4(2): 160-171.

SU Jian, SONG Zhiyong, FU Qiang, et al. Joint tracking method for the unresolved decoy and target with monopulse radar[J]. Journal of Radars, 2015, 4(2): 160-171.

SHERMAN S M. Complex indicated angles applied to unresolved radar targets and multipath[J]. IEEE Transactions on Aerospace and Electronic Systems, 1971, 7(1): 160-170.

HOWARD D D. Radar target angular scintillation in tracking and guidance systems based on echo signal phase front distortion[C]. Proc. of NEC, 1959, 15: 840-849.

DUNN H J and HOWARD D D. Radar target amplitude, angle, and doppler scintillation from analysis of the echo signal propagating in space[J]. IEEE Transactions on Microwave Theory and Techniques, 1968, 9(9): 715-728.

LARS F. Cross-eye jamming of monopulse radar[C]. International Waveform Diversity and Design Conference, Pisa, Italy, 2007: 209-213.

HARWOOD N M, DAWBER N W, KING J D, et al. Multiple-element crosseye[J]. IET Radar, Sonar Navigation, 2007, 1(1): 67-73.

SHARP E D and DIAB M. Van atta reflector array[J]. IRE Transactions on Antennas and Propagation, 1960, 8(4): 436-439.

DUPLESSIS W P, ODENDAAL J W, and JOUBERT J. Extended analysis of retrodirective cross-eye jamming[J]. IEEE Transactions on Antennas and Propagation, 2009, 57(9): 2803-2806.

DUPLESSIS W P. A comprehensive investigation of retrodirective cross-eye jamming[D]. [Ph.D. dissertation], University of Pretoria, Pretoria, South Africa, 2010.

DUPLESSIS W P, ODENDAAL J W, and JOUBERT J. Tolerance analysis of cross-eye jamming systems[J]. IEEE Transactions on Aerospace and Electronic Systems, 2011, 47(1): 740-745.

DUPLESSIS W P Platform skin return and retrodirective cross-eye jamming[J]. IEEE Transactions on Aerospace and Electronic Systems, 2012, 48(1): 490-501.

DUPLESSIS W P. Limiting Apparent target position in skin-return influenced cross-eye jamming[J]. IEEE Transactions on Aerospace and Electronic Systems, 2013, 49(3): 2097-2101.

LIU Tianpeng, WEI Xizhang, and LI Lei. Multiple-element retrodirective cross-eye jamming against amplitude- comparison monopulse radar[C]. 2014 12th International Conference on Signal Processing (ICSP), Hangzhou, 2014: 2135-2140.

LIU Songyang, DONG Chunxi, XU Jin, et al. Analysis of rotating cross-eye jamming[J]. IEEE Antennas and Wireless Propagation Letters, 2015, 14: 939-942.
