毫米波鳍线-微带振荡器
MILLIMETER-WAVE FINLINE-MICROSTRIP OSCILLATOR
-
摘要: 本文介绍一种结构新颖,具有机械调谐功能的毫米波混合集成振荡器及其设计方法。振荡器由鳍线和微带线构成,以微带线作为输出端口。通过短路活塞的调节,振荡器有3.0CHz以上的机械调谐带宽,带内输出功率大于70mW。Abstract: A new millimeter-wave integrated oscillator and design method are introduced in this paper. By combining finline and microstrip transmission line, this oscillator has more than 3.0 GHz mechanical tuning bandwidth and over 70.0mW output power.
-
Rubin D. IEEE Trans. on MTT, 1976, MTT-24: 866-867.[2]Chang K, et al. IEEE Trans. on MTT, 1983, MTT-31: 146-154.[3]Singh D R. IEEE MTT-S Digest, 1987, 981-982.[4]Kim C, Dunnrowicz C, Crowley J, dank B. Microwave Journa1,1989, 4: 91-102.[5]Collin R E. Proc[J].IRE.1956, 44:539-548[6]Pramanick P, Bhartia P. IEEE MTT-S Digest, 1981, 248-286.[7]Mahon J P, Elliott R E. IEEE Trans. on MTT, 1990, MTT-38(10): 1415-1420.[8]王阳,沈楚玉.电子学报,1992,20(3):89-89.[9]薛泉,等.复杂渐变线的分析与综合,全国微波会议论文集.合肥:1993年10月,217-222. -
