小型预警机主雷达天线的机体散射
Scattering of the main radar antenna fixed on mini-AWACS
-
摘要: 该文以一致性几何绕射理论(UTD)为基础,利用新提出的叠加模型对小型预警机主雷达相控阵天线的机体散射(包括螺旋桨散射)进行了分析,定量得出了这些散射的特点和变化规律,为天线装机后辐射性能预测与布局优化提供了理论依据。Abstract: Based on the Uniform Geometric Theory of Diffraction (UTD), the scattering of aircraft including propellers for the phased-array of the main radar is analysed by using of a new additive model of antenna. The variety and characteristic of the scattering is presented quantitatively. It can be used as a theoretical basis to dope out the radiation performance and optimize the arrangement of antennas.
-
J. B. Keller, Geometrical theory of diffraction, J. Opt. Soc. Am., 1962, 52(2), 116-130.[2]R.G. Kouyoumijan, P. H. Pathak, A uniform theory of diffraction for an edge in a perfectly conducting surface, Proc. IEEE, 1974, 62(11), 1448-1461.[3]B.N. Suresh Babu, T. P. Guella, Effect of antenna aircraft interaction on phased-array radar lerformance, IEEE National radar conference, Bedford, 1993, 102-106.[4]汪茂光,几何绕射理论,西安,西安电子科技大学出版社(第二版),1994年12月,第2,4,5章.[5]马凤国,刘其中,等,大口面天线机体散射效应分析,微波学报,1999,15(3),238-243. -
