多波束回波信号可变带宽滤波算法及其FPGA实现
doi: 10.3724/SP.J.1146.2011.00339
Variable Bandwidth Filtering Algorithm for Multi-beam Seafloor Echo and Its Implementation on FPGA
-
摘要: 噪声是限制多波束测深声呐深度估计精度的重要因素，目前在声呐系统中广泛采用的噪声抑制方法是固定带宽滤波。针对测量扇面内不同方向上噪声影响程度不同的特点，该文提出一种新的可变带宽滤波算法并依据多波束回波特性设计了相应的滤波器，与传统滤波方法相比，可以有效地提高信噪比，并且运算量小；其滤波算法结构非常有利于 FPGA的快速实现。文中给出了该滤波算法的FPGA实现结构，并仿真验证了该滤波算法的工程可行性。对湖上试验数据的处理结果验证了该算法的有效性。Abstract: In multi-beam bathymetric sonar, noise is one of the most important disadvantageous factors that restrict the estimation precision. Fixed bandwidth filter is currently widely used to suppress noise in sonar systems. On the measuring swath, the impact of noise varies with the beam angle. Considering this issue, an algorithm of variable bandwidth filter is proposed and its parameters are given in the paper. Compared with traditional method, this algorithm can not only improve the SNR but also have less computation and the structure is suitable for fast realization on FPGA. The realization structure of the algorithm is given and the engineering possibility is proved by computer simulation. The processing results of experimental data on lake prove the effectiveness of the proposed algorithm.
-
Key words:
- Signal processing /
- Multi-beam bathymetric sonar /
- Variable bandwidth filter /
- Noise
-
Lurton X. Swath bathymetry using phase difference: theoretical analysis of acoustical measurement precision [J].IEEE Journal of Oceanic Engineering.2000, 25(3):351-363[6]Masnadi-Shirazi M A, De Moustier C, Cervenka P, et al.. Differential phase estimation with the SeaMARC Ⅱ bathymetric sidescan sonar system [J].IEEE Journal of Oceanic Engineering.1992, 17(3):239-251[9]么彬. 多子阵波束域高分辨水声成像技术研究[D]. [博士论文],哈尔滨工程大学, 2009.[11]张毅乐. 多波束相干测深技术研究及其算法DSP实现[D]. [硕士论文], 哈尔滨工程大学, 2010.[13]胡广书. 数字信号处理: 理论、算法与实现[M]. 第2版, 北京:清华大学出版社, 2008: 326-327.[17]周天. 超宽覆盖海底地形地貌高分辨探测技术研究[D]. [博士论文], 哈尔滨工程大学, 2005.[19]曲少波. 基于并行流水线结构的可重配FIR滤波器的FPGA实现[J].国外电子元器件.2007, (3):65-67 -
