毫米波同轴-波导二极管管座计算机模拟分析
ANALYSIS OF MILLIMETER WAVE COAXIAL-WAVEGUIDE DIODE MOUNT WITH COMPUTER SIMULATION
-
摘要: 本文从理论上分析了构成功率合成器的主要组件横向耦合同轴-波导二级管管座的结构,建立了它的等效电路模型。并且通过计算机模拟分析,得到腔体短路位置l4。失配负载Z1及其位置l1。腔体输出负载Z3及其位置l3、同轴线内导体半径r以及同轴线段之间的距离等参量与功率比的关系。根据此结果给出毫米波合成器设计的最佳方案。模拟分析已为实验结果所证实。
-
关键词:
Abstract: A theoretical analysis is given in this paper to the structure of a cross-coupled coaxial-waveguide diode mount--a major module of power combiner. The equivalent circuit isobtained. It is shown by computer simulation that the shorted out position l4 of a cavity can be determined and the power ratio is related to the mismatched load z1, to the output impedance z3 of cavity and their position l1 and l3, to the radius r of inner conductor of a coaxial line and to the distance between coaxial lines. According to these results, a optimum design of millimeter wave combiner is discussed proved by expriments. -
R. L. Eisenhart et. al., IEEE Trans. on MTT,MTT-26(1978), 170.[2]L. Lewin, Proc. IEE Monogr. 259R, 109.[3]沈秀英,华东师范大学学报,1985年第1期,第55页.
