七级偏转象差中的Trilemma效应
THE TRILEMMA EFFECT IN SEVENTH-ORDER DEFLECTION ABERRATION
-
摘要: Trilemma效应是偏转系统实现自会聚的一个重要判据,对高级偏转象差的校正,需要考虑高阶Trilemma效应的影响,本文从多极场偏转象差校正理论出发,应用区域分割的方法,对直至七阶的Trilemma效应进行了分析,给出了各阶Trilemma常数的表达式,其中七阶Trilemma常数可以作为大偏转角偏转象差校正的判据。Abstract: Trilemma effect is an important criteria for the self-convergence deflection system. The influence of the higher order Trilemma effects should be taken into account for the correction of the higher-order deflection aberrations. In this paper, up to the seventh-order Trilemma effects are analyzed with region-cutting by means of the correction theory of the multipole field deflection aberration. The expressions of the various order of Trilemma constant are given, in which the seventh-order Trilemma constant can be used as a criteria of the deflection aberration correction at large deflection angle
-
Ando K, Hirota R, Akatsu M, Maruyama K. New selfconvergence yoke and picture tube system with 110 in-line feature. IEEE Trans. on CE. 1977, CE-23(3): 375-382.[2]Dasgupta B B. Is the Dilemma rule useful for designing deflection yoke used in color picture tubes?. Proc. SID, 1984, 25(2): 99-104.[3]丁守谦.磁偏转线圈设计理论基础.北京:国防工业出版社,1994,137-140.[4]Seyno Sluyterman A A. Fifth-order Trilemma in deflection yoke design. Proc. SID. 1987, 28(1):[5]9-13.[6]张晓兵,等.偏转象差中束夹角的高次方项研究.真空科学与技术学报,1996, 16(4): 257-262.[7]Heijnemans W A L. The deflection coils of the 30AX colour-picture system. Philps Tech. Rev, 1979, 39(6/7): 154-171.[8]张晓兵,等.大偏转角偏转象差的分析与校正.东南大学学报,1996,26(3):19-23.[9]张晓兵,等.七级偏转象差的多极场分析与校正.真空科学与技术学报,1996,16(2):73-80.[10]张晓兵.大偏转角偏转象差校正理论研究与多磁极自会聚偏转系统计算机辅助设计:[博士论文].南京:东南大学电子所,1996, 75-102. -
