基于迭代散射算法的柱体阵列散射场分析

刘起坤; 周东方; 邢锋; 雷雪; 余道杰

doi:10.11999/JEIT150167

基于迭代散射算法的柱体阵列散射场分析

doi: 10.11999/JEIT150167

基金项目:

国家自然科学基金(62101056)和国家863计划项目(2014AA01A707)

计量
- 文章访问数: 1164
- HTML全文浏览量: 110
- PDF下载量: 433
- 被引次数: 0
出版历程
- 收稿日期: 2015-01-29
- 修回日期: 2015-05-06
- 刊出日期: 2015-09-19

Analysis on Scattering Characteristics of Cylinder Array Based on Iterative Scattering Algorithm

摘要

摘要: 该文基于迭代散射算法(ISP)对柱体阵列的散射场进行分析。通过矢量柱面波函数展开，根据理想导体表面边界条件，建立柱体表面入射场与散射场的关系式。将前一次迭代时柱体阵列的近区散射场作为下一次迭代的入射场，推导出柱体阵列散射场系数间的迭代关系。通过分析不同迭代次数下2~4个柱体的散射场，确定3次迭代即可保证算法的准确度。对比数值结果表明，迭代散射算法具有与矩量法(MoM)结果同等的准确度，并具有明显优于矩量法的计算速度。
- 电磁散射 /
- 迭代散射算法 /
- 多次散射 /
- 柱体阵列 /
- 矩量法
Abstract: Based on Iterative Scattering Process (ISP) algorithm, the scattering characteristics of cylinder array are analyzed. The relationship between incident field and scattering filed can be evolved from the cylindrical harmonic functions under surface boundary condition of perfect conductor. With the previous iterative scattering fields among cylinders being the incident field next iteration, the coefficient relationship of scattering fields among cylinder array is derived. After analyzing the scattering fields of two or four cylinders within different iterations, it can be obtained that the calculated result of ISP algorithm keeps high accuracy with only three iterations. The results compared with numerical methods show that ISP algorithm and Method of Moments (MoM) agree well, whereas ISP algorithm has an observably faster calculated pace.
- Electromagnetic scattering /
- Iterative Scattering Process (ISP) algorithm /
- Multiple scattering /
- Cylinder array /
- Method of Moments (MoM)

HTML全文

参考文献(19)

程志华, 谢拥军, 樊君. 复杂目标的太赫兹波近场RCS快速计算[J]. 电子与信息学报, 2014, 36(8): 1999-2004.

Cheng Zhi-hua, Xie Yong-jun, and Fan Jun. Fast computation of near field RCS of complex objects in terahertz band[J]. Journal of Electronics Information Technology, 2014, 36(8): 1999-2004.

李晓峰, 谢拥军, 杨锐. 半空间电大导体目标散射的高频分析方法[J]. 电子与信息学报, 2009, 31(5): 1268-1270.

Li Xiao-feng, Xie Yong-jun, and Yang Rui. High-frequency analysis on scattering from conductive targets with electrically large size in half space[J]. Journal of Electronics Information Technology, 2009, 31(5): 1268-1270.

Nasr M A, Eshrah I A, and Hashish E A. Electromagnetic scattering from a buried cylinder using a multiple reflection approach: TM case[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(5): 2702-2707.

Wu Xiao-po, Shi Jia-ming, and Wang Jia-chun. Multiple scattering by parallel plasma cylinders[J]. IEEE Transactions on Plasma Science, 2014, 42(1): 13-19.

张会云, 刘蒙, 尹贻恒, 等. 基于格林函数法研究金属线栅在太赫兹波段的散射特性[J]. 物理学报, 2013, 62(19): 240-245.

Zhang Hui-yun, Liu Meng, Yin Yi-heng, et al.. Study on scattering properties of the metal wire gating in a THz band based on Green function method[J]. Acta Phasica Sinica, 2013, 62(19): 240-245.

Kim K T and Kramer B A. Direct determination of the T-matrix from a mom impedance matrix computed using the Rao-Wilton-Glisson basis function[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(10): 5324-5327.

Behnam Ghassemiparvin and Ayhan Altintas. Scattering from an impedance object at the edge of a perfectly conducting wedge[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(2): 852-861.

Ye Xiu-zhu, Chen Xu-dong, Yu Zhong, et al.. Simultaneous reconstruction of dielectric and perfectly conducting stutterers via T-matrix method[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(7): 3774-3781.

Cao Lei, Li Wei, and Hu Jun. A new T-matrix formulation for electromagnetic scattering by a radially multilayered gyroelectric sphere[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(2): 836-842.

Zhuromskyy O and Peschel U. T-matrix analysis of dipole waves on chains of dielectric particles[C]. 7th International Congress on Advanced Electromagnetic Materials in Microwaves and Optics-Metamaterials, Bordeaux, France, 2013: 268-270.

Tsang Leung and Chang Xin. Modeling of vias sharing the same antipad in planar waveguide with boundary integral equation and group T-matrix method[J]. IEEE Transactions on Components, Packaging and Manufacturing Technology, 2013, 3(2): 315-327.

Ozdemir N A, Ovejero D G, and Craeye C. On the relationship between multiple-scattering macro basis functions and Krylov subspace iterative methods[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(4): 2088-2098.

Desmal A and Ba c H. Shrinkage-thresholding enhanced born iterative method for solving 2D inverse electromagnetic scattering problem[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(7): 3878-3884.

Polewski M, Lech R, and Mazur J. Rigorous modal analysis of structures containing inhomogeneous dielectric cylinders[J]. IEEE Transactions on Microwave Theory and Techniques, 2004, 52(5): 1508-1516.

Kusiek A, Kowalczyk P, and Mazur J. Analysis of scattering from arbitrary conflguration of elliptical obstacles using T-matrix representation[J]. IET Microwaves, Antennas Propagation, 2008, 2(5): 434-441.

Adam Kusiek, Rafal Lech, and Jerzy Mazur. A new hybrid method for analysis of scattering from arbitrary conguration of cylindrical objects[J]. IEEE Transactions on Antennas and Propagation, 2008, 56(6): 1725-1733.
