基于TCL的电路板原理图自动审查平台建设
An Auto-verification Platform for Schematic Design Based on TCL
-
摘要: 该文提出了一种用TCL语言作为审查脚本语言构造原理图审查系统的系统框架。在该系统中,利用TCL语言的扩展性,制定了一套应用于原理图通用数据结构的TCL扩展命令,并在此基础上构建原理图规则库和自动审查执行器,实现了原理图的自动审查。Abstract: In this paper, an auto-verification platform for schematic design is presented based on the extended TCL as a script language. Using the extensible property of the TCL, constructed a set of extended TCL command on the general data structure of the schematic design, and on this base, a rule library and an auto-verification runner are built to make the auto verification of the schematic design possible.
-
蔡固顺,饶勇,李玉山.电子自动化设计数据的标准格式问题.电子科技,1998,(6):18-21.[2]John Ousterhout. Tcl and the Tk Toolkit. Boston, MA: Addison-Wesley Publishing Company, 1993:2 - 389. -
