Ka波段二次谐波回旋速调管放大器的PIC模拟

梁显锋; 刘濮鲲

Ka波段二次谐波回旋速调管放大器的PIC模拟

计量
- 文章访问数: 2439
- HTML全文浏览量: 104
- PDF下载量: 667
- 被引次数: 0
出版历程
- 收稿日期: 2004-01-05
- 修回日期: 2004-05-28
- 刊出日期: 2005-05-19

PIC Simulation of a Ka-Band Second Harmonic Gyroklystron Amplifier

摘要

摘要: 该文根据谐波回旋速调管放大器的注.波互作用特点,分析了放大器稳定工作的条件:对Ka波段二次谐波三腔回旋速调管放大器的注-波互作用进行了模拟计算,对放大器的注.波互作用电路参数进行了优化设计。模拟计算结果表明,在电子注电压为70kV,电子注电流15A,工作磁场为0.685T时,在35GHz频率放大器可以获得超过250kW的输出功率,大于21dB的增益,23%的效率和约为120MHz的带宽。计算结果为实际工程设计提供了有益的参考。
- 回旋速调管放大器; 电子回旋脉塞; 二次谐波; PIC模拟
Abstract: The conditions of the steady operation of the amplifiers are analyzed based on the characteristics of beam-wave interactions of harmonic gyroklystron amplifiers in this paper. The optimized design parameters of the circuit of the beam-wave interactions are obtained by simulation and calculation of the beam-wave interactions of a Ka-band, second harmonic, three cavities gyroklystron amplifier. The results show that this gyroklystron amplifier can produce an output peak power of over 250kW with more than 21dB gain and 23% maximum efficiency at 35GHz with a 70kV, 15A electron beam, and a 3dB bandwidth of about 120 MHz. This work is beneficial to the actual engineering design of the Ka-band second harmonic gyroklystron amplifier.
