聚甲基丙烯酸甲酯LB膜用作高分辨率电子束抗蚀层的研究
POLYMETHYLMETHACRYLATE LANGMUIR BLODGETT FILMS FOR HIGH RESOLUTION ELECTRON BEAM RESIST
-
摘要: 应用LB技术制备了厚度为20100nm的聚甲基丙烯酸甲酯(PMMA)超薄高分辨率电子束抗蚀层。应用改装的日立S-450扫描电子显微镜(SEM),研究了PMMALB膜的曝光特性和刻蚀条件。结果得到线宽0.15m的铝掩模光栅图形,表明此种超薄膜具有良好的分辨率和足够的抗蚀性。Abstract: Ultra-thin (20-100nm) polymethylmethacrylate (PMMA) films prepared by Langmuir-Blodgett techniques have been explored as high resolution electron beam resists. A Hitachi S-450 scanning electron microscope (SEM) has been refitted for a high resolution electron beam exposure system. The lithographic properties and exposure conditions of LB PMMA films were investigated. 0.15um lines-and-spaces patterns were achieved by using the SEM as the exposure tool. The results demonstrate that the etch resistance of such films is sufficiently good to allow patterning of a 20-nm aluminum film suitable for mask fabrication.
-
Bowden M J. Solid State Technol., 1981, 24(1): 73-79.[2]Barraud A. Thin Solid Films, 1983, 99(2): 317-321.[3]Broers A B, Pomerantz M. Thin Solid Films, 1983, 99(2): 323-329.[4]Kuan S W J, Frank C W, Yenlee Y H, et al. J. Vac[J].Sci Technol. .1989, 7(6):1745-1750[5]Miyashita T, Matsuda M. Thin Solid Films, 1989, 168(1): L47-L49.[6]Stroeve P, Srinnivasan M P, Higgins B G, et al. Thin Solid Films, 1987, 146(1): 209-220.[7]Knan S W J, Frank C W, Fu C C, et al. J. Vac[J].Sci. Teehnol. B.1988, 6(6):2274-2279[8]鲁武,顾宁,沈浩赢,等.东南大学学报,1994,24(1): 117-119. -
