在环型自由电子激光器中电子运动的混沌特性
CHAOTIC ELECTRON TRAJECTORIES IN A CIRCULAR FREE ELECTRON LASER
-
摘要: 本文分析了相对论性电子在环型摆动器磁场,轴向磁场和由非中性电子束产生的平衡自电场和自磁场中的运动。通过数值计算画出Poincare截面映射图,表明当自场足够强时,这种运动变成混沌的。虽然现实的环型摆动器场和自场一样使电子运动方程成为不可积的,但自场使运动产生混沌的作用要比摆动器场强。轴向磁场有抑制混沌发生的作用。
-
关键词:
- 环型自由电子激光器; 自场; 混沌
Abstract: The motion of a relativistic electron is analyzed in the field configuration consisting of a circular wiggler magnetic field, an axial magnetic field, and the equilibrium self-electric and self-magnetic fields produced by the non-neutral electron beam. By generating Poincare surface-of-section maps, it is shown that when the self-fields are strong enough, the electron motions become chaotic. Although the realistic circular wiggler field makes the equations of electron motion nonintegrable as the self-fields do, the effect of self-fields to cause the chaoticity is stronger than the wiggler field. The axial magnetic field can suppress the occurrence of chaoticity. -
Yin Y Z, Bekefi G. Phy[J].Fluids.1985, 28(4):1186-1192[2]Yin Y Z, Ying R J, Bekefi G. IEEE J. of Quantum Electron., 1987, QE-23(9): 1610-1616.[3]Saito H, Wurtelle J S. Phys, Fluids, 1987, 30(7):2207-2217.[4]Destler W W, Aghamir F M, Boyd D A, et al. Phys[J].Fluids.1985, 28(6):1962-1967[5]Chojnacki R, Destler W W. IEEE J. of Quantum Electron., 1987, QE-23(9): 1605-1609.[6]Mizuno T, Sekita H, Takagi K, et al. Nucl Instrum Methods in Phys. Res, 1992, A318(1～3): 749-753.[7]Chen C, Davidson R C. Phys[J].Fluids B.1990, 2(1):171-178[8]Michel-Lours L, Bourdier A, Buzzi J M. Phys[J].Fluids B.1993, 5(1～3):965-971[9]Spindler G, Renz G. Phys, Fluids B, 1991, 48(3): 2162-2171.[10]Hahn S J, Lee J K. Phys. Rev, E, 1993, 48(3): 2162-2171.[11]Lichtenberg A J, Lieberman M A. Regular and Stochastic Motion. New York: Springer, 1983, Ch.l a.nd Ch.5. -
