数字图象几何变换的B样条算法和硬件实现
B SPLINE ALGORITHM FOR GEOMETRIC TRANSFORMATION OF DIGITAL IMAGE AND HARDWIRED IMPLEMENTATION
-
摘要: 本文提出了一种利用B样条函数进行数字图象几何变换的算法。在给定一组特殊的规则控制栅格点的条件下,构成B样条变换式。此变换算法保证给出的控制栅格点的准确对应,可得较高的精度。在小型图象处理系统中可用一种专用的变换解算装置来实现。 本文还提出开窗几何变换的自动实现。
-
关键词:
Abstract: In this paper, the algorithm of using B spline function for geometric transformation of digital image is presented. Given a group of special regular controlling points, B spline function for transformation is formed. The algorithm guarantees precise correspondence between controlling points, higher precision can be obtained. It can be implemented in a minicomputer digital image processing system with a special hard-wired device.This paper also points out that the geometric window transformation can be implemented automatically. -
杨世仁,计算机学报,3(1980), 54.[2]H. S. Hou and H. C. Andrews, IEEE Trans. on ASSP, ASSP-26(1978), 508.[3]M. T. Munteanu and L. L. Schumaker, J. Approximation Theory, 10(1974), 23.[4]R. T. Gregorg and D. L. Karney, A Collection of Matrices for Testing Computational Algerithms, New York: Wiley, 1969, p. 48.[5]刘其真等,自动化学报,8(1982),279. -
