单元方向可控自适应圆阵的理论研究
THE ELEMENT PATTERN-STEERABLE ADAPTIVE CIRCULAR ARRAYS
-
摘要: 本文采用一种振子型合成元作为阵元组成圆阵天线,通过一组加权,可控制阵中所有的元方向图型都指向预先任意规定的相控方向。这在全向范围内,任何方向都能形成强定向波束,以有效地获取有用信号。在此基础上,本文通过引入等效干扰源的概念,把Gabriel的各向同性元自适应直线阵理论扩展应用到有向元圆阵,对单元方向可控自适应圆阵专题进行了研究。它包括:阵远区辐射图型;单元方向可控圆阵系统输入协方差矩阵的导出;单元方向可控自适应圆阵辐射图型正交分解;阵系统输出噪声瞬态特性公式。
-
关键词:
Abstract: In this paper the element pattern-steerable adaptive circular arrays are described. The element consists of three-orthogonal dipoles. All the element radiation patterns in the array can be steered by a set of weightings to point to an arbitrary specified direction. Thus a high directional beam in an arbitrary directional position within a 3-dimensional space can be formed to capture a desired signal effectively. On the above basis the techniques of the adaptive linear array of uniformly spaced isotropic element investigated by W.F.Gabriel are generalized to the special topic of the element patternsteerable adaptive circular arrays by means of the concept of equivalent interference source. This paper discusses following theoretical aspects of the said arrays: the array farzone radiation field, the direction-controlled weighting factors of the element radiation pattern, the covariance matrix of the set of system inputs, the orthogonal resolution of the array output pattern, the transient characteristic for total output noise power of the array system. -
W. F. Gabriel, Proc. IEEE, 64(1976), 239.[2]S. P. Applebaum, IEEE Trans. on AP, AP-24(1976),585.[4]B. D. Steinberg, Principles of Aperture and Array System Design, John Wiley sons, Inc.,(1976), chapter 12.[5]刘振威,电子学通讯,2(1980), 54.[6]刘振威,电子学通讯,1(1979), 163.[7]刘振威,电子学通讯,1(1979), 118.[10]A. E. Bryson.[J].Jr. and Yu-chi Ho, Applied Optimal Control, John Wiley Sons.1975,:-
