基于VI的机载SAR天线稳定平台ATS
An ATS Based on VI for Antenna Stabilization Platform of Airborne SAR
-
摘要: 该文简述了机载SAR天线稳定平台的工作原理，介绍了针对某型机载SAR天线稳定平台的新型自动化测试系统。该系统以PXI虚拟仪器为核心，使用二维电控转台模拟载机角运动，采用激光小角度测量方法测量平台响应误差。该机载SAR天线稳定平台测试系统可用于多种类型的机载SAR天线稳定平台测试。Abstract: This paper describes the principle of antenna stabilization platform of airborne SAR briefly, and then introduces an ATS(Automatic Test System) for such platform . The core of this system is a PXI VI(Virtual Instrument). The system uses an electro-controlling motion simulator to simulate the angle-motion of airplane and laser-test device to test the track error of the platform. It can be used for different types of antenna stabilization platform of airborne SAR.
-
张澄波. 合成孔径雷达的原理、系统分析及应用. 北京: 科学出版社, 1989: 299-235. [2] 张乐平. 虚拟仪器技术概论. 北京: 电子工业出版社，2003: 2-6.[2]PXI Specification，PXI System Alliance, 2000: 15-100.[3]张风均. LabWindows/CVI开发入门与进阶. 北京: 北京航空航天大学出版社，2001: 340-348.[4]TMS320VC5510 Fixed-Point Digital Signal Processor Data Manual，U.S.A，Texas Instrument，2000: 1-10. -
