伪码引信瞄准式欺骗性干扰及硬件实现
Jamming of Spot and Deception of Pseudo-Random Code Phase-Modulation Fuze and Hardware Implemented Circuit
-
摘要: 该文首先介绍了伪随机码调相引信的工作原理,提出了伪随机码调相引信瞄准式欺骗性干扰机方案,并给出了各部分电路的原理及硬件实现,主要包括伪码调相信号的解调、解调后的伪码序列的识别与重构、干扰波形的调制发射等关键部件。从各部分电路的试验结果来看,本设计原理正确,方案可行。Abstract: Firstly, the working principle of pseudo-random code phase-modulation fuze is described in the paper. The scheme of spot and deception jammer of pseudo-random code phase-modulation fuze is given. The circuit principle of each part and its hardware implemented circuit are presented. It includes mainly that demodulation of pseudo-random code phase-modulation signal ,recognition and reconstruction of demodulated code, modulation and transmission of interfered waveform .According to testing results of each part circuit, the designed principle is correct. The scheme is feasible.
