DBF-SAR系统1 bit量化的可行性分析

黄杰文; 祁海明; 李杨; 禹卫东

doi:10.3724/SP.J.1146.2010.00928

DBF-SAR系统1 bit量化的可行性分析

doi: 10.3724/SP.J.1146.2010.00928

基金项目:

中国科学院优秀博士论文院长奖获得者专项基金(0813260042)和微波成像技术国家重点实验室基金(9140C1903041003)资助课题

计量
- 文章访问数: 3408
- HTML全文浏览量: 123
- PDF下载量: 886
- 被引次数: 0
出版历程
- 收稿日期: 2010-08-31
- 修回日期: 2010-12-07
- 刊出日期: 2011-05-19

The Feasibility Analysis of One-bit Quantization for DBF-SAR

摘要

摘要: 该文针对DBF-SAR系统数据率巨大的问题，研究了在低信噪比条件下1 bit量化的可行性。提出了两种信号处理方法：(1)回波1 bit量化；(2)回波和距离向匹配滤波器都1 bit量化。通过理论分析和仿真验证，1 bit量化的两种处理方法均能正确反映出目标位置及散射特性，不影响图像空间分辨率，但会产生虚假目标并抬升旁瓣，且虚假目标幅度随着回波信噪比的升高而增大。因此仅在单通道回波信噪比低于5 dB左右时使用1 bit量化才有意义。
- 合成孔径雷达 /
- 数字波束形成 /
- 扫描接收 /
- 1 bit量化 /
- 信噪比
Abstract: Considering the issue of huge data rate in DBF-SAR system, the feasibility of one-bit quantization under low signal-to-noise ratio condition is analyzed by two methods. In the first method, each sample of echo is quantized into one bit, while in the second, samples of both echo and range matched filter are quantized into one bit. Theoretical analysis and numerical experiments indicate that, both methods can correctly get the positions and scattering characteristic of targets, and keep the spatial resolutions. However, false targets and high side lobe are generated, and false targets become more obvious with higher SNR. Therefore, one-bit quantization is feasible when single channel echos SNR is lower than 5 dB.
- SAR /
- Digital BeamForming (DBF) /
- Scan-on-receive /
- One-bit quantization /
- SNR

HTML全文

参考文献(1)

Pitz W and Miller D. The TerraSAR-X satellite[J]. IEEE Transactions on Geoscience and Remote Sensing, 2010, 48(2): 615-622.[2] 马仑, 廖桂生, 李真芳. 多通道SAR误差估计与补偿方法及其实测数据验证[J]. 电子与信息学报, 2009, 31(6): 1305-1309.Ma Lun, Liao Gui-sheng, and Li Zhen-fang. An approach for multi-channel SAR array error compensation and its verification by measured data[J]. Journal of Electronics Information Technology, 2009, 31(6): 1305-1309.[3] Wang Wen-qin. Near-space wide-swath radar imaging with multiaperture antenna[J]. IEEE Antennas and Wireless Propagation Letters, 2009, 8(1): 461-464.[4] Suess M and Wiesbeck W. Side-looking synthetic aperture radar system[P]. German, EP 1241487A1, 2002.[5] Krieger G, Gebert N, and Moreira A. Multidimensional waveform encoding: a new digital beamforming technique for synthetic aperture radar remote sensing[J]. IEEE Transactions on Geoscience and Remote Sensing, 2008, 46(1): 31-46.[6] Younis M, Huber S, and Patyuchenko A, et al.. Performance comparison of reflector and planarantenna based digital beam-forming SAR[J]. International Journal of Antennas and Propagation, 2009, 2009(1): 1-13.[7] Ossowska A. One-bit quantization for synthetic aperture radar with DBF[C]. European Conference on Synthetic Aperture Radar, Friedrichshafen, Germany, 2008, 3: 37-40.[8] Schaefer C, Fischer C, and Vlker M. One-bit digitization for DBF-SAR: too good to be true[C]. European Conference on Synthetic Aperture Radar, Friedrichshafen, Germany, 2008, 3: 23-26.[9] Franceschetti G, Pascazio V, and Schirinzi G. Processing of signum coded SAR signal: theory and experiments[J]. IEE Proceedings-F, 1991, 138(3): 192-198.[10] Alberti G, Franceschetti G, and Pascazio V, et al.Time-domain convolution of one-bit coded radar signals[J]. IEE Proceedings-F, 1991, 138(5): 438-444.[11] Gebert N, Krieger G, and Moreira A. Digital beamforming on receive: techniques and optimization strategies for high-resolution wide-swath SAR imaging[J]. IEEE Transactions on Aerospace and Electronic Systems, 2009, 45(2): 564-592.[12] Krieger G, Gebert N, and Moreira A. Unambiguous SAR signal reconstruction from nonuniform displaced phase center sampling[J]. IEEE Geoscience and Remote Sensing Letters, 2004, 1(4): 260-264.
