单台相机机载InSAR基线动态测量方法研究
The Dynamic Measurement Scheme Based on Single Camera for the Airborne InSAR Baseline
-
摘要: 该文提出一种对机载干涉合成孔径雷达(InSAR)基线的动态测量方法。通过在机载InSAR天线上布设一定数量的控制点，采用单台内方位元素精确标定的数码相机对天线进行实时监测。基于实时控制点图像所建立的共线方程和后方交会算法，解算出相机测量坐标系与控制点辅助坐标系之间的转换参数。将转换参数代入待测点坐标方程后，计算得到天线中心在测量坐标系下的实时三维坐标。在实验室进行的静态和动态模拟实验取得较好结果，验证了该文提出的InSAR基线动态测量方案的可行性。Abstract: The dynamic measurement scheme based on single camera for the airborne InSAR baseline is described in this paper. In the above measurement scheme, the calibrated camera is mainly responsible for taking pictures on the pre-designed legends on the antennas of the InSAR system at a reasonable frequency. The 3D coordinates of the antenna phase centers are calculated by the collinear equations and backward intersection algorithm. The scheme is verified feasible by the static and dynamic tests.
-
Graham L C. Synthetic interferometric radar for topographic mapping[J].Proc. IEEE.1974, 62(6):763-[2]Peng Hailiang, Shao Yi-ming, Song Fu-ming, Wu Yi-rong, Wang Lei, Li Lan. DEM generation using L-band airborne SAR data,IGARSS 2000, Honolulu Hawaii, USA, 2000:764 - 766.[3]王磊,彭海良.重复飞行机载干涉SAR的实验研究[J].电子与信息学报.2002,24(12):1939-1946浏览[4]Wang Yan-ping, Peng Hai-liang. Locating calibrators in airborne InSAR calibration. IGARSS 2003, Toulouse, France. 2003:4515 - 4517.[5]彭海良,王彦平.机载合成孔径雷达干涉灵敏度分析.高技术通讯,2004,14(1):17-20.[6]冯文灏.近景摄影测量的基本技术提要.测绘科学,2000,25(4):26-30.[7]王保丰.计算机视觉工业测量系统的建立与标定.[硕士论文],郑州:解放军信息工程大学,2004.[8]李德仁,王新华.CCD阵列相机的几何标定.武汉测绘科技大学学报,1997,22(4):308-313.[9]李广云,倪涵,徐忠阳.工业测量系统.北京:解放军出版社,1994:89-151.[10]黄桂平.多台电子经纬仪/全站仪构成混合测量系统的研究与开发.[硕士论文],郑州:解放军信息工程大学,1999. -
