镍硅化物生成的TEM原位研究
STUDY OF THE FORMATION OF NICKEL SILICIDES IN SITU BY TEM
-
摘要: 蒸涂法获得的Si-Ni界面在室温到800℃下热处理,并用透射式电子显微镜对它进行原位研究。在化学清洗的洁净的Si(100)及(111)面上生成了Ni2Si,NiSi和NiSi2系列。实验表明,在真空度为110-6mmHg,温度为650℃时,化学清洗的Si表面上生成了SiC;各种镍硅化物的出现不是在某一确定温度;在Si(111)面上外延生长镍硅化物比在(100)面上容易。Abstract: The interface of Si-Ni produced by evaporation was annealed from room temperature to 800℃ and in situ studied by transmission electron microscopy (TEM). The formation of Ni2Si, NiSi and NiSi2 on chemically cleaned Si (100) and (111) surfaces has been investigated. On the basis of experimental results, SiC had been formed at 650℃ on such cleaned Si surface at 1x10-6 mmHg vaccum; the appearance of that series of nickel silicide were not at an exact temperature; and it would be easier to epitaxy silicides on Si (111) than (100) surface.
-
H. Foll, Philosophical Magazine A, 45(1982), 31-37.[2]Z. Liliental, et al., Thin Solid Films, 104(1983), 17-29.[3]F. Folk et al., J. Appl. Phys., 52(1981), 250-255.[4]D. Cherns, et al., Philosophical Magazine A, 49(1984), 165-177.[5]A. K. Sinha, et al., J. Appl. Phys., 43(1972),3637-3643.[6]Y. J. Chang.[J].et al.,J. Vacuum Sci. Tech, A1(1983.1193,:-[7]E. J, Loenen, et al., Appl. Phys. Lett., 45(1984), 41.[8]E. J. Loenen, et al., Surface Science, 154(1985), 52.[9]E. J. Loenen, et al., Surface Science, 157(1985), 1.[10]O. Nishikawa, et al., J. Vacuum Sci Tech., B2(1984), 21.[11]F.Comin, et al., Phy. Rev. Lett., 51(1983), 2402.[12]F. Comin, J, Vacuum Sci Tech., (13(1985), 930.[13]R.W. Bicknell, J. Phys. D: Appl. Phys., 6(1973), 1991-1997.[14]高铭台,电子科学学刊,9(1987), 420-427. -
