并行角馈双极化微带天线阵的分析与设计
ANALYSIS AND DESIGN OF A DUAL-POLARIZED MICROSTRIP ANTENNA ARRAY WITH PARALLEL CORNER FEEDING
-
摘要: 本文提出利用双端口的并行角馈实现双极化天线,并设计了一种新的双极化馈线网络。综合运用了多端口网络模型、腔模理论、分片法和补片法,给出了各天线单元和双极化馈线网络的理论分析方法。实际设计了一副6GHz频段的单层共面的四元天线阵,实测的双端口隔离度达-50dB,其性能明显优越于通常的单层双极化微带天线阵列。Abstract: In this paper, parallel corner feeding with two ports is proposed to realize the high isolation, dual-polarized microstrip antenna. A novel dual-polarized feedline network is designed for the array. A method of analysis is developed, which is based on the multiport network model, the cavity theory, the segmentation technique and the desegmentation technique. A one-layer coplanar microstrip antenna array at 6GHz band is designed. The measured isolation between two feeding ports reaches -50dB, which is much better than those of one-layer dual-polarized arrays commonly used.
-
James J R, Hall P S, Wood C. Microstrip antenna theory and design, London: Peter Peregrinus Ltd, 1981, 166-167.[2]Tolt L J, Closte J H. Dual polarized linear microstrip patch array, IEEE AP-S Symposium, Blacksburg, VA: June, 1987, 810-813.[3]钟顺时.微带天线理论与应用，西安，西安电子科技大学出版社，1991, 第一、四章.[4]刘俊.极化捷变有源微带天线:[硕士论文].上海:上海大学通信工程系,1998.[5]Murakami Y, et al. Slot-coupled self-duplexing array antenna for mobile satellite communication,[6]IEE Proc. Microwave Ant. Propag, 1996, 143(2): 119-123.[7]Gupta K C. Multiport network modeling approach for computer-aided design of microstrip patches and arrays, IEEE AP-S Symposium, U.S.A: 1987, 786-789.[8]Gupta K C, Garg R, Bahl I J. Microstrip lines and slotlines, Dedham, MA: Artech House, 1979 Chapter 2. -
