基于深度信息的立体视频错误隐藏方法
doi: 10.3724/SP.J.1146.2011.01107
Error Concealment Based on Depth Information for Stereoscopic Video Coding
-
摘要: 针对双视加深度结构的立体视频的网络传输,该文提出了解码端的错误检测和错误隐藏技术。结合深度信息对发生错误宏块的编码模式进行估计,在错误宏块周围相邻宏块的编码模式不一致时,选择邻近宏块中深度与待重建的错误宏块深度最为接近的宏块的编码模式作为其编码模式。然后,根据编码模式选择用视点内或视点间的相关性信息重建错误宏块。实验结果表明采用该方法重建的图像客观质量峰值信噪比(PSNR)较传统的边界匹配错误隐藏方法提高了0.8-6.0 dB,并且主观质量也有提升。Abstract: An improved error detection method and a novel Error Concealment (EC) algorithm at the decoder for color plus depth formatted stereoscopic video transmission are presented. The encoding mode of the corrupted macroblock is predicted by the adjacent macroblocks and depth information. In the case that the encoding modes of macroblocks around the corrupted one are inconsistent, the encoding mode of the erroneous macroblock is predicted by the adjacent macroblock whose depth value is closest to that of the corrupted one. According to the encoding mode, the corrupted macroblock is reconstructed by intra-view or inter-view correlation. The experimental results show that the proposed EC algorithm provides 0.8-6.0 dB quality improvement of PSNR against the conventional Boundary Matching Algorithm (BMA) and achieves better subjective quality.
-
Key words:
- Stereoscopic video coding /
- H.264 /
- Error Concealment (EC) /
- Depth image
