二阶运动补偿对低频超宽带SAR视线误差补偿的影响

李建阳; 常文革; 黎向阳

doi:10.3724/SP.J.1146.2010.00812

二阶运动补偿对低频超宽带SAR视线误差补偿的影响

doi: 10.3724/SP.J.1146.2010.00812

李建阳^{* 常文革黎向阳,},
常文革,
黎向阳

计量
- 文章访问数: 3571
- HTML全文浏览量: 106
- PDF下载量: 687
- 被引次数: 0
出版历程
- 收稿日期: 2010-08-05
- 修回日期: 2011-01-25
- 刊出日期: 2011-04-19

Second-order Motion Compensation Effects on Light of Sight Error Compensation in Low-frequency Ultra Wide-band SAR

Li Jian-Yang^{* 常文革黎向阳
,},
Chang Wen-Ge,
Li Xiang-Yang

摘要

摘要: 视线误差补偿是低频超宽带合成孔径雷达(UWB SAR)成像处理的关键，该文主要研究基于测量数据的距离空变视线误差补偿，即二阶补偿。标准的二阶补偿在推导的过程中，对回波进行了一定的近似，认为距离空变视线误差对回波距离迁徙校正(RCMC)没有影响，而这个近似条件，在低频超宽带SAR中是不满足的。针对这个问题，该文对二阶补偿在低频超宽带SAR中的应用进行了分析，研究了3种二阶补偿方法，即：二阶补偿位于RCMC之后完成；二阶补偿位于RCMC之前完成；沿距离向划分子带进行二阶补偿。文中对3种二阶补偿方法进行了对比分析，并对每种补偿方法中存在的误差进行了分析。最后采用仿真以及实测低频超宽带SAR数据验证了文中分析的正确性。
- 低频超宽带SAR /
- 距离空变 /
- 二阶运动补偿 /
- 距离迁徙校正
Abstract: The MOtion COmpensation (MOCO) of Light Of Sight (LOS) error is very important in low-frequency Ultra Wide-Band Synthetic Aperture Radar (UWB SAR). In this paper, the second-order MOCO is studied which compensate the range-variant component of LOS error. In second-order MOCO, the assumption that there is no effect of range-variant LOS error on the Range Cell Migration Correction (RCMC) is supposed, which is not satisfied in UWB SAR. This paper analyzes the application of the second-order MOCO in low-frequency UWB SAR. Three methods which can be applied to compensate the range-variant LOS error are presented. First method implements the second-order MOCO after RCMC, second method implements it before RCMC, and the last method implements it in sub-band which is split along range direction. The three methods are compared and analyzed in this paper. Finally, the effectiveness of theoretical analysis is validated with simulation and real low-frequency UWB SAR data.
- Low-frequency ultra wide-band SAR /
- Range-variant /
- Second-order motion compensation /
- Range Cell Migration Dorrection (RCMC)

HTML全文

参考文献(1)

Moreira A and Huang Y H. Airborne SAR processing of highly squinted data using a chirp scaling approach with integrated motion compensation[J]. IEEE Transactions on Geoscience and Remote Sensing, 1994, 32(5): 1029-1040.[2] Fornaro G. Trajectory deviations in airborne SAR: analysis and compensation[J]. IEEE Transactions on Aerospace and Electronic Systems, 1999, 35(3): 997-1009.[3] Potsis A, Reigber A, Mittermayer J, Moreira A, and Uzunoglou N. Sub-aperture algorithm for motion compensation improvement in wide-beam SAR data processing[J]. IEEE Electronic Letters, 2001, 37(23): 1405-1406.[4] Macedo K A C and Scheiber R. Precise topography and aperture-dependent motion compensation for airborne SAR[J]. IEEE Geoscience and Remote Sensing Letters, 2005, 2(2): 172-176.[5] 薛国义, 周智敏, 赖涛. 宽波束角大测绘带UWB SAR的子孔径子带运动补偿算法[J]. 宇航学报, 2008, 29(3): 1008-1014.Xue Guo-yi, Zhou Zhi-min, and Lai Tao. An improved sub-aperture sub-patch motion compensation algorithm for UWB SAR[J]. Journal of Astronautics, 2008, 29(3): 1008-1014.[6] 李燕平, 邢孟道, 保铮. 结合非线性CS算法的UWB SAR运动补偿[J]. 系统工程与电子技术, 2007, 29(4): 514-519.Li Yan-ping, Xing Meng-dao, and Bao Zheng. Motion compensation for ultra wide-band SAR based on nonlinear chirp scaling algorithm[J]. Systems Engineering and Electronics, 2007, 29(4): 514-519.[7] 李建阳, 常文革, 王亮, 李悦丽. 机载UWB SAR实时信号处理算法研究[J]. 国防科技大学学报, 2010, 32(1): 57-62.Li Jian-yang, Chang Wen-ge, Wang Liang, and Li Yue-li. Real-time processing of airborne ultra-wide band SAR[J]. Journal of National University of Defense Technology, 2010, 32(1): 57-62.[8] 王亮. 基于实测数据的机载超宽带合成孔径雷达信号处理技术研究[D]. [博士论文], 国防科学技术大学, 2007.Wang Liang. Research of real data processing technology on airborne UWB SAR[D]. [Ph.D. dissertation], National University of Defense Technology, 2007.[9] Reigber A, Potsis A, and Alivizatos E, et al.. Wavenumber domain SAR focusing with integrated motion compensation[C]. International Geoscience and Remote Sensing Symposium(IGARSS), Toulouse, France, 2003: 1465-1467.[10] Samcynski P and Kulpa K S. Coherent MapDrift technique[J]. IEEE Transactions on Geoscience and Remote Sensing, 2010, 48(3): 1505-1517. [11] Xing Meng-dao, Jiang Xiu-wei, Wu Ren-biao, Zhou Feng, and Bao Zheng. Motion compensation for UAV SAR based on raw radar data[J]. IEEE Transactions on Geoscience and Remote Sensing, 2009, 47(8): 2870-2883.
