一种基于最大似然估计的合作目标多维参数跟踪算法

魏子翔; 崔嵬; 李霖; 吴爽; 吴嗣亮

doi:10.11999/JEIT141150

一种基于最大似然估计的合作目标多维参数跟踪算法

doi: 10.11999/JEIT141150

基金项目:

上海航天科技基金(SAST201215)和新世纪优秀人才支持计划(NCET-13-0034)资助课题

计量
- 文章访问数: 1425
- HTML全文浏览量: 107
- PDF下载量: 547
- 被引次数: 0
出版历程
- 收稿日期: 2014-09-02
- 修回日期: 2014-12-02
- 刊出日期: 2015-06-19

Maximum Likelihood Estimation Based Algorithm for Tracking Cooperative Target

摘要

摘要: 空间交会对接微波雷达采用基于延迟锁定环(DDLL)、锁频环(FLL)和锁相环(PLL)的算法处理合作目标转发的直接序列扩频信号，获得入射信号的时延、频率及波达角(DOA)估计。针对当前基于DDLL, FLL和PLL(DFP)的算法没有充分利用接收信号有效信息的问题，该文提出一种基于极大似然估计(MLE)的低代价闭环跟踪(MLBT)算法。该算法利用代价函数的梯度正比于参数误差的特性，设计了参数误差鉴别器。在此基础上给出了相应的扩频信号多参数跟踪环路。分析并验证了鉴别器的方差特性，从而给出MLBT算法的参数估计均方根误差(RMSEs)下限。仿真实验验证了对MLBT算法参数估计均方根误差下限分析的正确性。此外仿真结果表明，MLBT算法相比DFP算法有限地增加运算量，同时获得了更优的参数估计性能。
- 雷达 /
- 直接序列扩频信号 /
- 时延 /
- 频率 /
- 波达角
Abstract: The scheme which is based on the Digital Delay Locked Loop (DDLL), Frequency Locked Loop (FLL), and Phase Locked Loop (PLL) is implemented in the microwave radar for spatial rendezvous and docking, and the delay, frequency and Direction Of Arrival (DOA) estimations of the incident direct-sequence spread spectrum signal transmitted by cooperative target are obtained. Yet the DDLL, FLL, and PLL (DFP) based scheme has not made full use of the received signal. For this reason, a novel Maximum Likelihood Estimation (MLE) Based Tracking (MLBT) algorithm with a low computational burden is proposed. The feature that the gradients of cost function are proportional to parameter errors is employed to design discriminators of parameter errors. Then three tracking loops are set up to provide the parameter estimations. In the following section, the variance characteristics of discriminators are investigated, and the low bounds of Root Mean Square Errors (RMSEs) of parameter estimations are given for the MLBT algorithm. Finally, the simulations and computational efficiency analysis are provided. The low bounds of Root Mean Square Errors (RMSEs) of parameter estimations are verified. Additionally, it is also shown that the MLBT algorithm achieves better performances in terms of estimators accuracy than those of the DFP based scheme with a limited increase in computational burden.
- Radar /
- Direct-sequence spread spectrum signal /
- Delay /
- Frequency /
- Direction Of Arrival (DOA)

HTML全文

参考文献(15)

耿生群, 吴嗣亮. 伪码连续波交会对接雷达信号处理机设计[J]. 现代雷达, 2006, 28(9): 37-41.

邓晓东, 孙武. 基于FLL+PLL的载波跟踪环路设计 [J]. 现代防御技术, 2010, 38(4): 137-141.

韩月涛, 吴嗣亮, 王堃, 等. 一种基于有限记忆算法的干涉仪解模糊纠错方法[J]. 宇航学报, 2012, 33(1): 120-127.

张群飞, 保铮, 黄建国. 一种水下多目标方位、频率、距离联合估计新方法[J]. 电子学报, 2004, 32(9): 1409-1413.

Michaela C V, Constantinos B P, and Arogyaswami P. Joint angle and delay estimation (JADE) for multipath signals arriving at an antenna array[J]. IEEE Communications Letters, 1999, 1(1): 12-14.

Alle-Jan V, Michaela C V, and Arogyaswami J P. Joint angle and delay estimation Using Shift-Invariance Properties[J]. IEEE Signal Processing Letters, 1997, 4(5): 142-145.

Stoica P and Gershman A B. Maximum-likelihood DOA estimation by data-supported grid search[J]. IEEE Signal Processing Letters, 1999, 6(10): 273-275.

Hosseini E and Perrins E. Timing, carrier, and frame synchronization of burst-mode CPM[J]. IEEE Transactions on Communications, 2013, 61(12): 5125-5138.

Bors A G and Ming Luo. Optimized 3D watermarking for minimal surface distortion[J]. IEEE Transactions on Image Processing, 2013, 22(5): 1822-1835.

Shawash J and Selviah D R. Real-time nonlinear parameter estimation using the LevenbergMarquardt algorithm on field programmable gate arrays[J]. IEEE Transactions on Industrial Electronics, 2013, 60(1): 170-176.

Pereira F H, Alves W A L, Koleff L, et al.. A two-level genetic algorithm for large optimization problems[J]. IEEE Transactions on Magnetics, 2014, DOI: 10.1109/TMAG.2013.2285703.

Gonzalez-Valdes B, Allan G, Rodriguez-Vaqueiro Y, et al.. Sparse array optimization using simulated annealing and compressed sensing for near-field millimeter wave imaging[J]. IEEE Transactions on Image Processing, 2014, 62(4): 1716-1722.

Huang Yung-dar and Barkat M. A dynamic programming algorithm for the maximum likelihood localization of multiple sources[J]. IEEE Transactions on Antennas and Propagation, 1992, 40(9): 1023-1030.

Parkinson B W and Spilker J J. Global Positioning System: Theory and Applications[M]. Washington DC: AIAA, Inc, 1996: 329-407.

Kay S M著. 罗鹏飞, 张文明, 刘忠, 等译. 统计信号处理基础估计与检测理论[M]. 北京: 电子工业出版社, 2006, 33-36.
