基于介质顶阵的到达角估计
DOA ESTIMATION BASED ON DIELECTRIC DOME ARRAY
-
摘要: 由于介质顶对来波的发散作用,到达平面阵的波是非平面波。本文研究基于介质顶阵的到达角(DOA)估计方法。通过对采样协方差矩阵进行远场近似(FFA)处理,用高分辨特征结构技术(MUSIc算法)进行DOA估计,得到了比较好的结果。计算机模拟结果证实了该方法的有效性。
-
关键词:
- DOA估计; MUSIC算法; 介质顶阵
Abstract: The performance of DOA estimation will be distorted in the presence of dielectric dome in the Dielectric Dome Array(DDA) because the dielectric dome diverge the planar wavefront into non-planar wavefront inside it. We proposed a far field approximation(FFA) method in this paper to improve the performance based on DDA. This method first reconstructs a FFA covariance matrix, which is Toplitz and approximate to the far field data covariance matrix, and then the high-resolution eigenstructure techniques can be utilized to estimate the DOAs without revising the planar wavefont assumption. Simulation results confirm the theoretical work. -
Schmidt R O. Multiple emitter location and signal parameter estimation. IEEE Trans. on Antenna and Propagation, 1986, AP-31(3): 231-236.[2]Roy R, Kailath T. ESPRIT-estimation of signal parameters via rotational invariance techniques. IEEE Trans. on ASSP, 1989, ASSP-37(7): 984-995.[3]Ziskind I, Wax M. Maximum likelihood location of multiple sources by alternaing projection. IEEE Trans. on ASSP, 1988, ASSP-36(11): 1553-1560.[4]Swindlehurat A, Kailath T. Azimuth/elevation direction finding using regular array geometries. IEEE Trans. on AES, 1993, AES-27(1): 145-156.[5]Stangel J J, Valenfine P A. The dome anntenna. Microwave Journal, 1975, 18(1): 31-34.[6]柴舜连,刘荧,姚德森,毛钧杰.介质共形顶相控阵的研究.电子学报,已录用.1997. 10. -
