I2L和TTL型双边沿D触发器
I2L AND TTL TYPE DOUBLE-EDGE-TRIGGERED D-FLIP-FLOPS
-
摘要: 本文首先提出双边沿D触发器的系统设计方法,代替直观设计。接着用此法设计出I2L型和TTL型双边沿D触发器。
-
关键词:
- 双极型; 双边沿触发器; 系统设计方法
Abstract: This paper first presents a systematic procedure for designing double-edge-triggered D-flip-flops, instead of intuitive design, next, the double-edge-triggered D-flip-flops in the types of I2L and TTL are designed. -
Afghahi M, Yuan J. Double-edge-triggered D-flip-flop for high-speed CMOS circuits, IEEE J. of SC, 1991, SG26(8): 1168-1170.[2]Lu S L, Ercegovac M. A novel CMOS implementation of double-edge-triggered flip-Hops, IEEE J. of SC, 1990, SC-25(4): 1008-1010.[3]Unger S H. Double edege-triggered flip-flops, IEEE Trans. on Computer, 1981, 630(6): 447-451.[4]刘必虎,等编.中大规模集成电路原理与应用.上海:上海科学技术出版杜,1991,218-242.[5]阎石,主编.数字电子技术基础.北京:高等教育出版社,1989, 587-589. -
